Electronically controlled comfort instantaneous water heater
Hide thumbs Also See for DHB-E 13 AU:

Advertisement

Quick Links

OPERATION AND INSTALLATION
Electronically controlled comfort instantaneous water heater
» DHB-E 13 AU
» DHB-E 18 AU
» DHB-E 27 AU
electronic
°C
45
40
50
35
55
30
60

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DHB-E 13 AU and is the answer not in the manual?

Questions and answers

Summary of Contents for STIEBEL ELTRON DHB-E 13 AU

  • Page 1 OPERATION AND INSTALLATION Electronically controlled comfort instantaneous water heater » DHB-E 13 AU » DHB-E 18 AU » DHB-E 27 AU electronic °C...
  • Page 2: Table Of Contents

    Instructions, standards and regulations �������������������� 7 supplying a shower (shower operation). Appliance description ���������������������������������������7 Standard delivery ������������������������������������������������ 7 - Shower information for DHB-E 13 AU: Preparation ���������������������������������������������������7 The appliance is suitable for supplying a Installation location ��������������������������������������������� 7 shower (shower operation). When using pre- Installation ����������������������������������������������������8...
  • Page 3: General Information

    OPERATION General information OPERATION - Drain the appliance as described in chapter "Installation / Maintenance / Draining the appliance". General information The chapter "Operation" is intended for appliance users and qual- ified contractors. The chapter "Installation" is intended for qualified contractors. Note Read these instructions carefully before using the appli- ance and retain them for future reference.
  • Page 4: Other Symbols In This Documentation

    OPERATION Safety Other symbols in this documentation WARNING Injury The appliance may be used by children aged 3 and older Note and persons with reduced physical, sensory or mental Notes are bordered by horizontal lines above and below capabilities or a lack of experience and know-how, pro- the text.
  • Page 5: Settings

    OPERATION Settings Settings Following an interruption to the water supply DHB-E 13 AU Material losses To ensure that the bare wire heating system is not dam- aged following an interruption to the water supply, the appliance must be restarted by taking the following steps.
  • Page 6: Troubleshooting

    This appliance contains capacitors which are discharged when disconnected from the power supply. The capacitor discharge voltage may briefly reach > 60 V DC. Information on shower operatio DHB-E 13 AU CAUTION Burns If the water supplied to the appliance is preheated, please note the following points: The internally adjustable anti-scalding protection that is may be exceeded.
  • Page 7: Instructions, Standards And Regulations

    INSTALLATION Appliance description Instructions, standards and regulations Flow rate f Ensure that the flow rate (see chapter "Specification / Data table", On) is sufficient for switching on the appliance. Note Observe all applicable national and regional regulations f Increase the mains water pressure if the required flow rate is and instructions.
  • Page 8: Installation

    INSTALLATION Installation Oversink installation f Fit the wall mounting bracket. Align the installation template based on the existing electrical connection when marking out the drill holes (wall mounting and lower back panel). If you want to adapt the existing water connections, take the di- 1 Cold water inlet mensions from the drawing when marking out the drill holes;...
  • Page 9 INSTALLATION Installation f Press the appliance over the threaded stud of the wall Damage to the appliance and environmental pollution mounting bracket. When doing so, push through the soft The strainer must be fitted for the appliance to function. seal in the back panel of the appliance. If necessary, use a f When replacing the appliance, check that the strain- screwdriver.
  • Page 10: Completing The Installation

    INSTALLATION Installation 10.2 Completing the installation Lower back panel installation f Open the shut-off valve in the cold water inlet line. Fitting the sealing elements for the appliance cover 1 Connection pieces delivered in the pack 2 Screw f Cut open the lower back panel (see illustration). f Fit the lower back panel by bending it out at the sides and guiding it over the pipes.
  • Page 11: Installation Options

    INSTALLATION Installation 10.3 Installation options Large conductor cross-section for electrical connection from below - Electrical connection from above on unfinished walls If you use cables with a large cross-section, you can fit the cable - Electrical connection on finished walls grommet after the appliance has been installed.
  • Page 12 INSTALLATION Installation Installation with offset tiles f Fit the strainer and the plastic profile washer in the tee for the cold water inlet. Damage to the appliance and environmental pollution The strainer must be fitted for the appliance to function. f When replacing the appliance, check that the strain- er is present.
  • Page 13: Temperature Limit / Anti-Scalding Protection

    INSTALLATION Commissioning 11. Commissioning 10.4 Temperature limit / Anti-scalding protection The maximum temperature can be limited on the programming WARNING Electrocution unit of the appliance cover. The maximum temperature can on Commissioning must only be carried out by a qualified the programming unit of the appliance cover.
  • Page 14: Appliance Shutdown

    INSTALLATION Appliance shutdown 12. Appliance shutdown f Isolate all poles of the appliance from the power supply. f Drain the appliance (see chapter "Maintenance"). 13. Troubleshooting WARNING Electrocution In order to check the appliance it must be connected to the power supply. 13.1 Indicator options for LED diagnostic traffic light Indicator options Illuminates in the event of a fault...
  • Page 15: Maintenance

    INSTALLATION Maintenance 14. Maintenance 15. Specification 15.1 Dimensions and connections WARNING Electrocution Before any work on the appliance, disconnect all poles from the power supply. ≤ 20 Draining the appliance The appliance can be drained for maintenance work. CAUTION Scalding Hot water may escape when draining the appliance.
  • Page 16: Wiring Diagram

    INSTALLATION Specification 15.2 Wiring diagram 15.4 Application areas / Conversion table Specific electrical resistivity and specific electrical conductivity 3/PE ~ 380-415 V (see chapter "Data table"). Standard specifica- tion at 15 °C 20 °C 25 °C Conductivity σ Conductivity σ Conductivity σ Resist- Resist- Resist- ance ρ...
  • Page 17: Data Table

    INSTALLATION | ENVIRONMENT AND RECYCLING Data table 15.8 Data table DHB-E 13 AU DHB-E 18 AU DHB-E 27 AU 232360 233986 233987 Electrical data Rated voltage Rated output 12.2 13.5 14.5 16.2 19.4 23.5 Rated current 18.5 19.5 20.2 24.7 35.6...
  • Page 18 Contact person: Customer Service Representative The Stiebel Eltron warranty for the unit is in addition to any rights E-mail: service@stiebel.com.au and remedies you may have under the Australian Consumer Law.
  • Page 19 NOTES www.stiebel-eltron.com DHB-E AU|...
