Version 4.01.001
July 29, 1999
Overview
PictureTel LiveManager 4.01 is a member of PictureTel's family of collaborative computing conferencing
products designed specifically for the LAN. LiveManager 4.01 is a H.323 Version 2 compliant gatekeeper
application that manages PictureTel LiveLAN and H.323 calls and provides additional functionality to the
LiveLAN, LiveGateway, PictureTel 240 and PictureTel 330 products.
LiveManager 4.01 is compatible with LiveLAN 3.1, Intel TeamStation, Intel ProShare, PictureTel 550,
LiveGateway 3.1, PictureTel 330 v2.0, PictureTel 240 v1.0 and LiveManager 3.1.
LiveManager 4.01 is an enhancement of LiveManager 3.1 providing new features and improved interoperability
with PictureTel's and third party vendors' H.323 products.
LiveManager 4.01 includes the following features:
Support for Windows NT 4.0 TCP/IP systems
Bandwidth Management
Gateway Sharing
Extended Name Resolution
Microsoft Internet Locator Server (ILS) registration using LDAP
Extensive Monitoring and Logging capabilities
Year 2000 Compliance
H.323 Version 2 Compliance
Gatekeeper Routed Call Signaling
Web Browser Based User Interface
Additional information about this product, including how to install and use it, is available in the Installation and
Administrator's Guide. The guide is located on the distribution CD in the \doc directory. The guide is provided
in HTML and Word 97 formats.
These Release Notes are organized into the following sections:
System and Network Requirements
Installing LiveManager
Deinstalling LiveManager
New Features
PictureTel 140 LiveManager
Gatekeeper Software
Release Notes
NEW
NEW
NEW
Advertisement
Table of Contents
Related Manuals for Polycom PictureTel 140
Summary of Contents for Polycom PictureTel 140
-
Page 1: Release Notes
PictureTel 140 LiveManager Gatekeeper Software Release Notes Version 4.01.001 July 29, 1999 Overview PictureTel LiveManager 4.01 is a member of PictureTel’s family of collaborative computing conferencing products designed specifically for the LAN. LiveManager 4.01 is a H.323 Version 2 compliant gatekeeper application that manages PictureTel LiveLAN and H.323 calls and provides additional functionality to the... -
Page 2: System And Network Requirements
Restrictions and Recommendations Helpful Hints Identified Problems On-line Documentation Software Components System and Network Requirements You can install LiveManager 4.01 on the following minimum system configurations: Gatekeeper Service: Pentium 200 MHz Windows NT 4.0 Server or Workstation with Service Pack 3 and TCP/IP 64 MB memory Web UI Service: Pentium 150 MHz... - Page 3 User Groups are created on each server. See the PictureTel 140 LiveManager Installation and Administration Guide for more information on creating User Groups.
-
Page 4: New Features
New Features H.323 Version 2 Compliance Gatekeeper Routed Call Signaling Web Browser based User Interface I. H.323 Version 2 Compliance H.323 Version 2 compliance allows Version 2 endpoints and gatekeepers to interoperate more reliably and with greater flexibility. LiveManager 4.01 is compliant with the H.323 version 2 standard. -
Page 5: Restrictions And Recommendations
This will take you to the PictureTel Web Center, which is the starting point for Web access to multiple PictureTel products. Click on the " screen to go to the PictureTel 140 LiveManager home page. Example: You installed the LiveManager Web UI service on host N112H200. -
Page 6: Helpful Hints
2 gateway features. LiveManager 4.01 provides mapping of a "User Prefix" to a gateway prefix supplied by a registered gateway or to the "Default Prefix" which you specify. See the PictureTel 140 LiveManager Installation and Administrator’s Guide for further information. - Page 7 NT access violation. You must have a local account with administrative privileges on the server you are attempting to access. Go to the LiveManager server and create a local account with administrative privileges. See the PictureTel 140 LiveManager Installation and Administrator’s Guide for more information on how to deal with this situation using User Groups.
-
Page 8: Online Documentation
7. The on-line help does not work correctly in the Netscape browser. Online Documentation This release of LiveManager contains the PictureTel 140 LiveManager Installation and Administrator’s Guide, which is located on the distribution CD in the supplied in HTML and Microsoft Word 97 formats. If you do not have Microsoft Word software...
