RB87
User's manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the RB87 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Retevis RB87

Summary of Contents for Retevis RB87

  • Page 1 RB87 User’s manual...

  • Page 2: Table Of Contents

    Battery..............BASIC OPERATION..............Technical Parameters............... Frequency table................ Warnings.................. Warranty card................For downloading further resources: Brochures, Software/Firmware, Manual etc, Pls contact your direct reseller first OR go to website retevis.com and check “support” in the each product link to download it.

  • Page 3: Feature

    Feature GMRS Scanning Channel Lockout Busy Channel Lockout Low Battery Warning Special Signaling CTCSS/DCS Be Familiar With The Machine Antenna Power/Volume Switch Indicator Light Up Key Speaker Down Key Microphone Charging the Battery 1.The battery is not charged in the factory,please charge the battery under the environmental temperature 5—40℃ before using.

  • Page 4: Basic Operation

    BASIC OPERATION Channel Selection Press【UP】【DOWN】keys to adjust the channels. PTT Key Press this button whenever you wish to talk with the user of the other radio. Monitoring Press 【UP】 key for two seconds to enter into the monitor mode,release it to exit. Channel Lockout Press both【UP】【DOWN】keys to lock;...

  • Page 5: Technical Parameters

    Technical Parameters SPECIFICATIONS Frequency Range GMRS Supply Power DC7.4V Memory Channel Antenna Configuration External Antenna Work Mode Co/Differ-frequency Simplex Communication Ground Method Cathode TRANSMITTER Output Power 5W/0.5W Modulation Mode FM(F3E） Max.Frequency Deviation(Wide/Narrow) ≤5KHz/≤2.5KHz Sparious Radiation ≤7.5μW Preemphasis Character Per Octave 6dB Emission Current ≤1.5A RECEIVER...

  • Page 6: Frequency Table

    Frequency table GMRS CTC/DCS Power 462.5625 462.5625 12.5KHz 462.5875 462.5875 12.5KHz 118.8 462.6125 462.6125 12.5KHz 127.3 462.6375 462.6375 12.5KHz 131.8 462.6625 462.6625 12.5KHz 136.5 462.6875 462.6875 12.5KHz 141.3 462.7125 462.7125 12.5KHz 146.2 467.5625 467.5625 0.5W 12.5KHz D243N 467.5875 467.5875 0.5W 12.5KHz D032N 467.6125...
  • Page 7 Your Retevis two-way radio has a RF Exposure Product Label. Also, your Retevis user manual, or separate safety booklet includes information and operating instructions required to control your RF exposure and to satisfy compliance requirements.
  • Page 8 —Consult the dealer or an experienced radio/TV technician for help. CE Requirements: •(Simple EU declaration of conformity) Shenzhen Retevis Technology Co., Ltd. declares that the radio equipment type is in compliance with the essential requirements and other relevant provisions of RED Directive 2014/53/EU and the ROHS Directive 2011/65/EU and the WEEE Directive 2012/19/EU;...

  • Page 9: Warnings

    •When operating in front of the face, worn on the body, always place the radio in a Retevis approved clip, holder, holster, case, or body harness for this product. Using approved body-worn accessories is important because the use of Non-Retevis approved accessories may result in exposure levels, which exceed the IEEE/ICNIRP RF exposure limits.

  • Page 10: Warranty Card

    •The adapter shall be installed near the equipment and shall be easily accessible •This radio meets the RF exposure guidelines when used with the Retevis accessories supplied or designated for the product. Use of other accessories may not ensure compliance with the RF WARNING exposure guidelines and may violate regulations.
  • Page 11 1.This guarantee card should be kept by the user, no replacement if lost. 2.Most new products carry a two-year manufacturer’s warranty from the date of purchase. Further details, pls read http://www.retevis.com/after-sale/ 3.The user can get warranty and after-sales service as below: Contact the seller where you buy.
  • Page 12 Shenzhen Retevis Technology Co.,Ltd. Add: 7/F, 13-C, Zhonghaixin Science&Technology Park, No.12 Ganli 6th Road, Jihua Street, Longgang District, Shenzhen, China Web: www.retevis.com E-mail: kam@retevis.com Facebook: facebook.com/retevis...
