Specifications - Polycom SoundStation 2 Specifications

Polycom SoundStation2
Architecture
• Tabletop console contains audio processing
functions and keypad. Wall module contains power and
telephone line interfaces.
• Cables consist of 21 ft (6.4 m) single-cord connection to
tabletop console and 7 ft (2.1 m) connection to RJ-11 tele-
phone jack. Optional Extended microphone modules con-
nect to console via 8 ft. (2.4 m) cables
Console
Size (L x W x H)
• 14.5 x 12.25 x 2.5 in
(36.8 x 31.1 x 6.4 cm)
Weight
• 1.75 lb. (0.8 kg)
Power
• 110V 60Hz AC / 220V 50 Hz AC (depending on
country-specific SKU)
Network interface
• Two-wire RJ-11 analog PBX or public switched
telephone network interface
Keypad
• Standard telephone keypad, on/off key, conference (Flash)
key, mute key, volume adjustment keys, menu navigation
keys and three context-dependent soft keys*
Display*
• 132x65 pixel backlit graphical LCD
User interface*
• User selectable ring tones
• Configurable soft keys for easy dialing of voice
conferencing services
• Multi-lingual support: English, German, French, Italian,
Spanish, Portuguese, Norwegian
• Password protected configuration settings for
administrators
Polycom Acoustic Clarity Full Duplex
3 Cardiod microphones
10ft Microphone Pickup range
Intelligent microphone mixing
Dynamic Noise Reduction
Volume (adjustable up to 94 dBA @ 0.5m)
User selectable ring tones
12-key telephone keypad
Mute, Volume up/down keys
Mute, Conference keys
Graphical Backlit LCD
Configurable conference Speed Dial Key
3 Context sensitive soft-keys
Multi-lingual User Interface
CallerID
25 Entry Phone Book
RCA Auxiliary Audio Jack
Applications Port
EX microphone jacks
Polycom Headquarters:
www.polycom.com
Polycom EMEA:
Polycom Asia Pacific:

Specifications

Caller ID and phone book*
• Support for multiple Caller ID standards**:
- Bellcore Type 1 (requires a telephone company
subscription for activation)
- ETSI
- DTMF
- British Telecom
• Phone book/speed dial list – up to 25 entries*
Keypad
• 12-key telephone keypad
• On-hook/off-hook, conference, mute, volume up/down
keys, menu, navigation keys*
• 3 context sensitive soft keys* including redial, hold, pro-
grammable conference key
Console loudspeaker
• Frequency response: 300 to 3300 Hz
• Volume: adjustable to 94 dBA SPL (peak) volume
at 0.5 meters
Console microphones
• 3 cardioid microphones 300 to 3500 Hz
Audio
• Polycom Acoustic Clarity full duplex – IEEE 1329
Type 1
• Up to 10 ft. microphone pickup range
• Gated microphones with intelligent microphone mixing
• Dynamic Noise Reduction
Interfaces
• 2 EX microphone connections*
• Applications Port* for connection to other communication
devices such as mobile phones† and computers
• RCA Auxiliary audio jack
Accessories
• 2 cardioid extension microphones 300 - 3500 Hz
(for EX models only)
Regulatory Compliance
• NA Cl/C-UL
• FCC Part 68
• FCC Part 15 Class B
SoundStation2 non-expandable SoundStation2 non-expandable, w/ display
I
I
I
I
I
I
I
I
I
I
©2005 Polycom, Inc. All rights reserved.
SoundStation, and SoundStation Premier are registered trademarks and, SoundStation2 and the industrial design of SoundStation are trademarks of Polycom, Inc. in the U.S. and
various countries. All other trademarks are the property of their respective companies. Specifications are subject to change without notice.
4750 Willow Road, Pleasanton, CA 94588 (T) 1.800.POLYCOM (765.9266) for North America only.
For North America, Latin America and Caribbean (T) +1.925.924.6000, (F) +1.925.924.6100
270 Bath Road, Slough, Berkshire SL1 4DX, (T) +44 (0)1753 723000, (F) +44 (0)1753 723010
Polycom Hong Kong Ltd., Rm 1101 MassMutual Tower, 38 Gloucester Road, Wanchai, Hong Kong, (T) +852.2861.3113, (F)+852.2866.8028
Part No. 3726-16760-001 Rev. 8/05
• Canadian ICES-003
• CE Mark (R & TTE Directive)
• VCCI Class B (Japan)
Environmental Requirements
• Operating temperature: 40˚ - 104˚F (5˚ - 40˚C)
• Relative humidity: 20% - 85% (non-condensing)
• Storage temperature: -22˚ - 131˚F (-30˚ - 55˚C)
Recommended Room Conditions
• Reverberation time: <0.5 seconds
• Noise level: <48 dBa
SoundStation2 ships with:
• Tabletop phone console
• 21 ft. (6.4 m) cord to console
• 7 ft. (2.1 m) telco cable to RJ-11 telephone jack
• User documentation (user guide CD, quick installation
guide, registration card)
Warranty
• 12 months
Part Numbers (North America):
• 2200-15100-001: SoundStation2, non expandable
• 2200-16000-001: SoundStation2, non-expandable,
with display
• 2200-16200-001: SoundStation2, expandable, with display
• 2200-16155-001: Extension microphone kit
* Not available on all models
** Due to the diversity of Caller ID standards, some features may not be avail-
able in all areas. In addition, the quality of the telephone line connection
may affect Caller ID functionality. Caller ID service may require a subscrip-
tion from a service provider in your area.
† SoundStation2 uses a cable that connects to a standard 2.5mm headset con-
nector. If your mobile phone model does not support this type of connection
you will need an adapter (not included).
Connecting the SoundStation2 to a mobile phone is analogous to connecting
a headset to a mobile phone. Not all mobile phone models recognize the
SoundStation2 as a headset. For a list of mobile phones that are known to
work with SoundStation2, please consult www.polycom.com.
