Projectiondesign cineo Supplementary Manual page 31

Figure 3 shows a 33-bytes address message and the corresponding 19 bytes short mes-
sage. Address in this example is 5 (0x05, byte 3). Payload_lo (byte 5) is set to 0x0B.
Byte 1 2 3
Select vga1 0xBA 0xDA 0x05
Byte 1 2 3
Select vga1 0xBA 0xDA 0x05
Figure 3: Long (33 bytes) address message and corresponding short (19 bytes) address message.
Note that the CRC is not in use and can be left 0x00
33 bytes address message
4 5 6 7 8
0x03 0x19 0x00 0x00 0x00
19 bytes address message
4 5 6 7 8
0x03 0x0B 0x00 0x00 0x00
9 10 11 12-13 14
0x01 0x01 0x44 0x00 0x00
9 10 11 12-13 14
0x01 0x01 0x44 0x00 0x00
15-17 18 19 20-33
0x00 0x00 0x00 0x00
15-17 18 19
0x00 0x00 0x00
