Summary of Contents for Fisher & Paykel DW60UC4X2
- Page 1 BUILT-UNDER DISHWASHER CONTEMPORARY DW60UC4X2, DW60UN4X2, DW60UN4B2, DW60UC2X2, DW60UN2X2 & DW60UN2B2 models INSTALLATION GUIDE NZ AU...
-
Page 3: Safety And Warnings
SAFETY AND WARNINGS WARNING! WARNING! Electric Shock Hazard Cut Hazard Failure to follow this advice may result in Failure to use caution could result in injury. electrical shock or death. • Take care – panel edges are sharp. • This appliance must be earthed. This appliance has a cord with an equipment-earthing conductor WARNING! and an earthing plug. - Page 4 SAFETY AND WARNINGS WARNING! Failure to install the custom panels correctly could invalidate any warranty or liability claims. To reduce the risk of fire, injury to persons or damage when using the appliance, follow the Installation of this dishwasher requires basic mechanical and electrical skills. important safety instructions listed below.
-
Page 5: Components Required
COMPONENTS REQUIRED PARTS TOOLS Keep all packing materials until the unit has been inspected. Not supplied Not supplied Inspect the product to ensure there is no shipping damage. If any damage is detected contact the dealer or retailer you bought the product from to report the damage. Fisher &... -
Page 6: Product Dimensions
PRODUCT DIMENSIONS Models: DW60UC4X2 , DW60UC2X2 Product Dimensions a Overall height of product* 820 - 880 B Overall width of product c Overall depth of product D Height of chassis e Depth of chassis DATUM: DOOR f Height of feet*... - Page 7 PRODUCT DIMENSIONS Models: DW60UN4X2 , DW60UN4B2 , DW60UN2X2 , DW60UN2B2 Product Dimensions a Overall height of product* 820 - 880 B Overall width of product c Overall depth of product (incl. panel and hose support) D Height of chassis e Depth of chassis DATUM: DOOR f Height of feet* 0 - 60...
-
Page 8: Cabinetry Dimensions
CABINETRY DIMENSIONS CLEARANCES Connections can be located in an adjacent cabinet on either side of the dishwasher*** PLAN ISOMETRIC CABINETRY DIMENSIONS CABINETRY CLEARANCES A Minimum inside height* A Minimum clearance to adjacent cupboard door B Minimum inside width B Minimum clearance to corner cupboard C Minimum overall depth** D Recommended height of adjacent cabinetry 713 - 794... -
Page 9: Left Side
PLUMBING & ELECTRICAL CONSIDERATIONS Hose and cord lengths Your services can be installed to either the left-hand or right-hand side of the product in an adjacent cabinet. Refer to 'Cabinetry preparation' for service access requirements. The drain hose should not extend more than 4m. A longer drain hose will cause reduced performance. -
Page 10: Service Access
SERVICE ACCESS We recommend locating the service holes on either side of the Dishwasher as shown. If the holes are created through wood, ensure the edges are smooth and rounded If the holes are created through metal, ensure an edge protector is fitted. REAR WALL FLOOR... - Page 11 UNPACK PRODUCT CABINETRY PREPARATION Ensure all minimum cabinetry and Cut straps, lift carton off product and service specifications have been met remove the top cap. and that all services will be accessible Dispose of packaging responsibly. after installation. Ensure cabinetry floor is free from Remove the install kit, any internal bumps and obstructions that could packaging, all rubber bands and all tape.
- Page 12 PUSH INTO CAVITY SECURE TO CAVITY Using a flat bladed screwdriver, turn to raise the leveling feet. Level the rear, outside legs first followed by the front Loosely fit 2 x side fixing screws. legs. Do not adjust the rear middle leg yet.
- Page 13 INSTALL SOUND SEAL INSTALL TOE KICK PRE-FINISHED TOE KICK Align both sound seal sheets to the base of the dishwasher. If required, trim Measure the distance between the floor excess felt. and the base of the door. Refer to the table and mark out the cut location.
-
Page 14: Install Toe Kick
INSTALL TOE KICK CONTINUOUS TOE KICK PANEL CUSTOM TOE KICK PANEL Mark the pilot hole locations for each bracket. Measure the centre of the panel and mark 237mm to each side. Align toe kick to product and ensure all To determine the height of the door swing clearances have been met. - Page 15 PLUMBING & ELECTRICAL CONNECTION Ø38MM STANDPIPE INSTALLATION SINK TRAP/WASTE TEE INSTALLATION Install the drain hose support to the Install the drain hose support to the back wall, as close to the underside of back wall, as close to the underside of the countertop as possible.
-
Page 16: Installer Checklist
INSTALLER CHECKLIST TEST OPERATION TO BE COMPLETED BY THE INSTALLER Installation … Check all parts are installed correctly and are secure. Turn power and water supply on and open the dishwasher. … Ensure all packaging, tape and rubberbands have been removed. …... - Page 20 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2023. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
