- Page 1 OPERATION AND INSTALLATION Electronically controlled instantaneous water heater » DHB-E 13 AU » DHB-E 18 AU » DHB-E 27 AU electronic °C...
-
Page 2: Table Of Contents
CONTENTS | SPECIAL INFORMATION SPECIAL INFORMATION SPECIAL INFORMATION OPERATION General information �����������������������������������������3 - The appliance may be used by children aged 8 Safety instructions ����������������������������������������������� 3 and up and persons with reduced physical, sen- Other symbols in this documentation ����������������������� 3 sory or mental capabilities or a lack of experience Units of measurement ������������������������������������������... -
Page 3: General Information
OPERATION General information OPERATION Other symbols in this documentation Note Notes are bordered by horizontal lines above and below the text. General information is identified by the symbol General information shown on the left. f Read these texts carefully. The chapter "Operation" is intended for appliance users and qual- ified contractors. -
Page 4: Ce Designation
Appliance description Settings Damage to the appliance and environment Protect the appliance and its tap against frost. DHB-E 13 AU CE designation The CE designation shows that the appliance meets all essential requirements according to the: - Low Voltage Directive... -
Page 5: Troubleshooting
OPERATION Troubleshooting Troubleshooting Fault Cause Remedy The appliance will There is no voltage in the Check the fuses/MCBs in not start despite the appliance. your fuse box/distribution DHW valve being panel. fully open. The aerator in the tap or Clean and/or descale the the shower head is scaled aerator or shower head. -
Page 6: Installation
INSTALLATION Safety INSTALLATION Appliance description Standard delivery The following are delivered with the appliance: Safety - Mounting bracket Only a qualified contractor should carry out installation, commis- - Installation template sioning, maintenance and repair of the appliance. - 2 plugs - 2 extensions General safety instructions - 2 caps... -
Page 7: Installation Site
INSTALLATION Installation 10. Installation Installation site Material losses 10.1 Standard installation Only install the appliance in rooms free from the risk of - Electrical connection in the lower section of the appliance for frost. installation on unfinished walls - Water connection for installation on finished walls f Always install the appliance vertically near the draw-off point. - Page 8 INSTALLATION Installation Note f Install the flow limiter. f With low water pressure.The pressure drop can be reduced by replacing the flow limiter with the plastic profile washer provided. 1 Installation aid Installing the appliance f Prepare the power cable. Preparing the water connection Material losses Carry out all water connection and installation work in...
- Page 9 INSTALLATION Installation Lower back panel installation f Screw the pre-assembled parts with flat gaskets to the cold 1 Connection pieces delivered in the pack water and DHW pipes of the appliance. 2 Screw f Fit the cold water inlet pipe and the DHW outlet pipe from f Cut open the lower part of the back panel (see illustration).
-
Page 10: Completing The Installation
INSTALLATION Installation 10.2 Completing the installation 10.3 Installation options f Open the shut-off valve in the cold water inlet line. - Electrical connection from above on unfinished walls - Electrical connection for finished walls Fitting the sealing elements for the appliance cover - Large cross-section for electrical connection from below - Water installation on unfinished walls - Wall mounting bracket when replacing an appliance... - Page 11 INSTALLATION Installation Damage to the appliance and environment The strainer must be fitted for the appliance to function. f When replacing the appliance, check that the strain- er is present. f Screw the connection pipes from the appliance to the tee. f Open the shut-off valve in the cold water inlet line.
- Page 12 INSTALLATION Installation Installation with offset tiles Temperature limitation / Anti-scalding protection The maximum temperature can be limited to 43 °C via the pro- gramming unit on the appliance cover. For this, the following steps are necessary: f Remove the appliance cover. f Remove the electronic PCB from the programming unit on the appliance cover.
-
Page 13: Commissioning
INSTALLATION Commissioning 11. Commissioning 12. Shutting down the system f Isolate all poles of the appliance from the power supply. WARNING Electrocution f Drain the appliance (see chapter "Maintenance"). Commissioning may only be carried out by a qualified contractor in accordance with safety regulations. 11.1 Initial start-up electronic electronic... -
Page 14: Troubleshooting
INSTALLATION Troubleshooting 13. Troubleshooting WARNING Electrocution In order to check the appliance it must be connected to the power supply. 13.1 Indicator options for LED diagnostic traffic light Indicator options Illuminates in the event of a fault Yellow Illuminates during heating mode Green Flashing: Appliance is supplied with mains power 13.2 Fault table... -
Page 15: Maintenance
INSTALLATION Maintenance 14. Maintenance 15. Specification 15.1 Dimensions and connections WARNING Electrocution Before any work on the appliance, disconnect all poles from the power supply. ≤ 20 Draining the appliance You can drain the appliance for maintenance work. CAUTION Scalding Hot water may escape when draining the appliance. -
Page 16: Wiring Diagram
INSTALLATION Specification 15.2 Wiring diagram Connected load in kW 50 °C DHW output in l/min. Rated voltage Cold water inlet temperature 380 V 400 V 415 V 5 °C 10 °C 15 °C 20 °C 3/PE ~ 380-415 V 10.1 11.0 12.0 12.2 13.2 13.5 13.6 14.2... -
Page 17: Fault Conditions
INSTALLATION Specification 15.6 Fault conditions In case of faults, loads up to 95 °C at a pressure of 1.0 MPa can occur temporarily in the installation. 15.7 Data table DHB-E 13 AU DHB-E 18 AU DHB-E 27 AU 232360 233986 233987 Electrical data... -
Page 18: Warranty
Who gives the warranty 9.3. The name, address and contact details (such as phone The warranty is given by Stiebel Eltron (Aust) Pty Ltd number and e-mail address) of the owner; (A.B.N. 82 066 271 083) of Unit 4/8 Rocklea Drive, Port Mel- 9.4. - Page 19 The Stiebel Eltron warranty for the unit is in addition to any d) connection to an incorrect power supply; rights and remedies you may have under the Australian e) connection to faulty equipment, such as damaged Consumer Law.
- Page 20 Deutschland Verkauf Tel. 05531 702-110 | Fax 05531 702-95108 | info-center@stiebel-eltron.de STIEBEL ELTRON GmbH & Co. KG Kundendienst Tel. 05531 702-111 | Fax 05531 702-95890 | kundendienst@stiebel-eltron.de Dr.-Stiebel-Straße 33 | 37603 Holzminden Ersatzteilverkauf Tel. 05531 702-120 | Fax 05531 702-95335 | ersatzteile@stiebel-eltron.de Tel.
