Specifications - Polycom VSX7000 Brochure & Specs

Polycom VSX 7000 Series
ITU H.323 and H.320 compliant • Full-duplex digital audio
• Instant Adaptation Echo Cancellation
Bandwidth
• Automatic Gain Control (AGC) – Voice
• Maximum Data Rate IP and Serial/V.35:
activated
Up to 2 Mbps
• Automatic Noise Suppression (ANS)
• Maximum Data Rate ISDN: Up to 2 Mbps
• Audio Mixer (Mic, VCR, line-in)
Video Standards & Protocols
• Built-in tonal speaker test
• H.261, Annex D
• Real-time audio level meter for local and
• H.263+ Annexes: F, I, J, L, N, T
far-end microphones
• H.263++ Annexes: W
• Microphone and VCR input audio mixing
• H.264
• Ability to talk over VCR audio
• ITU 60-fps full screen – Pro-Motion™
• Ability to turn off Echo Cancellation when
external audio equipment is used
Frame Rates (Point-to-Point)
• Intelligently selects frame rate for best
Audio Inputs: 3 Connectors
performance video
• 1 x Conference Link
• 30 fps at 56 kbps up to 2 Mbps
• 60 fields per second up to 2 Mbps
Video Inputs: Main Camera + 2
• 1 x RCA input for stereo or mono input
Connectors
from VCR
• Integrated main camera
• 1 x RCA input for stereo or mono input
• 1 x S-Video; 4-pin mini DIN (Document
from external mixer
camera, VCR or second camera)
• 1 x Composite; RCA/Phono (Document
Audio Outputs: 2 Connectors
camera, VCR or second camera)
• 2 x RCA for stereo VCR record (or stereo
for auxiliary speakers or Vortex Installed
RS-232 Data Port: 1 Connector
Voice products)
• 1 x 8-pin mini DIN
• Control port for custom integration with
Polycom Digital Tabletop Microphone
remote devices such as Crestron and
• 360˚ voice pick up, 4.8 dB less reverber-
AMX control systems
ant than omni microphone
• Connectivity for closed captioning tele-
• Three cardioid elements per microphone
type device or PTZ control for auxiliary
• Flotation feet reduce transmission of
PowerCam™
tabletop noise
• Communication port for transmission of
• Integrated mute button
serial data (i.e. medical devices) over
• Optional Polycom Ceiling Microphone
ISDN calls
Array is available
Video Outputs: 5 Connectors
Integrated Speaker and Subwoofer
• 1 x S-Video; 4-pin mini DIN
• Frequency response: 80 Hz to 22 kHz
(Main monitor)
• Crossover frequency to subwoofer: 216 Hz
• 1 x Composite; RCA/Phono (Main monitor)
• Total Output Power: 20 Watts (RMS)
• 1 x S-Video (Second monitor)
• Customize audio for user environment
• 1 x Composite; RCA/Phono
• Master volume control
(Second monitor)
• Midrange and subwoofer speakers On/Off
• 1 x VGA (Second graphics display)
• Subwoofer adjustable level
• User-tuned treble and bass controls
Video Formats
• NTSC/PAL
Other ITU-Supported Standards
• Graphics: XGA, SVGA, VGA
• H.221 communications
• H.224/H.281 far-end camera control
Integrated Main Camera
• Annex Q standard for FECC in H.323 calls
• Ultra-quiet, ultra-fast action pan/tilt/zoom
• H.225, H.245, H.241, H.331
(PTZ)
• H.239 People+Content
• 65˚ field of view
• H.231 in multipoint calls
• Tilt Range: +/- 25˚ (Up/Down)
• H.243 MCU password
• Pan Range: +/- 100˚ (Left/Right)
• H.233, H.234, H.235V3 encryption
• Total Field of View: 265˚
standards
• 12x Zoom; f-4.2 to 42mm
• Bonding, Mode 1
• F=1.85 to 2.9 mm
• Auto focus
Network Interfaces Supported
• Automatic white balance
• SIP Support (Session Initiation Protocol)
• Camera presets - local and far-end
• IP (LAN, DSL, cable modem)
(up to 99)
• Single 10/100 Ethernet port
• Standards-based, far-end camera control
(10 Mbps/100Mbps/Auto)
(FECC)
• Optional ISDN QBRI (Basic Rate Interface)
Module
People Video Resolution
• Optional ISDN PRI (Primary Rate
• Pro-Motion interlaced video (60/50 fields
Interface) Module T1/E1
full-screen video for NTSC/PAL)
• Optional Serial Module (V.35/RS-530/RS-
• 4SIF (704 x 480)
449 with RS-366 dialing)
• 4CIF (704 x 576)
• Optional wireless LAN support via
• SIF (352 x 240)
Ethernet port
• CIF (352 x 288)
• Choice of 4:3 or 16:9 display aspect ratios
Network Features
• Display People on VGA Second Monitor
• Integration with Cisco Systems'
CallManager
Content Video Resolution
Version 4.0
• XGA (1024 x 768), SVGA (800 x 600), VGA
• Automatic IP/ISDN calling
(640 x 480) for graphic displays
• Down speeding over IP and ISDN
• People video support for 4CIF and SIF on
• Audio & Video Error Concealment over IP,
second VGA display
ISDN and mixed calls
• Up to 4CIF for NTSC/PAL displays
• IP address conflict warning
Audio Standards & Protocols
• Fast Connect IP for quick video
• Polycom StereoSurround ready
connections
• 14 kHz bandwidth with G.722.1 Annex C
• Maximum call length digital timer
(Siren 14)
• Auto SPID detection and line number
• 7 kHz bandwidth with G.722, G.722.1
configuration
• 3.4 kHz bandwidth with G.711, G.728,
• MGC™ Click&View™ for individual screen
G.729A
layouts
• Polycom OneDial™ intelligent call man-
Audio Features
agement attempts call on preferred net-
• Audio add-in over SoundStation VTX
work (IP or ISDN) and automatically rolls
1000™ conference phone
over to secondary network if needed
• Audio add-in over ISDN
Polycom Headquarters:
www.polycom.com
Polycom EMEA:
Polycom Asia Pacific:

Specifications

• Polycom PathNavigator support for easy
call placement and network cost opti-
mization
• TCP/IP, UDP/IP, RTP, DNS, WINS, DHCP,
ARP, HTTP, FTP, Telnet
• Chair control through API command or
Integrated Web Interface.
