UTC Fire and Security interlogix VT7220 Installation & Operation Instructions page 2

2 BNC Cables
(Fixed Video Inputs from Cameras)
NOTE: WITHOUT PROPER FIBER CONNECTION, LED's DO NOT INDICATE
CORRECT OPERATIONAL STATUS OF THE UNIT.
VIDEO
INPUT
1
2
CAMERA ON
POWER
VT7230
2 CHANNEL DIGITAL
VIDEO TRANSMITTER
International
ifs
Fiber
Systems
Incorporated
VR7230
2 CHANNEL DIGITAL
VIDEO RECEIVER
International
ifs
Fiber
Systems
Incorporated
OPTICAL OUT
- 2
POWER
+12 VDC - 1
Simplex single mode
fiber optic cable
2 BNC Cables
(Video Output to Monitors)
1 -
VIDEO
OUTPUT
2 -
OPTICAL INPUT
- 2
POWER
+12 VDC - 1
