Trina Solar TSM-DE08M User Manual

166-cell back sheet-glass framed module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL _166-cell Back Sheet-Glass Framed Module
USER MANUAL ................................................................................................................. 1
1.
INTRODUCTION FOR USER MANUAL ...................................................................... 2
1.1
DISCLAIMER ................................................................................................ 2
1.2
LIMITATION OF LIABILITY .......................................................................... 2
2.
SAFETY PRECAUTIONS ........................................................................................... 2
2.1
WARING ....................................................................................................... 2
2.2
GENERAL SAFETY ...................................................................................... 2
2.3
HANDLING SAFETY .................................................................................... 2
3.
UNLOAD/TRANSPROTATION/STORAGE ................................................................ 3
3.1
MAKERS ON OUTER PACKAGING ............................................................ 3
3.2
UNLOADING WARNNING ........................................................................... 4
3.3
SECONDARY TRANSPORT AND WARNNING ........................................ 5
3.4
STORAGE .................................................................................................... 6
4.
UNPACKING INTRODUCTION .................................................................................. 7
4.1
UNPACKING SAFETY ................................................................................. 7
4.2
UNPACKING STEP ...................................................................................... 7
5.
SITE SELECTION ....................................................................................................... 8
6.
TILT ANGLE ................................................................................................................ 9
7.
INSTALLATION .......................................................................................................... 9
7.1
INSTALLATION SAFETY ............................................................................. 9
7.2
INSTALLATION METHOD .......................................................................... 10
7.2.1 MECHINICAL INSTALLATION AND WARRING ........................................ 10
7.2.2 GROUNDING ............................................................................................. 14
7.2.3 ELECTRICAL INSTALLATION ................................................................... 17
8.
INVERTER SELECTION AND COMPATIBILITY ..................................................... 19
9.
MODULE MAINTENANCE FOR PV MODULE PV .................................................. 19
9.1
PANEL VISION INSPECTION AND REPLACEMENT ............................... 19
9.2
CONNECTOR AND CABLE INSPECTION .................................................. 20
9.3
CLEANNING ............................................................................................... 20
9.3.1 REQUIREMENTS FOR WATER QUALITY ............................................... 21
9.3.2 MODULE INSPECTION AFTER CLEANING ............................................ 21
9.3.3 TROUBLESHOOTING 40 ........................................................................... 21
10. REPORTING TECHNICAL ISSUES or CLAIMS ...................................................... 21
Date: Dec 26th, 2019
Doc No: PS-M-0871
Ver: A
Page 1 of 21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TSM-DE08M and is the answer not in the manual?

Questions and answers

Related Manuals for Trina Solar TSM-DE08M

Summary of Contents for Trina Solar TSM-DE08M

  • Page 1: Table Of Contents

    USER MANUAL _166-cell Back Sheet-Glass Framed Module USER MANUAL ......................... 1 INTRODUCTION FOR USER MANUAL ..............2 DISCLAIMER ....................2 LIMITATION OF LIABILITY ................2 SAFETY PRECAUTIONS ................... 2 WARING ....................... 2 GENERAL SAFETY ..................2 HANDLING SAFETY ..................2 UNLOAD/TRANSPROTATION/STORAGE ..............

  • Page 2: Introduction For User Manual

    Manual for future reference. 1.1 DISCLAIMER Trina Solar reserves the rights to change this User Manual without prior notice. Failure of the customer to follow the requirements outlined in this Manual during the installation of the module will result in the invalidity of product's limited warranty.

  • Page 3: Unload/Transprotation/Storage

    take care to keep modules and in particular their electrical contacts, clean and dry before installation. If connector cables are left in damp conditions then the contacts may corrode. Any module with corroded contacts should not be used. Please do NOT loosen or unscrew the PV module bolts. This may lead to a reduction of the module’s load rating and potential damage from a fall.

  • Page 4: Unloading Warnning

    3.1.5 3.1.6 Do NOT step on the package and module The carton can be recycled 3.1.7 3.1.8 Modules shall be stacked as required, not exceeding One module shall be handled by at least two the maximum number of layers printed on the outer persons together packaging.

  • Page 5: Secondary Transport And Warnning

    3.2.3 3.2.4 Store the module in a dry and ventilated place Do Not stack the modules at the project site. 3.2.5 Cover the module with waterproof material to prevent it from moisture SECONDARY TRANSPORT AND WARNNING 3.3.1 3.3.2 Do NOT remove the original packaging if the The finished package can be transported by land, modules require long-distance transport or long- sea or air.

  • Page 6: Storage

    3.3.5 3.3.6 No transport or handling by pedi-cab as shown Do Not transport the module with rope as shown below; below: 3.3.7 Do Not carry the modules on the back of one person as shown below; STORAGE Do NOT expose the modules to rain or moisture. Store the finished product in a well ventilated, waterproof and dry place.

