Polycom VSX 7000s

Specifications

H.323, SIP and H.320 compliant • Up to 4CIF/4SIF on NTSC/PAL displays
for People or Content
VSX 7000s Bundled Solutions
• VSX 7000s VTX: VSX 7000s with Audio Standards & Protocols
SoundStation VTX 1000 instead of • Polycom StereoSurround
microphone array • 14 kHz bandwidth with Polycom Siren 14
• VSX 7400s Presenter: VSX 7000s, (G.722.1 Annex C)
Visual Concert VSX, People+Content IP • 7 kHz bandwidth with G.722, G.722.1
• VSX 7400s Presenter VTX: VSX 7400s • 3.4 kHz bandwidth with G.711, G.728,
with SoundStation VTX 1000 instead of G.729A
microphone array
Audio Features
• VSX 7800s Presenter MP: VSX 7000s,
• Audio add-in over SoundStation VTX
Visual Concert VSX, People+Content IP,
1000 conference phone
4-way MPPlus
• Audio add-in over ISDN
• VSX 7800s Presenter MP VTX: VSX
• Full-duplex digital audio
7800s and SoundStation VTX 1000
• Instant Adaptation Echo Cancellation
instead of microphone array
• Automatic Gain Control (AGC) – Voice
Bandwidth activated
• Maximum IP Data Rate: 2 Mbps • Automatic Noise Suppression (ANS)
• Maximum ISDN/V.35 Data Rate: 2 Mbps • Audio Mixer (Mic array, VCR, line-in)
• Built-in tonal speaker test
Video Standards & Protocols
• Real-time audio level meter
• H.261
• Microphone and VCR input audio mixing
• H.263+ Annexes: F, I, J, L, N, T
• Ability to talk over VCR audio
• H.263++ Annexes: W
• H.264 Audio Inputs: 3 Connectors
• ITU 50/60-fps full screen – Pro-Motion • 1 x Conference Link
Frame Rates (Point-to-Point)
• Intelligently selects frame rate for best
performance video
• 1 x RCA input for stereo or mono input
• 30 fps from 56 kbps up to 2 Mbps
from VCR
• 60 fields per second from 512 Kbps to
• 1 x RCA input for stereo or mono input
2 Mbps
from external mixer
Video Inputs: Main Camera + 2 Connectors
Audio Outputs: 2 Connectors
• Integrated main camera
• 2 x RCA/Phono, Line Level output for
• 1 x S-Video; 4-pin mini DIN (document
VCR record
camera or second camera)
• 1 x S-Video; 4-pin mini DIN (VCR) Polycom VSX Microphone Array
• Dedicated connections for VCR/DVD-R • 360˚ voice pick up
playing and recording • Three cardioid elements per microphone
• Flotation feet reduce transmission of
RS-232 Data Port: 1 x 8-pin mini DIN
tabletop noise
• Control port for custom integration with
• Integrated mute button
®
remote devices such as Crestron and
• Optional Polycom Ceiling Microphone
®
AMX control systems
Array is available
• Connectivity for closed captioning
teletype device or PTZ control for Integrated Speaker and Subwoofer
auxiliary PowerCam™ • Frequency response: 80 Hz to 22 kHz
• Communication port for transmission • Crossover frequency to subwoofer: 216 Hz
of serial data (i.e. medical devices) over • Total Output Power: 20 Watts (RMS)
ISDN and IP calls • Customize audio for user environment
• Master volume control
Video Outputs: 4 Connectors
• Midrange and subwoofer speakers
• 1 x S-Video; 4-pin mini DIN
On/Off
(Main monitor)
• Subwoofer adjustable level
• 1 x S-Video (Second monitor)
• User-tuned treble and bass controls
• 1 X VGA HD-15
(main or second monitor display) Other ITU-Supported Standards
• 1 x S-video (VCR) • H.221 communications
• H.224/H.281 far-end camera control
Video Formats
• H.323 Annex Q far-end camera control
• NTSC/PAL
• H.225, H.245, H.241, H.331
• XGA, SVGA, VGA
• H.239 People+Content
Integrated Main Camera
• H.231 in multipoint calls
• Ultra-quiet, ultra-fast action
• H.243 MCU password
pan/tilt/zoom (PTZ)
• H.233, H.234, H.235V3 encryption
• 65˚ field of view
standards
• Tilt Range: +/- 25˚ (Up/Down)
• H.460 NAT/firewall traversal
• Pan Range: +/- 100˚ (Left/Right)
• Bonding, Mode 1
• Total Field of View: 265˚
• 12x Zoom; f-4.2 to 42mm
• Register and authenticate with:
• F=1.85 to 2.9 mm
• Auto focus
• Automatic white balance
• Camera presets – local and far-end
• FECC
(up to 99)
• H.261, H.263, H.264
• Standards-based, far-end camera control
• G.711, G.722, G.722.1, G.728, G.729A,
(FECC)
People Video Resolution
• Microsoft LCS contact list support
• Pro-Motion interlaced video (60/50
