INSTALLATION MANUAL
IEC & UL version
Module Type
TSM-PD15H/.08/.09
TSM-PD06H/.08/.09
TSM-DD15H(II)/ .08(II)/.09(II)
TSM-DD06H(II)/ .08(II)/.09(II)
TSM-PE15H/.08/.09
TSM-PE06H/.08/.09
TSM-DE15
H(II)/ .08(II)/.09(II)/.05(II)
TSM-DE06H(II)
/ .08(II)/.09(II)/.05(II)
TSM-PD15M/.08/.09
TSM-PD06M/.08/.09
TSM-
DD15M(II)/ .08(II)/.09(II)/.05(II)
TSM-
DD06M(II)/ .08(II)/.09(II)/.05(II)
TSM-PE15M/.08/.09
TSM-PE06M/.08/.09
TSM-
DE15M(II)/ .08(II)/.09(II)/.05(II)
TSM-DE06M(II)/ .
08(II)/.09(II)/.05(II)
TSM-PE15A
TSM-PE15A.08
TSM-PE15A.09
TSM-PE15A(II)
TSM-PE15A.08(II)
TSM-PE15A.09(II)
TSM-PE06A
TSM-PE06A.08
TSM-PE06A.09
TSM-PE06A(II)
TSM-PE06A.08(II)
TSM-PE06A.09(II)
TSM-DE15A(II)
TSM-DE15A.08(II)
TSM-DE15A.09(II)
TSM-DE06A(II)
TSM-DE06A.08(II)
TSM-DE06A.09(II)
TSM-PE15H
TSM-PE15H.08
TSM-PE15H.09
TSM-PE15H(II)
TSM-PE15H.08(II)
TSM-PE15H.09(II)
TSM-PE06H
TSM-PE06H.08
TSM-PE06H.09
TSM-PE06H(II)
TSM-PE06H.08(II)
Advertisement
Table of Contents
Related Manuals for Trina Solar TSM-PD15H
Summary of Contents for Trina Solar TSM-PD15H
- Page 1 INSTALLATION MANUAL IEC & UL version TSM-PD15H/.08/.09 TSM-PD06H/.08/.09 TSM-DD15H(II)/ .08(II)/.09(II) TSM-DD06H(II)/ .08(II)/.09(II) TSM-PE15H/.08/.09 TSM-PE06H/.08/.09 TSM-DE15 H(II)/ .08(II)/.09(II)/.05(II) TSM-DE06H(II) / .08(II)/.09(II)/.05(II) TSM-PD15M/.08/.09 TSM-PD06M/.08/.09 TSM- DD15M(II)/ .08(II)/.09(II)/.05(II) TSM- DD06M(II)/ .08(II)/.09(II)/.05(II) TSM-PE15M/.08/.09 TSM-PE06M/.08/.09 TSM- DE15M(II)/ .08(II)/.09(II)/.05(II) TSM-DE06M(II)/ . 08(II)/.09(II)/.05(II) TSM-PE15A TSM-PE15A.08 TSM-PE15A.09 TSM-PE15A(II) TSM-PE15A.08(II)
- Page 2 TSM-PE06H.09(II) TSM-PE15M TSM-PE15M.08 TSM-PE15M.09 TSM-PE15M(II) TSM-PE15M.08(II) TSM-PE15M.09(II) TSM-PE06M TSM-PE06M.08 TSM-PE06M.09 TSM-PE06M(II) TSM-PE06M.08(II) TSM-PE06M.09(II) TSM-DE15H(II) TSM-DE15H.08(II) TSM-DE15H.09(II) TSM-DE06H(II) TSM-DE06H.08(II) TSM-DE06H.09(II) TSM-DE15M(II) TSM-DE15M.08(II) TSM-DE15M.09(II) TSM-DE06M(II) TSM-DE06M.08(II) TSM-DE06M.09(II) TSM-NE15M(II); TSM-ND06M(II); Date: 2019.05.06 Doc No: PS-M-0692 Ver. A Page - 2 - of 13...
-
Page 3: Table Of Contents
Table of Contents DISCLAIMER OF LIABILITY ......................... - 4 - SAFETY PRECAUTIONS ..........................- 4 - UNPACKING AND STORAGE ........................- 5 - PRODUCT IDENTIFICATION........................- 5 - ENVIRONMENTAL CONSIDERATIONS AND SITE SELECTION ............- 5 - CLIMATE CONDITIONS ........................- 5 - SITE SELECTION .......................... -
Page 4: Disclaimer Of Liability
Trina Solar assumes no responsibility for any infringement of patents or other rights of third parties that may result from use of the module. No license is granted by implication or under any patent or patent rights. -
Page 5: Unpacking And Storage
Rated electrical characteristics are within ± 10 percent of measured values at Standard Test Conditions of 1000 W/m², 25°C cell temperature and AM 1.5 solar spectral irradiance. The fire rating of a Trina Solar PV module is valid only when mounted in the manner specified in the mechanical mounting instructions of this installation manual. -
Page 6: Site Selection
5.2 SITE SELECTION Trina Solar Modules can be mounted in landscape or portrait orientation however the impact of dirt shading the solar cells can be minimized by orienting the product in landscape. Solar module is recommended to be installed at an optimized tilt angle to maximize the energy output. It is roughly equal to the latitude of the project site as a rule of thumb, facing to equator. -
Page 7: Mounting With Clamps
5) HEX Stainless Nut B. Mounting with Clamps Trina Solar has tested its modules with a number of clamps from different manufacturers and recommends the use of clamps which have an EPDM or similar insulating washer, fixing bolt of at least M8. -
Page 8: Mounting With Single-Axis Tracking System
3600Pa, and negative design loading 1600Pa, with 1.5 times safety factor, and product failure as a result of an overload situation will not be covered by the Trina Solar warranty. C. Mounting with Single-axis Tracking System ... - Page 9 Secure the module in each fixing location with an M6 bolt, two flat washers, a spring washer and nut as shown in Figure 3. If a different bolt similar to M6 is used, they need to be tightened to a torque of 16N.m.(140lbf.in). ...
-
Page 10: Grounding
Trina Solar modules can be installed with the use of third party listed grounding devices for grounding the metallic frames of PV modules. The devices have to be installed in accordance with the grounding device manufacturer’s specified instructions. -
Page 11: Electrical Configuration
7.2 INVERTER SELETION AND COMPATIBILITY When installed in systems governed by IEC regulations, Trina Solar modules normally do not need to be electronically connected to earth and therefore can be operated together with either galvanically isolated (with transformer) and transformerless inverters. - Page 12 Cover the front surface of modules by an opaque material when repairing. Modules when exposed to sunlight generate high voltage and are dangerous. Trina Solar PV modules are equipped with bypass diodes in the junction box. This minimizes module heating and current losses.
-
Page 13: Warning
Contact your installer Contact Trina Solar after sales service team at http://customerservice.trinasolar.com/ Submit the Customer Feedback form at: http://www.trinasolar.com/ and one of our technical service representatives will contact you within 5 business days. A username and password is required to send feedback from the customer service link ...