• Software Upgradeable Inverse
Multiplexer (IMUX)
Internal Multipoint Features (Optional)
• Mixed protocol dialing connects a total of
four endpoints (IP/ISDN/Serial) through
the internal MCU
• Dial-in/Dial-out Calling (IP/ISDN/Serial)
• Password protection for incoming calls
- Supports up to (3) microphones • Supports IP telephones
- Supports SoundStation VTX 1000™ • Automatic IP/ISDN down speeding
conference phone • Supports People+Content™ from any end-
point (Not just the host site)
• Voice Activated Switching - view current
speaker
• Continuous Presence - see all locations
• Automatic Presentation - switch between
presenter and continuous presence mode
• MP key installation while in a call
• Audio add-in over ISDN
• Cascading for up to 10 conference partici-
pants (mix of IP/ISDN/Serial Video and
ISDN Audio)
Conference on Demand
• Initiates unscheduled MGC calls from
the endpoint
• Utilizes Polycom Office™ (PathNavigator
& MGC)
• Auto selects either the internal or
external bridge
• Dials all participants simultaneously
Security
• COMSEC tested by Titan Systems,
Information Security Systems Division,
and independently validated to operate
with approved government encryption
technologies
• KG-194/KIV-7 encryptor support with on
screen and address book dialing
• Enhanced integration for independently
certified, classified encryption devices
• Account validation number entry
• SNMP trap notification of all failed login
attempts from HTTP, FTP or Telnet
• Secure password authentication
• Unique factory default passwords
• Administrator password
• Dial-in meeting password
• Encrypted password for VSX Web access
• Ability to disable remote interfaces (FTP,
Telnet, HTTP, SNMP)
• Ability to disable mixed protocol multi-
point calls
• Auto-Answer (On/Off)
• Allow access to user settings (On/Off)
Embedded Encryption
• Advanced Encryption Standard (AES)
• FIPS validated by National Institute of
Standards & Technology (NIST) certified
agency
• 128-bit key length
• AES software encryption on ISDN, IP and
Serial/V.35 up to 2 Mbps
• Standards-based H.235V3 (IP)
• Standards-based H.233/H.234
(ISDN/Serial)
• Automatic key generation and exchange
• Supported in People+Content™
• Supported in Point-to-Point IP & ISDN &
mixed multipoint calls
User Interface
• User-friendly graphical interface
• Customizable home screen and color
themes
• Kiosk mode with scrolling marquee
• User-selectable camera icons and
ring tones
• Speed Dial List on home page
• Persistent Preview (Far-site PIP) on
all screens
• Picture In Picture (PIP) (On/Off, Moveable)
• Dual Monitor Emulation
©2005 Polycom, Inc. All rights reserved.
Polycom, the Polycom logo design, SoundStation VTX 1000 and Vortex are registered trademarks and VSX, PathNavigator, Global Management System, Siren, Pro-Motion, MGC,
Click&View, Polycom OneDial, People+Content, The Polycom Office, iPriority, Visual Concert, PowerCam, Polycom Conference Suite and StereoSurround are trademarks of Polycom, Inc.
All other trademarks are the property of their respective owners. Information in this document is subject to change without notice.
