Mnenomic Table
IABS [0..2, 4..6] 0 0 – BNC
1 1 – VGA
2 2 – DVI
3 3 – YPbPr interlace
4 4 – S-Video
5 5 – Composite Video
6 6 – YPbPr progressive
SABS[0..3, 9-10, 13-14] 0 – 1to1 (only VGA)
1 – fill all (only VGA)
2 – fill aspect ratio
3 – fill 16:9
9 – letterbox to 16:9
10 – letterbox subtitle to 16:9
13 – zoom (only Video)
14 – anamorphic
16 - cinemascope
ORIE[0..3] 0 – Desktop front
1 – Ceiling rear
2 – Desktop rear
3 – Ceiling front
THRM [0..2, 7..11] 1 – Temperature too high (shutdown)
2 – Temperature warning (close to shutdown)
7 – Fan lamp 1 stopped
8 – Fan lamp 2 stopped
9 – Fan ballast 1 stopped
10 – Fan ballast 2 stopped
11 – Fan main stopped
LENS [1..7] 1 – ultra wide
2 – wide
3 – super tele zoom
4 – tele zoom
5 – wide zoom
6 – standard
7 – no lens mounted
18
Comments
Ignore other values returned, no source is connected.
Use of other numbers may result in poor picture quality, and is
not recommended.
0 – Normal, everything OK
