Command Set - multicomp pro MP710080 User Manual

COMMAND SET

Command code & Return Value
Input Command: SOUT<Output>[CR]
Return Value: [OK][CR]
Input Command: GOUT [CR]
Return Value: <Output> [CR][OK][CR]
Input Command: SETD <VOLTAGE><CURRENT>[CR]
Return Value: [OK][CR]
Input Command: GETD [CR]
Return Value: <Voltage><;><Current><;>
<CV/CC Mode><;>[CR][OK][CR]
Input Command: GETS [CR]
Return Value: <Voltage><;><Current><;>[CR][OK][CR]
Input Command: VOLT<Voltage>[CR]
Return Value: [OK][CR]
Input Command: CURR<Current>[CR]
Return Value: [OK][CR]
Input Command: GVSH [CR]
Return Value: <Voltage>[CR][OK][CR]
Input Command: GVSL [CR]
Return Value: <Voltage>[CR][OK][CR]
Input Command: GISH [CR]
Return Value: <Current>[CR][OK][CR]
Input Command: GISL [CR]
Return Value: <Current>[CR][OK][CR]
Input Command: GMAX [CR]
Return Value: <Voltage><;><Current><;>[CR][OK][CR]
Input Command: GMIN [CR]
Return Value: <Voltage><;><Current><;>[CR][OK][CR]
Description
Set Output on/off
Set Output off: <Output>=0
Set Output on: <Output>=1
Get Output Status
Output off: <Output>=0
Output on: <Output> =1
SET Voltage and Current
<voltage> =0000~3640
<Current> =0000~5100
Get display Volt & display Curr &
CV/CC mode
<voltage> =0~9999
<Current> =0~9999
<CV mode> =0 CV Mode
<CC mode> =0 CC Mode
Get Setting Volt & Curr
<voltage> =0~3640
<current> =0~5100
Set output voltage
Set output current
Get voltage set high limit
<voltage>=????
Get voltage set low limit
<voltage>=???
Get current set high limit
<Current>=????
Get current set low limit
<Current>=???
Get voltage set high limit & current
set high limit
<voltage> =????
<current> =????
Get voltage set low limit & current
set low limit
<voltage> =???
<current> =???
Example
Input Command: SOUT0[CR]
Return Value: [OK][CR]
Meaning: Set Output off
Input Command: GOUT[CR]
Return Value: 0[CR][OK][CR]
Meaning: Output is off
Input Command:
SETD05001000[CR]
Return Value: [OK][CR]
Meaning: Voltage 5.00V Current
1.000A
Input Command: GETD [CR]
Return Value:
500;1000;0;[CR][OK][CR]
Meaning: The Display value is
5.00V and 1.000A
It is CV mode
Input Command: GETS[CR]
Return Value:
500;1000;[CR][OK][CR]
Meaning: The Memory setting
voltage value is 5.00V and Current
is 1.000A
Input Command: VOLT 1000[CR]
Return Value: [OK][CR]
Meaning: Set voltage value is
10.00V
Input Command: CURR1000[CR]
Return Value: [OK][CR]
Meaning: Set Current value is
1.000A
Input Command: GVSH [CR]
Return Value: 3600 [CR][OK][CR]
Meaning: voltage set high limit is
36.00V
Input Command: GVSL [CR]
Return Value: 100 [CR][OK][CR]
Meaning: Voltage set low limit is
1.00V
Input Command: GISH [CR]
Return Value: 5500 [CR][OK][CR]
Meaning: Current set high limit is
5.500A
Input Command: GISL [CR]
Return Value: 250 [CR][OK][CR]
Meaning: Current set low limit is
0.250A
Input Command: GMAX [CR]
Return Value:
3600;5500;[CR][OK][CR]
Meaning: Voltage set high limit is
36.00V & Current set high limit is
5.500A
Input Command: GMIN [CR]
Return Value:
100;250;[CR][OK][CR]
Meaning: Voltage set low limit is
1.00V & Current set low limit is
0.250A