• Microsoft LCS presence support
fields full-screen video for NTSC/PAL)
• Interoperable with Microsoft Office
• 4SIF (704 x 480), 4CIF (704 x 576)
• SIF (352 x 240), CIF (352 x 288)
Network Interfaces Supported
• QSIF (175 x 120), QCIF (176 x 144)
• Single 10/100 Ethernet port
• Choice of 4:3 or 16:9 display aspect ratios
(10 Mbps/100Mbps/Auto)
Content Video Resolution
• Optional ISDN QBRI (Basic Rate
• XGA (1024 x 768), SVGA (800 x 600),
Interface) Module
VGA (640 x 480) for single monitor
• Optional ISDN PRI (Primary Rate
VGA or when using VGA as 2nd monitor
Interface) Module T1/E1
for Content
• Optional Serial Module with
Polycom Headquarters:
www.polycom.com
Polycom EMEA:
Polycom Asia Pacific:
appropriate cables
• Optional wireless LAN support via
customer provided wireless bridge
Network Features
• Integration with Cisco Systems
CallManager Version 4.0
• Down speeding over IP and ISDN
• Audio & Video Error Concealment over IP,
ISDN and mixed calls
• IP address conflict warning
• Maximum call length digital timer
• Auto SPID detection and line number
configuration
• MGC Click&View™ for individual
screen layouts
• Polycom OneDial™ intelligent call
management attempts call on preferred
network (IP or ISDN) and automatically
rolls over to secondary network if needed
• Polycom PathNavigator support for
easy call placement and network cost
optimization
• TCP/IP, UDP/IP, RTP, DNS, WINS, DHCP,
ARP, HTTP, FTP, Telnet
• Chair control through API command or
Integrated Web Interface
- Supports up to (3) microphones
• Software Upgradeable Inverse
- Supports SoundStation VTX 1000
Multiplexer (IMUX)
conference phone
Internal Multipoint Features (Optional)
• Mixed protocol dialing connects a total
of four endpoints (IP/ISDN/Serial)
• StereoSurround and Siren 14 audio
• Dual monitor emulation
• Dial-in/Dial-out Calling (IP/ISDN/Serial)
• Password protection for incoming calls
• Supports IP telephones
• Automatic IP/ISDN down speeding
• Supports People+Content™ from any
endpoint
• Voice Activated Switching – view
current speaker
• Continuous Presence – see all locations
• Automatic Presentation – switch
between presenter and continuous
presence mode
• Audio add-in over ISDN
• Cascading for up to 10 conference
participants
Conference on Demand
• Initiates unscheduled MGC calls
from the endpoint
• Utilizes The Polycom Office™
(Polycom PathNavigator and MGC)
• Auto selects either the internal or
external bridge
• Dials all participants simultaneously
Security
• COMSEC tested by Titan Systems,
Information Security Systems Division,
and independently validated to operate
with approved government encryption
technologies
• KG-194/KIV-7 encryptor support with on
screen and address book dialing
• FIPS 140-2 (Pre-validation List)
- Secure web (HTTPS)
- Secure Telnet, FTP
SIP Support (Sessions Initiation Protocol)
- Security mode
• Account validation number entry
- Microsoft LCS
• SNMP trap notification of all failed login
- Nortel MCS
attempts from HTTP, FTP or Telnet
- Standards-based SIP servers
• Secure password authentication
• Administrator password – in-room and
remote access
• Dial-in meeting password
Siren 14 (G.722.1 Annex C)
• Ability to disable remote interfaces
(FTP, Telnet, HTTP, SNMP)
• Ability to disable mixed protocol
multipoint calls
Communicator
• Auto-Answer (On/Off)
• Allow access to user settings (On/Off)
Embedded Encryption
• Advanced Encryption Standard (AES)
• FIPS 197 validated by National Institute
of Standards & Technology (NIST)
certified agency
• 128-bit key length
• AES software encryption on ISDN,
©2006 Polycom, Inc. All rights reserved.
Polycom, the Polycom logo, SoundStation VTX 1000 and Vortex are registered trademarks and VSX, PathNavigator, Global Management System, Siren, Pro-Motion, MGC, Click&View,
Polycom OneDial, People+Content, The Polycom Office, iPriority, Visual Concert, PowerCam, Polycom Conference Suite and StereoSurround are trademarks of Polycom, Inc.
All other trademarks are the property of their respective owners. Information in this document is subject to change without notice.