4750 Willow Road, Pleasanton, CA 94588 (T) 1.800.POLYCOM (765.9266) for North America only.
For North America, Latin America and Caribbean (T) +1.925.924.6000, (F) +1.925.924.6100
270 Bath Road, Slough, Berkshire SL1 4DX, (T) +44 (0)1753 723000, (F) +44 (0)1753 723010
Polycom Hong Kong Ltd., Rm 1101 MassMutual Tower, 38 Gloucester Road, Wanchai, Hong Kong, (T) +852.2861.3113, (F)+852.2866.8028
Part No. 1726-21403-001 Rev. 4/05
• Numerical menu navigation (Similar to Collaboration Solutions
mobile phone) • Visual Concert™ VSX (Audio and video
• Date, Time Server accessibility input from PC or Macintosh
• Calendar and Conference scheduling
• Alert Signal on home page
• Do Not Disturb (On/Off)
• VSX Web for remote monitoring
Directory Services
• People+Content IP (Optional)
• 4,000 number global directory
• 1,000+ number local directory
• Limitless multipoint entries
• Live address book with Polycom Global
Directory Services automatically and
quickly updates directory with address
changes or new endpoints
• Live address book with Polycom Global
Directory Services automatically and
quickly removes endpoints from directory
• Closed captioning support
if they are turned off
• Web Streaming in and out of a call, RTP
• Polycom Global Directory Services inte-
based, suitable with QuickTime
grates with Active Directory/LDAP
• Directory Server backup in the event Furniture solutions
Polycom Global Directory is not • Media Center with audio system
accessible • Media Center
• Automatic ISDN localization of calls • Media Cart
• Video Cart
System Management
• Wall Mount Solution
• SNMP for enterprise management
• Diagnostics and software upgrades via Language Support (12 languages)
PC, LAN Chinese (Simplified), Chinese (Traditional),
• Integrated VSX Web management tool English, French, German, Italian,
• Web Director: Remote administrator Japanese, Korean, Norwegian,
video monitoring and control from VSX Portuguese, Russian, Spanish
Web (enabled/disabled from endpoint for
security)
• Out-of-box setup from VSX Web
• Place a call from VSX Web
• Language independence between set-top
interface and VSX Web
• System configuration from VSX Web
• Recent Calls Log – Records last 99
incoming and outgoing calls
• Call Detail Record (CDR) - Reports all
incoming and outgoing calls along with
VSX 7800 Includes
call statistics
• VSX 7000 system
• CDR Feature On/Off
• Internal Multipoint Software License
• Downloadable CDR data for processing
• Additional Display Adapter Kit
requires no external management system
• (2) Digital Tabletop Microphones
• Account number validation at call initia-
• Visual Concert™ VSX
tion integrated with Polycom Global
• People+Content IP
Management System for billing purposes
• Stereo Speaker Kit
• Administrator-configurable dialing speeds
VSX 7400 Includes
• Complete support for The Polycom
• VSX 7000 system
Office™ including:
• Additional Display Adapter Kit
- Polycom Global Management System
• Visual Concert VSX
- Polycom OneDial
• People+Content IP
- Polycom PathNavigator
- Polycom Conference Suite
Electrical
- Polycom MGC
• Auto sensing power supply
- Polycom SoundStation VTX 1000
• Operating voltage/power 90-260 VAC, 47-
®
- Polycom Vortex
63 Hz/80 watts
Quality of Service and Experience –
Environmental Specifications
iPriority™
• Operating Temperature: 0-40˚ C
• Video Error Concealment
• Operating Humidity: 15-80%
• Audio Error Concealment
• Non-Operating Temperature: -40-70˚ C
• Universal Plug and Play (UPnP)
• Non-Operating Humidity (Non-condens-
• IP Precedence (ToS)
ing): 10-90%
- Configurable video/audio/FECC
Physical Characteristics
service value
• Video Base Unit (W/H/D):
• DiffServ (DSCP) (COS)
11.82"/5.83"/9.63"
• Dynamic Bandwidth Allocation
300.3mm/148mm/244.5mm
• Proactive Network Monitoring
• Video Base Unit Weight: 6.0 lbs/2.8 kg
• Packet and jitter control
• Subwoofer (W/H/D): 6.9"/10.72"/8.67"
• Network Address Translation (NAT)
175.2mm/272.4mm/220mm
support
• Subwoofer Weight: 9.0 lbs/4.08 kg
• Automatic NAT discovery
• Asymmetric speed control
Warranty
• Alternate Gatekeeper Support
• One-year return to factory parts and labor
• TCP/UDP fixed-port firewall support
• One-year software updates and upgrades
• Lip synchronization
• Echo cancellation
• Echo suppression
• Auto gatekeeper discovery
• Automatic gateway dialing profiles
• Specify outbound call routing for gate-
way/ISDN
®
) (Optional)
- 1 x audio input for laptop
- 1 x VGA output for projector
- 3 x 10/100 Ethernet hub
- Content Input: 1280 x 1024, 60 Hz
- Content Output: Up to 1024 x 768
- Show content from laptop/PC over IP
network connection
- No resolution adjustment required on
presenter's laptop/PC
- Supports CIF, SIF, 4CIF, 4SIF, VGA,
SVGA, XGA display resolutions
- Zoom control
®
- Supports Windows 2000 and
Windows XP
®
Players
- Documentation translations in
all languages
- User interface translations in
all languages
- Keypad audio dialing confirmation in
all languages
- VSX Web translations in
all languages
- Remote controls labeled in
all languages
