 SETTING UP LAN COMMUNICATION

The projector is shipped with a set of default settings, these are as follows:
Description
IP address
Subnet mask
Default gateway
TCP port
UDP port
Username
Password
Before you connect the projector to your LAN make sure that the IP address 192.168.1.90
is not already in use. If you need to change it, you have to make sure that the computer you
use is on the same subnet. This means that the computer need to have an IP address in
the range from 192.168.1.1 to 192.168.1.254.
.1

Setting the IP address

If you need to change the computers IP address, follow these steps:
1. Right click on "Network Neighborhood" / "My Network Places" on your computer, and
then select "Properties".
Value
192.168.1.90
255.255.255.0
192.168.1.1
1025
1225
admin
admin
2. Doubleclick on the network connection that represents your LAN, select "properties",
then doubleclick "Internet Protocol (TCP/IP).
3. This will take you to a screen where you can set the computers IP address:
Set the IP address and click OK on this and the previous dialog when you're done.
5
