Advanced Router Setup - Polycom PVX Software Manual

Internet and Intranet Calling with Polycom PVX 8.0.1

Advanced Router Setup

The following ports are for advanced PVX features.
GMS Ports:
GMS listens for connections on ports 80 and 3601 (GAB) and in the future will listen on port
3604 (ViaVideo) and other potentials later.
H.323 Ports:
MGC (Accord), Polycom Network Systems Additional Ports:
Port
21 (FTP)
80 (HTTP)
3601 (Data Traffic)
(Proprietary)
3603
389
1002
Port
80
389
1503
1718
1719
1024-65535
1024-65535
1024-65535
1024-65535
3604
Port
5001
21
Feature
Software updates and provisioning
Pulling ViewStation/VS4000 information
GAB data
TCP - Pulling Video inf (since might be non-web server PC)
LDAP and ILS
ILS
Feature
Static TCP - HTTP Interface (optional)
Static TCP - ILS Registration (LDAP)
Static TCP - T.120
Static UDP - Gatekeeper discovery (Must be bidirectional)
Static UDP - Gatekeeper RAS (Must be bidirectional)
Dynamic TCP H245
Dynamic UDP - RTP (Video data)
Dynamic UDP - RTP (Audio data)
Dynamic UDP - RTCP ( Control information)
GMS Server Discovery - Used by ViaVideo (Broadcast)
Feature
Static TCP - MGC Manager (5003 can be chosen instead within
MGC)
Static TCP - FTP (retrieve MGC configuration files, etc.)
- 18 -
