It is advised to place the oven under an extractor hood or in such a way that hot fumes and odours exit the oven
via adequate ventilation to the outside.
The oven must be placed on a flat surface so that it does not slip or turn over.
The installation area must be able to support the weight of the appliance filled to the maximum.
See the information level on the back of the oven for the gross weight.
Make sure that it is placed so that the door may be fully opened.
Position it so that the back of the oven is easily accessible for maintenance, connection to the mains sockets,
and water.
The appliance is not meant to be fitted and a 5 cm space must be left all round it.
Do not position other heat sources like, fryers or hotplates, near the oven. If this is not possible at least respect
the following distances from machinery: 50 cm from the sides and above the appliance and 70 cm from behind.
Do not place the device near materials or containers of inflammable liquids (such as walls, furniture, screens,
gas canisters) as it can be a fire hazard. If this is not possible, cover the inflammable parts with fire and heat-
proof material and by checking fire hazard regulations.

4. PREPARING FOR INSTALLATION

Remove the outer packaging (wooden or carton box) and
dispose it in compliance with the laws in force in the
country of installation.
REMOVING PROTECTIVE FILM ETC.
EN
Remove the protection film from the external and internal
walls. (See image)
Remove all information covering from the inside, and take
off all plastic packaging.
STAND ADJUSTMENT
Do not use the appliance without feet.
The adjustable feet are already screwed to the underside of the oven.
If they are not used, this prevents airflow from cooling the electric parts and outsides of the oven which causes
over-heating and damage to components.
The oven will function correctly if placed level on a flat surface by adjusting the feets accordingly and using a
spirit level. Screw or unscrew them as necessary to adjust.

5. ELECTRICAL CONNECTION

WARNING: Mains connection must be carried out by a qualified and authorized technician according to
national, international and local laws in the country where it is installed. Before mains connection, ensure
that the frequency (.....V) and voltage (....Hz) meet the requirements indicated in the in the information tag
on the back of the appliance.
The electric system, as prescribed and specified by the Standard in force, must be equipped with an efficient
ground. It is possible to guarantee the electric safety of the appliance only in the presence of Standard electric
system.
