- Page 1 INSTALLATION MANUAL IEC version TSM-DC01A.05 The Solution in Black TSM-DC80.08 The Quadmax Module TSM-DC05A The Honey M Module TSM-DC05A.05 TSM-DC05A.08 TSM-PC05.05 The Aesthetic Module TSM-DC01A The Comax Module TSM-DC01A.08 TSM-PC05 The Universal Module TSM-PC05.08 TSM-PC14 The Utility Module TSM-PD14 TSM-PC05A The Honey Module TSM-PC05A.08...
-
Page 2: Table Of Contents
Table of Content 1. DISCLAIMER OF LIABILITY ......................1 2. SAFETY PRECAUTIONS ........................1 3. UNPACKING AND STORAGE ......................1 3.1. PRODUCT IDENTIFICATION ...................... 2 4. ENVIRONMENTAL CONSIDERATIONS ..................2 4.1. -
Page 3: Disclaimer Of Liability
Trina Solar assumes no responsibility for any infringement of patents or other rights of third parties that may result from use of the module. No license is granted by implication or under any patent or patent rights. -
Page 4: Product Identification
5. SITE SELECTION Trina Solar Modules can be mounted in landscape and portrait orientation however the impact of dirt shading the solar cells can be minimized by orienting the product in portrait. -
Page 5: Mounting With Bolts
B. Mounting with Clamps : Trina Solar has tested its modules with a number of clamps from different manufacturers and recommends the use of clamps which have an EPDM or similar insulating washer, fixing screw of at least M6. The clamp must overlap the module frame by at least 7mm but no more than 10 mm. -
Page 6: Grounding
Trina Solar modules can be installed with the use of third party listed grounding devices for grounding the metallic frames of PV modules. The devices have to be installed in accordance with the grounding device manufacturer’s specified instructions. -
Page 7: Electrical Configuration
10V between strings then check the string configuration before making the connection. Trina Solar modules are provided with stranded copper cables with a cross sectional area of 4mm ² which are rated for 1000Vdc, 90°C and are UV resistant. -
Page 8: Maintenance And Care
Installation close to a source of continual moisture, such as bodies of water To reduce the risk of PID, we strongly suggest that modules feature Trina Solar’s Anti-PID technology, which can be applied to any Trina product. Alternatively, we recommend the use of an inverter that includes a transformer as well as proper grounding of the negative DC leg of the PV array.
