8.4.

Field setting list for Installation Manual

First Second
code code Setting name
0 Remote control setup
00 User permission level.
01 Room temperature compensation value.
02 Not applicable. Do not change the default value.
03 Status: space heating schedule timer mode
Method 1=1 / Method 2=0.
04 Status: space cooling schedule timer mode
Method 1=1 / Method 2=0.
1 Settings are not applicable
00 Not applicable. Do not change the default value.
01 Not applicable. Do not change the default value.
02 Not applicable. Do not change the default value.
03 Not applicable. Do not change the default value.
2 Automatic setback function
00 Status: setback operation.
01 Setback operation start time.
02 Setback operation stop time.
3 Weather dependent set point
00 Low ambient temperature (Lo_A).
01 High ambient temperature (Hi_A).
02 Set point at low ambient temperature (Lo_Ti).
03 Set point at high ambient temperature (Hi_Ti).
4 Settings are not applicable
00 Not applicable. Do not change the default value.
01 Not applicable. Do not change the default value.
02 Not applicable. Do not change the default value.
5 Automatic setback and disinfection set point
00 Not applicable. Do not change the default value.
01 Not applicable. Do not change the default value.
02 Leaving water setback temperature.
03 Room setback temperature.
04 Not applicable. Do not change the default value.
6 Option setup
01 External room thermostat installed.
02 Heater kit option.
03 Not applicable. Do not change the default value.
8 Option setup
00 User interface temperature control.
01 Not applicable. Do not change the default value.
02 Emergency operation.
03 Not applicable. Do not change the default value.
04 Status: freeze-up prevention.
9 Automatic temperature compensation
00 Leaving water temperature compensation value
(heating).
01 Leaving water thermistor auto corrective function.
02 Not applicable. Do not change the default value.
03 Leaving water temperature compensation value
(cooling).
04 Not applicable. Do not change the default value.
Installation and operation manual
22
Installer setting at variance with default value
Date Value Date
Default
Value value Range
2 2~3
0 –5~5
1 —
1 (ON) 0/1
1 (ON) 0/1
1 —
1:00 —
0 —
15:00 —
1 (ON) 0/1
23:00 0:00~23:00
5:00 0:00~23:00
–10 –20~5
15 10~20
40 25~80
25 25~80
1 —
Fri —
23:00 —
70 —
10 —
5 0~10
18 17~23
0 —
0 (OFF) 0/2
0 (OFF) 0/1
0 —
0 (OFF) 0/1
1 —
0 0/1
1 —
0 0~2
0 –2~2
1 (ON) 0/1
0 —
0 –2~2
0 —
VRV IV System indoor unit
Step Unit
1 —
0.5 °C
— —
— —
— —
— —
— —
— —
— —
— —
1:00 hour
1:00 hour
1 °C
1 °C
1 °C
1 °C
— —
— —
— —
— —
— —
1 °C
1 °C
— —
— —
— —
— —
— —
— —
— —
— —
1 —
0.2 °C
1 —
— —
0.2 °C
— —
HXY080+125A8V1B
