Projectiondesign F1+ Protocol Manual page 14

ASCII Function
CMNA* Color Management Not Corrected (native)
▼
CMCU* Color Management Custom
CCRG
CTRD
CTGR
CTBL
CCXY
CMXV
CMYV
▼
CMTE* Color Management Temperature
CTMP
* Applies to uncalibrated units only
CRED Red Gain
BRED Red Offset
CGRE Green Gain
BGRE Green Offset
CBLU Blue Gain
BBLU Blue Offset
VPOS Vertical position
HPOS Horizontal position
VHUE Hue video
SHRP Sharpness
FREQ Frequency
PHSE Phase
VKEY Vertical keystone
HKEY Horizontal keystone
DESK Select Orientation Desktop Front
CEIL Select Orientation Ceiling Front
RDES Select Orientation Desktop Rear
RCEI Select Orientation Rear Ceiling
ORIE [0-3] See section 10 Select orientation abs value
BKBK Select Splash/Background Black/Black
LGLG Select Splash/Background Logo/Logo
LGBL Select Splash/Background Blue Logo/Blue
14
▼
Select Custom RGB
Custom Red
Custom Green
Custom Blue
▼ Select Custom Coordinates
X coordinate
Y coordinate
Color Temperature
Operations supported Legal modifiers
Get, Set A, ?
Get, Set A, ?
Get, Set A, ?
Get, Set A, R, ?, ?M, ?N
Get, Set A, R, ?, ?M, ?N
Get, Set A, R, ?, ?M, ?N
Get, Set A, ?
Get, Set A, R, ?, ?M, ?N
Get, Set A, R, ?, ?M, ?N
Get, Set A, ?
Get, Set A, R, ?, ?M, ?N
A, R, ?, ?M, ?N
A, R, ?, ?M, ?N
A, R, ?, ?M, ?N
A, R, ?, ?M, ?N
A, R, ?, ?M, ?N
A, R, ?, ?M, ?N
Get, Set A, R, ?, ?M, ?N
Get, Set A, R, ?, ?M, ?N
Get, Set A, R, ?, ?M, ?N
Get, Set A, R, ?, ?M, ?N
Get, Set A, R, ?, ?M, ?N
Get, Set A, R, ?, ?M, ?N
Get, Set A, R, ?, ?M, ?N
Get, Set A, R, ?, ?M, ?N
Get, Set A, ?
Get, Set A, ?
Get, Set A, ?
Get, Set A, ?
Get, Set A, R, ?, ?M, ?N
Get, Set A, ?
Get, Set A, ?
Get, Set A, ?
