Summary of Contents for Sencor K5
- Page 1 SENCOR SCOOTER K5 User Manual Electric scooter Uživatelská příručka Elektrická koloběžka Používateľská príručka Elektrická kolobežka Felhasználói kézikönyv Elektromos roller Podręcznik użytkownika Hulajnoga elektryczna...
-
Page 3: Table Of Contents
Table of Contents 1. Supply Content ......................4 2. Sencor Scooter K5 Description .................4 3. Before First Use ......................5 4. Assembling the Sencor Scooter K5 ................5 5. Charging ........................6 6. Driving ........................7 7. Safety Instructions ....................8 8. Maintenance and Adjustment ...................9 9. -
Page 4: Supply Content
Package Contents / Sencor Scooter K5 Description 1. Supply Content Sencor Scooter K5 Charging Adapter Allen key Handlebar Allen bolt Top handlebar clamp Bar clamp User manual 2. Sencor Scooter K5 Description 9 10 4 EN Revision 01/2023 Copyright © 2023, Fast ČR, a. s. -
Page 5: Before First Use
Before the first start / Setting up the Sencor Scooter K5 Handlebar – height adjustable Handlebar height adjustment locking clamp Clamp for attaching handlebar bar to front fork Front wheel with LED effect Electric motor starter Rear mudguard/brake LED effects... -
Page 6: Charging
The charging is performed with the supplied charging adapter. First of all, uncover the rubber cap of the charging connector in the Sencor Scooter K5 and connect the charging adapter “Charging connector No. 9 in the main illustration”. Then connect the charging adapter to your power outlet. -
Page 7: Driving
Stopping is essential for safe driving of the Sencor Scooter K5. Press the “rear mudguard No. 6 in the main illustration” with your foot so that the rear wheel slows down or stops. -
Page 8: Safety Instructions
During each ride, use helmet and protectors to prevent injury in case of falling. Always have adult supervision nearby! This electric Sencor Scooter K5 is designed for entertainment and recreational use. This is not a means of transport. Observe the safety of everyone in both private and public areas, follow the instructions below as well as local traffic regulations. -
Page 9: Maintenance And Adjustment
Before the first ride, it is necessary to perform a complete visual inspection of the individual parts of the Sencor Scooter K5 electric scooter. Contact a specialised provider (e.g. a bike service) for proper adjustment. Adjustment and assembly can- not be made under warranty or post-warranty service at the manufacturer or dis- tributor. -
Page 10: Waterproof Ipx4
10 litres per minute and at a pressure of 80-100kN/m for 5 minutes. Therefore, follow these points to avoid damage to the Sencor Scooter K5 electric scooter: Never use a high-pressure water wash to clean the electric scooter. -
Page 11: Technical Specifications
Technical Specifications 10. Technical Specifications Drive Engine power 60 W Maximum speed up to 8km/h Travel range up to 8km Maximum pitch angle up to 5° Wheels 5" front and 3.5" rear rubber tyres Foot brake on the rear wheel Technical Specifications Maximum load 60 Kg Dimensions: 83(68) x 63 x 39 cm... - Page 12 Charging adapter Value and precision Unit Manufacturer’s name or Shenzhen Fuyuandian trade mark, commercial Power Co., Ltd 8F, registration number and A9 Building, Tianrui address Industrial Park, Fuyong Town, Baoan District, Shenzhen, 518103 Guangdong, P.R. China Model identifier FY0182520700E Input voltage 100-240 Input AC frequency AC 50/60...
- Page 13 Změny v textu, designu a technických specifikací se mohou měnit bez předchozího úřadů nebo od svého prodejce. FAST CR, a.s. hereby declares that the radio device type Sencor Scooter K5 upozornění a vyhrazujeme si právo na jejich změnu. conforms to the 2014/53/EU directive.
- Page 14 Manufacturer: FAST ČR, a.s., U Sanitasu 1621, Říčany 251 01, Czech Republic Visit www.sencor.com for detailed information about authorized service centers. The original version of the instructions is in the Czech language, other language versions are made by the appropriate translation.