4750 Willow Road, Pleasanton, CA 94588 (T) 1.800.POLYCOM (765.9266) for North America only.
For North America, Latin America and Caribbean (T) +1.925.924.6000, (F) +1.925.924.6100
270 Bath Road, Slough, Berkshire SL1 4DX, (T) +44 (0)1753 723000, (F) +44 (0)1753 723010
Polycom Hong Kong Ltd., Rm 1101 MassMutual Tower, 38 Gloucester Road, Wanchai, Hong Kong, (T) +852.2861.3113, (F)+852.2866.8028
Part No. 3726-17351-001 Rev. 03/06
IP and Serial/V.35 up to full bandwidth
• Standards-based H.235V3 (IP)
• Standards-based H.233/H.234
(ISDN/Serial)
• Automatic key generation and exchange
®
• Supported in People+Content™
• Supported in Point-to-Point IP & ISDN &
mixed multipoint calls
User Interface
• User-friendly graphical interface
• Customizable home screen and
color themes
• Kiosk mode with scrolling marquee
• User-selectable camera icons and
ring tones
• Speed Dial List on home page
• Persistent Preview (Far-site PIP) on
all screens
• Picture In Picture (PIP) (On/Off,
Moveable)
• Dual Monitor Emulation
• Calendar and Conference scheduling
• Alert Signal on home page
• Do Not Disturb (On/Off)
• Closed captioning support
Directory Services
• 4,000 number global directory
• 1,000+ number local directory for single
or multipoint entries
• Speed dial list displaying video buddy list
• Live address book with Polycom Global
Directory Services automatically and
quickly updates directory with address
changes or new endpoints
• Polycom Global Directory Services
integrates with Active Directory/LDAP
• Directory Server backup in the event
Polycom Global Directory is not
accessible
• Automatic ISDN localization of calls
System Management
• Baseline mode setting for legacy system
interoperability
• SNMP for enterprise management
• Diagnostics and software upgrades via
PC, LAN
• Integrated VSX Web management tool
• Web Director: Remote administrator
video monitoring and control from VSX
Web (enabled/disabled from endpoint for
security)
• Out-of-box setup from VSX Web
• Place a call from VSX Web
• Language independence between set-top
interface and VSX Web
• System configuration from VSX Web
• Recent Calls Log – last 99 incoming
and outgoing calls
• Call Detail Record (CDR) - Reports all
incoming and outgoing calls along with
call statistics
• CDR Feature On/Off
• Downloadable CDR data for processing
requires no external management system
• Account number validation at call initia-
tion integrated with Polycom Global
Management System for billing purposes
• Administrator-configurable dialing
speeds
iPriority – Quality of Service Features
• Video Error Concealment
• Audio Error Concealment
• Universal Plug and Play (UPnP)
• IP Precedence (ToS)
- Configurable video/audio/FECC
service value
• DiffServ (DSCP) (COS)
• RSVP
• Dynamic Bandwidth Allocation
• Proactive Network Monitoring
• Packet and jitter control
• Adjustable Packet Size
• NAT/firewall traversal (H.460)
• Network Address Translation
(NAT) support
• Automatic NAT discovery
• Asymmetric speed control
• Alternate Gatekeeper Support
• TCP/UDP fixed-port firewall support
• Lip synchronization
• Echo cancellation
• Echo suppression
• Auto gatekeeper discovery
• Automatic gateway dialing profiles
• Specify outbound call routing for
gateway/ISDN
Collaboration Solutions
• People and Content (PC, VCR/DVD,
Doc cam) are displayed simultaneously
• Visual Concert VSX (Audio and video
®
input from PC or Macintosh ) (Optional)
- 1 x audio input for laptop
- 1 x VGA output for projector
- 3 x 10/100 Ethernet hub
- Content Input: 1280 x 1024, 60 Hz
- Content Output: Up to 1024 x 768
• People+Content IP (Optional)
- Show content from laptop/PC over IP
network connection
- Content displayed in native resolution
®
- Supports Windows 2000 and
Windows XP
• QSX (Optional)
- Connect to Visual Concert to show
content from laptop/PC
- Content displayed in native resolution
- Up to 10 voice participants can view
content being shared
• Adjustable bandwidth for content
- 10% Content, 90% People
- 50% Content, 50% People
- 90% Content, 10% People
• Web Streaming in and out of a call, RTP
®
based, suitable with QuickTime Players
Furniture solutions
• Media Center with audio system
• Media Center
• Media Cart
• Video Cart
• Wall Mount Solution
Language Support (15 languages)
Chinese (Simplified), Chinese
(Traditional), English (American), English
(British), French, German, Hungarian,
Italian, Japanese, Korean, Norwegian,
Polish, Portuguese, Russian, Spanish
• Translated items include:
- Documentation (no Hungarian/Polish)
- User interface
- Audio dialing confirmation
- VSX web
- Remote control (no Hungarian/Polish)
Electrical
• Auto sensing power supply
• Operating voltage/power 90-260 VAC,
47-63 Hz/ 80 Watts
• Max 74 VA@115v60Hz,
87 VA@220v50Hz
• Max Heat Dissipation: 273 BTU/hour
Environmental Specifications
• Operating Temperature: 0-40° C
• Operating Humidity: 15-80%
• Non-Operating Temperature: -40-70° C
• Non-Operating Humidity (Non-con-
densing): 10-90%
Physical Characteristics
• Video Base Unit (W/H/D):
11.82"/5.83"/9.63"
300.3mm/148mm/244.5mm
• Video Base Unit Weight: 6.0 lbs/2.8 kg
• Subwoofer (W/H/D): 6.9"/10.72"/8.67"
175.2mm/272.4mm/220mm
• Subwoofer Weight: 9.0 lbs/4.08 kg
Warranty
• One-year return to factory parts and labor
• 90-day Software Warranty
