APPENDIX E, TRUTH TABLES

E.1 OSD Warning On:
When enabling OSD Warnings after beeing disabled, OSD is still disabled and must be
set to ON to become visible again.
E. Lamp Ignition states:
00 – Lamp does not ignite
01 – Lamp is warming up
02 – Lamp ignited
03 – Lamp is off
04 – Lamp is cooling down
E.3 Thermal Monitor states:
00 – OK
01 – Temperature too high
02 – Temperature warning
03 – Fan 70 x 70 stopped
04 – Fan 60 x 60 stopped
05 – Fan Blower stopped
E.4 Lamp On States
00 – Lamp is not lit
01 – Lamp is lit