  • Page 7: Unpacking Introduction

    3.4.2 Normal warehouse storage (moisture＜85% and temperature range from -20°C to + 50 °C): 120-cell frame module to be stacked no more than three layers and 144-cell frame module to be stacked no more than two layers (take 144-cell frame module for example) 120 cell 144 cell 4.

  • Page 8: Site Selection

    4.2.3 4.2.4 Cut the tape at shorter edge and hold it up by 90° Cut the two horizontal packing belts in the carton from the bottom; and pull out the cardboard to and cut the two packing belts near the bottom of expose the modules.

  • Page 9: Tilt Angle

    Trina Solar Framed series modules may be installed in the following conditions to produce energy for more than 25 years. In addition to the required IEC certifications, Trina Solar products have also been tested to verify resistance to ammonia fumes that may be present around barns sheltering cattle, as well as suitability for installation in humid (coastal) areas and areas of high sand storms.

  • Page 10: Installation Method

    The application level of Trina Solar module is Class A, which can be used in systems operating at greater than 50 V DC or 240 W, where general public contact access is anticipated; Keep the PV module packed in the Trina carton until installation.
  • Page 11 thickness with an outer diameter of 20-24mm (0.79-0.94in). Fig.1 Backsheet-Glass module 1) Aluminum Frame 2) M8 Stainless Bolt 3) Flat Stainless Washer 4) Spring Stainless Washer 5) HEX Stainless Nut Mechanical Safety Module Mounting Direction Load Pressure factor 120 pcs Back sheet- 3600 Pa /-...
  • Page 12 4 installation holes of 7*10 mm are used for Single-axis tracking system installation, as shown in Figure 2 To maximize mounting longevity, Trina Solar strongly recommends the use of corrosion proof (stainless steel) attachment hardware.
  • Page 13 2400Pa C. Mounting with Clamps Trina Solar has tested its modules with a number of clamps from different manufacturers, mounting bolt of at least M8. The length of clamp ≥40mm (1.57in) , thickness≥ 3mm(0.12in). The clamp must overlap the module frame by at least 7mm (0.28in) but no more than 10mm (0.39in).

  • Page 14: Grounding

    National Electrical Codes. The grounding conductor must then make a connection to earth using a suitable earth ground electrode.  Trina Solar modules can be installed with the use of third party listed grounding devices for grounding the metallic frames of PV modules. The devices have to be installed in accordance with the grounding device manufacturer’s specified instructions.
  • Page 15 wire binding bolt. Star washer, flat washer, grounding wire are placed in turn, then screwed into the grounding hole to bond the adjacent modules  Trina recommends using the following methods to ground modules properly, Method 1: Tyco grounding bolt # 2058729-1: Figure 4.
  • Page 16 Method 2: Tyco grounding bolt #1954381-2: Figure 5. Tyco grounding bolt # 1954381-2 (NOT applicable for TRINAMOUNT module series) 1) Wire slot (available for 0.006 to 0.025in cable) 2) Slider 3) Bolt 4) Base 5) Nut Tyco grounding hardware comes in a package that includes the grounding bolt, mounting and grounding hex nut.

  • Page 17: Electrical Installation

    For proper wire binding, machine bolt B should be torqued to 35lbf.in. INSTALL EFFECT CHART The install effect chart is as follows. Please consult with Trina Solar engineers to confirm whether the rails match Trina clamp/frame or not. And confirm there are no shelter on the back of the modules.
  • Page 18 10V between strings then check the string configuration before making the connection. Trina Solar modules are provided with stranded copper cables with a cross sectional area of 4mm²(0.006in²) which are UV resistant. All other cables used to connect the DC system should have a similar (or better) specification.

  • Page 19: Inverter Selection And Compatibility

    Do NOT share a fuse in a Combiner Box with two or more strings in parallel connection. INVERTER SELECTION AND COMPATIBILITY When installed in systems governed by IEC regulations, Trina Solar modules normally do not need to be electronically connected to earth and therefore can be operated together with either galvanically isolated (with transformer) and transformerless inverters.

  • Page 20: Connector And Cable Inspection

    o In a system using a battery, blocking diodes are typically placed between the battery and the PV module output to prevent battery discharge at night. In the event that a module is damaged (broken glass or a scratch on back sheet) and needs to be replaced o Observe the safety precautions listed earlier in this Manual o Wear cut resistant gloves and other personal protective equipment required for the particular...

  • Page 21: Requirements For Water Quality

    10. REPORTING TECHNICAL ISSUES or CLAIMS  Contact your installer  Contact Trina Solar after sales service team at http://customerservice.trinasolar.com/  Submit the Customer Feedback form at: http://www.trinasolar.com/ and one of our technical service representatives will contact you within 5 business days.
