TPG Archer VR600 Configuration Manual

Modem Configuration Guide

VR1600v (Fibre To The Building (FTTB))

Windows 7

IMPORTANT MESSAGE

Your modem has already been pre-configured, you do not need to follow each step of the set-up guide but should retain

this document in case you need to manually configure your equipment.

To configure your device with your wireless password including changing your wireless password, please

proceed to step 4.

Contents

1. Physical Connection

2. Network Configuration

3. Configuring Internet

4. Configuring Wireless

5. Change of Password

1. PHYSICAL CONNECTION

Have your modem powered on and connected directly to your PC via Ethernet Cable before you begin, as these

instructions are based on wired Ethernet connection

For further information, please see wiring diagram and instructions for your FTTB connection below.

•

TPG Fibre To The Building

2. NETWORK CONFIGURATION

PPPoE connection does not require you to have an IP address or DNS settings manually encoded on your network card.

PPPoE connection uses authentication to establish the Internet connection and once connected your modem will be

assigned an IP and DNS settings from TPG.

To begin, your PC needs to receive a private IP address from the modem. Most modems have DHCP enabled by default

that will take care of this.

VR1600v

Table of Contents

Do you have a question about the Archer VR600 and is the answer not in the manual?

Page 1 PPPoE connection uses authentication to establish the Internet connection and once connected your modem will be assigned an IP and DNS settings from TPG. To begin, your PC needs to receive a private IP address from the modem. Most modems have DHCP enabled by default...
Page 2 Modem Configuration Guide VR1600v To ensure your Network Card is ready for this, please follow the following steps: A. Click Start -> Control Panel -> Network and Internet -> Network and Sharing Center -> Change adapter settings B. Right click on Local Area Connection and select Properties C.
Page 3 Modem Configuration Guide VR1600v 3. CONFIGURING MODEM A. Open your browser and in the address bar type http://192.168.1.1 and press Enter B. Enter admin for both the username and password and click Login. If you have changed the login credentials, please enter the current username and password for your modem interface.
Page 4 Modem Configuration Guide VR1600v F. Enter your TPG Username and Password. Click Save G. Click the Basic tab. H. On the menu on the left side of the page, click Wireless. I. You can change your Wi-Fi details or keep the default settings.
Page 5 PLEASE NOTE: Each time your modem is powered on, it will initialize this automated authentication process after which your modem will receive a public dynamic IP address (fixed or dynamic depending on your plan) and DNS settings from TPG. tpg.com.au/support...
