Graco 19B120 Manual

Texture Guns
Models: 288628, 288629, 245924, 19B120
125 psi (8.75 bar, 0.875 MPa) Maximum Air Working Pressure
70 psi (4.9 bar, 0.49 MPa) Maximum Fluid Working Pressure
IMPORTANT SAFETY INSTRUCTIONS.
sprayer instruction manual for Pressure Relief, priming and
spray instructions. Keep these instructions.
The following Warnings are for the setup, use, grounding, maintenance and repair of this equipment. The exclamation point
symbol alerts you to a general warning and hazard symbols refer to procedure-specific risks. Refer back to these Warnings.
Additional, product-specific warnings may be found throughout the body of this manual where applicable.
WARNINGS
PRESSURIZED EQUIPMENT HAZARD
Fluid from the gun/dispense valve, leaks, or ruptured
components can splash in the eyes or on skin and
cause serious injury.
• Follow Pressure Relief Procedure in this manual when
you stop spraying and before cleaning, checking, or
servicing equipment.
• Tighten all fluid connections before operating the
equipment.
• Check hoses, tubes, and couplings daily. Replace worn
or damaged parts immediately.
FIRE AND EXPLOSION HAZARD
Flammable fumes, such as solvent and paint fumes,
in work area can ignite or explode. To help prevent
fire and explosion:
• Use equipment only in well ventilated area.
• Eliminate all ignition sources; such as pilot lights, ciga-
rettes, portable electric lamps, and plastic drop cloths
(potential static arc).
• Keep work area free of debris, including solvent, rags
and gasoline.
• Do not plug or unplug power cords, or turn power or light
switches on or off when flammable fumes are present.
• Ground all equipment in the work area. See Grounding
instructions.
• Use only grounded hoses.
• Hold gun firmly to side of grounded pail when triggering
into pail.
• If there is static sparking or you feel a shock, stop oper-
ation immediately. Do not use equipment until you
identify and correct the problem.
• Keep a working fire extinguisher in the work area.
Refer to your
- For Water-Based Materials Only -
• Do not operate the unit when fatigued or under the influ-
ence of drugs or alcohol.
• Do not exceed the maximum working pressure or tem-
perature rating of the lowest rated system component.
See Technical Data in all equipment manuals.
• Use fluids that are compatible with equipment wetted
parts. See Technical Data in all equipment manuals.
Read fluid manufacturer's warnings. For complete infor-
mation about your material, request MSDS forms from
distributor or retailer.
• Check equipment daily. Repair or replace worn or dam-
aged parts immediately with genuine manufacturer's
replacement parts only.
• Do not alter or modify equipment.
• Use equipment only for its intended purpose. Call your
distributor for information.
• Route hoses and cables away from traffic areas, sharp
edges, moving parts, and hot surfaces.
• Do not kink or over bend hoses or use hoses to pull
equipment.
• Keep children and animals away from work area.
• Comply with all applicable safety regulations.
• Protective eyewear
• Clothing and respirator as recommended by the fluid and
solvent manufacturer
• Gloves
• Hearing protection
CALIFORNIA PROPOSITION 65
This product contains a chemical known to the State of
California to cause cancer, birth defects or other
reproductive harm. Wash hands after handling.
Model 245924
with hopper
Model 288628
without hopper
EQUIPMENT MISUSE HAZARD
Misuse can cause death or serious injury.
PERSONAL PROTECTIVE EQUIPMENT
You must wear appropriate protective equipment
when operating, servicing, or in the operating area
of the equipment to help protect you from serious
injury. This equipment includes but is not limited to:
311777G
Model 19B120
Model 288629
