Summary of Contents for Fermax MEET MILO 1W PANEL

  • Page 1 MILO 1W PANELS INSTALLER MANUAL...
  • Page 2 Technical publication for information purposes edited by FERMAX ELECTRÓNICA S.A.U. FERMAX ELECTRÓNICA applies a continuous improvement policy, therefore it reserves the right to modify the contents of this document, as well as the product features hereof at any time and without prior notice.
  • Page 3: Table Of Contents

    INDEX Product Introduction ....................... 4 Overview ........................ 4 Functions Introduction ....................5 Call Apartment ....................... 5 Mifare Reader (Only panel with proximity reader) ..........5 Configuration via Web Server ..................6 Device Information ....................6 General Settings ....................7 Network Settings ....................9 ACC ........................
  • Page 4: Product Introduction

    1 Product Introduction 1.1 Overview Microphone 1 Mpx High definition camera Lighting for night vision with LEDs Speaker Pushbutton for calling Mifare reader (Only for panel with Slider Page 4...
  • Page 5: Functions Introduction

    2 Functions Introduction Call apartment  Open door, relay delay settings  Connect exit button  Speech message for release lock  Door opened alarm  Tamper alarm  Alarm management by access control (only panel with proximity reader)  2.1 Call Apartment Visitor push the pushbutton for calling in the 1W Panel, the ring back tone will be sent, meanwhile the monitor will ring.
  • Page 6: Configuration Via Web Server

    3 Configuration via Web Server The 1W panel has an integrated web server, which allows to configure the parameters. This web server is accessed via the panel’s IP address. The browser opens with the configured IP address of the panel. A screen opens requesting a username and password.
  • Page 7: General Settings

    3.2 General Settings TYPE 1W PANEL BLOCK: Block number the 1W panel, between 001 and 999 (default option 1). APARTMENT: Apartment number communicates with 1W panel, between 0001 and 9899 (default option 101). DEVICE NO.: Panel Number, between 1 and 9 (default option 1). DEVICE TAG: Text to be shown in the monitor and other concierge.
  • Page 8 Page 8...
  • Page 9: Network Settings

    3.3 Network Settings MEET allows to the installer to define the IP range according to the project needs and make the network management easier. MEET panel network mode is static mode. Ensure that each device has a unique IP address in same installation. The devices (digital panel, monitor and guard unit) will show IP conflict if there same IP is used on the same LAN.
  • Page 10: Acc

    3.4 ACC DOOR RELAY TIME: Time that the lock-release relay remains active (1-9s optional). OPEN DOOR DELAY: Time delay between door lock command is sent, and door lock relay is activated. The delay time is useful when the lock is not close to the panel (0-9s optional). ADMIN CARD: Master card registered to enroll additional prox cards.
  • Page 11: Sip Settings

    3.5 SIP Settings ENABLE SIP: Enable or disable sip function. SEARCH SIP STATUS: this button appear when enable SIP function, show SIP REGISTERED if the panel register successfully or SIP REGISTER FAILED if the panel register unsuccessfully. SIP SERVER: SIP server IP address. DOMAIN: Sip server domain.
  • Page 12: Advanced Settings

    3.6 Advanced Settings Quick dial is associated a MIO monitor, guard unit or sip terminal. QUICK DIAL: Enable or disable quick dial function. NOTE: The panel type do not be used 1W panel if you enable quick dial. URL: if call device of MEET system, URL: sip: sip account @ IP address of MEET device, the sip account is optional.
  • Page 13: Restore

    3.8 Restore RESTORE FACTORY SETTINGS: All the settings are restored to the factory settings. The IP address will be changed to the default IP: 10.1.1.2 REBOOT DEVICE: The guard unit will be restarted and will keep all the previous settings. Page 13...
  • Page 14: Installation

    4 Installation 4.1 Installation height Page 14...
  • Page 15: Installation Step Diagram

    4.2 Installation Step Diagram ○ ○ ○ ,1Flush box install. ,2Base flush box depth adjustment hook. ,3The upper part of the panel is stuck in, then move the panel to the flush box. 1.7CM 1.7CM ○ ,4Move the slider of the panel and fix the two screws, when installing, pay attention to the reservation of the 1.7CM space around the door to move the slide cover.
  • Page 16: Connectors

    4.3 Connectors 10/100Mbps RJ45 Port  +12V, —: 12Vdc Power Input  Relay contacts for release lock  NC, C, NO: EXIT, —: Exit button  —, DS: Door-open sensor  485+, 485-: RS485 port  Page 16...
  • Page 17: Technical Parameters

    Maximum number of per home: 9 Operating temperature: -40~70℃ Relative humidity: 20%~93%, without condensation RADIO FREQUENCY MODULE. EC DECLARATION OF CONFORMITY: FERMAX ELECTRÓNICA, S.A.U. declares that this product complies with the requirements in the RED 2014/53/EU Directive “Radio frequency equipment”. https://www.fermax.com/intl/en/pro/documents/technical-documentation/DT-13-declarations- of-conformity.html Radio frequency module: Frequency: 13.56MHz / Maximum Power:...

This manual is also suitable for:

Meet proximity readerMeet 1/w milo video panelMeet 1/w milo video panel with prox953395349535
