APPENDIX A, BINARY OPERATION PACKET TYPE

A.1

Operation Packet Type

The Operation packet is used by the host system to execute operations (such as Bright-
ness, Contrast, Image Position, etc) in the target system. The Operation packet payload
size is 11 bytes.
The source code definition of the Operation packet data structure is:
typedef struct
{
eOPERATION_TYPE eOpType;
WORD eOperation;
WORD bIsAvail;
DWORD dwTarget;
DWORD dwValue;
LONG lwMin;
LONG lwMax;
LONG lwInc;
} OPERATION_MESSAGE;
This lets the user directly perform logical operations such as "Set Contrast = 80".
If the user performs an OPERATION_GET, the returned packet will include operation
and target along with the value.
// Operation type.
// Operation
// Operation validation.
// Operation target.
// Operation value.
// Lower limit.
// Upper limit.
// Increment.
A.

Operation Packet Payload Format

Field
Byte Field Name
Value
1-7 1-7
8 Operation Type
9-10 Operation Number
11 Operation Validation
12
13-16
17-18 Operation Value
19-20 Operation Value
21-24 Lower Limit
25-28 Upper Limit
29-32 Increment
Table 2: Packet Payload format
Description
Header, which consists of:
Byte 1-5: 0xBE 0xEF 0x03 0x19 0x00
Byte 6-7: CRC (not in use)
(see appendix C for an example of a
complete packet)
1 OPERATION_SET
2 OPERATION_GET
3 OPERATION_INCREMENT
4 OPERATION_DECREMENT
5 OPERATION_EXECUTE
7 OPERATION_DESCRIPTOR
Operation ID.
Operation is valid, return only.
n/a (not available for use).
n/a (not available for use).
Value to SET or the value of the GET on
a return.
Not in use
Lower Parameter limit.
Upper Parameter limit
Increment steps within limits.
