Contents High-pressure washer OPERATING INSTRUCTIONS Thank you for buying this high-pressure washer. Before using it, please read carefully this operating manual and retain it for further use. CONTENTS 1. GENERAL SAFETY INSTRUCTIONS ....................4 2. SYMBOLS .............................. 5 3. GENERAL DESCRIPTION ........................ 7 4. -
Page 3: General Safety Instructions
Adherence to the attached instructions for use is a precondition for the proper use of the machine. The operation manual includes also instructions for operation, maintenance and repairs. The manufacturer does not take any responsibility for accidents or damages resulting from the failure to adhere to this manual. FDW 2001 E FDW 2004-E FDW 201201-E... -
Page 4: Symbols
Symbols Symbols 2. SYMBOLS To ensure your own safety as well as safety of other persons, read the Instruction Manual attentively prior to the fi st startup of the high-pressure washer. Keep the Instruction Manual in a safe and practical place to be available when needed. - Page 5 This product is made in compliance with approved standards. Electrical appliances shall not be disposed in the household waste. Use ears protection. FDW 2004-E FDW 2001 E FDW 201201-E...
-
Page 6: General Description
General description General description 3. GENERAL DESCRIPTION The final p oduct can differ from the depicted device. 1 - Motor and Pump in Case 10 - Variable Spray Nozzle with Lance 2 - ON/OFF switch 11 - High-Pressure Hose 3 - Cord Wrap 13 - Shipping Plug Poznámka: Photographs and line drawings used in this manual are for reference only and 4 - Power Supply Cord... -
Page 7: Safety Instructions
FDW 2004-E their safety. Never use any accessories unless delivered together with the product or intended particularly for the appliance. FDW 201201-E... - Page 8 Inappropriate extension cables can be dangerous. Should an extension cable be used, both the socket and the plug shall be of a waterproof design and the coupled parts shall be kept Safety instructions dry and with no connection with earth. We recommend using of an extension cable drum keeping the socket 60 mm above the ground as minimum.
- Page 9 Should you use an extension cable to the power supply network, it shall be of the waterproof design. The manufacturer shall not be liable for damages caused by inappropriate use of the appliance and accessories (injuries, burns, scalding, fi e, food spoilage, etc.). FDW 2004-E FDW 2001 E FDW 201201-E...
-
Page 10: Assembly Instructions
Assembly instructions Assembly instructions 5. ASSEMBLY INSTRUCTIONS Locate and remove all loose parts from the carton. Click the storage hook into the back part and fix it with t o screws. Remove and discard the shipping plug from the outlet on the front of the machine. PRESSURE WASHER OPERATING FEATURES HOW TO USE VARIABLE SPRAY LANCE ATTENTION! NOTICE:... -
Page 11: Starting
Connect the garden hose to the connector on the back of the machine. Before connecting, run water through the garden hose {not supplied) to flush cut a y foreign matter. FDW 2001 E FDW 2004-E FDW 2001 E FDW 2001 E FDW 201201-E... - Page 12 Starting Note: If your water source is a well, the garden hose length can only be 9m as maximum. Insert the spray lance into the gun by pushing fi mly and simultaneously twisting a 1/4 of a turn counter clockwise until locked into place. ATTENTION! WARNING If the lance is not securely locked into place, it could be ejected under high pressure during operation, possibly causing injury or damage.
- Page 13 Squeeze the trigger to start motor and begin pressure washing. Note: The motor only runs when the gun trigger is depressed and warier Is spraying. Shutting down ISee Storage section in this manual for proper shutdown and storage procedures. FDW 2001 E FDW 2004-E FDW 201201-E...
-
Page 14: Storage
Storage Storage 7. STORAGE ATTENTION! CAUTION: Prior to moving the unit, always disconnect the garden hose via the garden hose connector. ATTENTION! CAUTION: Always store your pressure washer in a location where the temperature will not fall below 40 °F (4 °C). The pump in this machine is susceptible to permanent damage if frozen. FREEZE DAMAGE IS NOT COVERED BY THE WARRANTY. -
Page 15: Troubleshooting Guide
If you feel you are using more detergent than is required for the application, you can dilute the detergent with regular tap water. FDW 2001 E FDW 2004-E FDW 201201-E... - Page 16 Troubleshooting Guide Troubleshooting guide Circuit breaker trips Circuit overload Verify that the circuit is rated at 15 amps or or fuse blown in greater. Ensure no other appliance is drawing fuse box power from the same circuit [dedicated circuit). Extensor Cord too We do not recommend using of extension long or wire gauge too cords with your high-pressure washer.
- Page 17 Clean the nozzle according to the instructions overheated provided in the Nozzle paragraph under Maintenance section of this manual. Allow the motor to cool for 20 minutes before troubleshooting and the switch will automatically reset FDW 2001 E FDW 2004-E FDW 201201-E...
- Page 18 Troubleshooting Guide Troubleshooting guide To attach the Lance - apply steady Connecting and Disconnecting the downward pressure on the lance (in the Spray Lance direction of the trigger) while simultaneously Note: Due twisting the lance 90° counter clockwise. It to the high may help if you set the gun vertically on a flat pressures produced surface with the lance pointing upwards.
-
Page 19: Technical Specification
You can inform about the system impedance at the local power distributor´s office, if necessa y. Changes of the text and technical specifications reserved. The User’s Manual is in a specific language ersion. FDW 2001 E FDW 2004-E FDW 201201-E... -
Page 20: Declaration Of Conformity
10. DECLARATION OF CONFORMITY Product / Name: HIGH-PRESSURE WASHER / FIELDMANN Type / Model: FDW 2004-E, FDW 201201-E............230V / 50Hz /1 200W The product complies with the following directives: The Directive of the European Parliament and the Council No. 2014/35/EU on the harmonisation of the laws of Member States relating to electrical equipment designed for use within certain voltage limits. -
Page 21: Disposal
