MEET GUARD UNIT
INSTALLER'S MANUAL
ENGLISH Version
Cod. 970136Ib V09_18
This manual corresponds to MEET Guard Unit firmware version V2.0.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MEET GUARD UNIT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Fermax MEET GUARD UNIT

  • Page 1 MEET GUARD UNIT INSTALLER’S MANUAL ENGLISH Version Cod. 970136Ib V09_18 This manual corresponds to MEET Guard Unit firmware version V2.0.
  • Page 2 FERMAX ELECTRÓNICA S.A.U. http://www.fermax.com MEET Guard Unit manual available at https://www.fermax.com/qr/meet/ Copyright Notice Fermax and Fermax MEET guard unit are trademarks of Fermax Electronica S.A.U. registered in the European Union and other countries. © FERMAX ELECTRÓNICA S.A.U., 2018. Page 2...
  • Page 3: Table Of Contents

    INDEX  1   Product Introduction ....................... 4   1.1   Overview ......................... 4   1.1   Guard Unit Interface ....................4   2   Functions Overview ......................5   2.1   Call Receptions....................... 5   2.2   Call Apartment ......................6   2.3  ...
  • Page 4: Product Introduction

    1 Product Introduction 1.1 Overview Alarm notification LED Handset Touch screen Base 1.1 Guard Unit Interface Network Status Page 4...
  • Page 5: Functions Overview

    Support auto answer, audio and video record in SD card automatically, or record manually the audio from monitor. 2.1 Call Receptions The MEET Guard Unit can receive calls from: Outdoor panels Monitor call Other guard units from the same installation The guard unit establish a conversation, capture pictures and release lock when the guard unit communicates with panel.
  • Page 6: Call Apartment

    2.2 Call Apartment The guard unit is able to contact any apartment of the community using the guard unit's call apartment function. To call from the guard, the concierge must enter 3 digits for the resident's block number and 4 digits for the apartment number. Video communication from guard unit to the monitor can be established if an IP camera is linked with the guard unit.
  • Page 7: Call Log

    REMARK : The guard unit can’t auto on for general entrance panel and 1W pan 2.5 Call Log Guards can have a clear view of their call history in the CALL LOG interface and are able to browse through image or listen to the audio records, for each call if applied.
  • Page 8: Function Setting

    Each record includes: time and date, source and triggered zone. 2.7 Function Setting The functions restrictions interface is used to activate or deactivate functions. CAMERA: no use in this version. VIDEO RECORD, AUDIO RECORD Function During the call, the guard unit is able to record audio and video. (SD card needed) if the guard unit does not answer.
  • Page 9: Ringtone Setting

    2.8 Ringtone Setting In the ringtone setting interface the guard can select the desired ringtone from the 3 available. From this interface it is also possible to set the ringtone volume and enable/disable the touch screen click tone. 2.9 Date/Time Setting If the project has no MEET management software installed, the installer can set date, time and time zone manually.
  • Page 10: Language Setting

    2.10 Language Setting The guard can select the guard unit's operating language in the language settings menu. REMARK: The guard unit will reboot automatically language is selected. 2.11 Screen Setting The user can adjust brightness and contrast of the screen by the screen settings menu. Page 10...
  • Page 11: About

    2.12 About In this option is it possible to access to the following information: device name, firmware version, MAC address, IP address. Page 11...
  • Page 12: Configuration Via Web Server

    3 Configuration via Web Server The Guard Unit has an integrated web server, allow to configure parameter. This web server is accessed via the guard unit’s IP address. The browser opens with the configured IP address of the Guard Unit. A screen opens requesting username and password.
  • Page 13: General Settings

    3.2 General Settings GUARD NO.: Guard unit number, between 01 and 98 (default option 1). DEVICE NO.: The extension guard unit with the same guard unit number, between 0 and 7(default option 0). Guard units with the same GUARD NO. but different DEVICE NO. will ring at the same time.
  • Page 14: Network Settings

    3.3 Network Settings MEET allows the installer to define the IP range according to the project needs and make the network management easier. MEET panel network mode is static mode. Ensure that each device has a unique IP address in same installation. The devices (digital panel, monitor and guard unit) will show IP conflict if there same IP is used on the same LAN.
  • Page 15: Sip Settings

    3.4 SIP Settings ENABLE SIP: Enable or disable sip function. SIP SERVER: SIP server IP address. DOMAIN: Sip server domain. OUTBOUND: Some servers are used when NAT. STUN IP: Audio and video NAT traversing public network server IP. STUN PORT: The port of audio and video NAT traversing public network server. SIP USER: The username of sip account.
  • Page 16: Advanced Settings

    3.5 Advanced Settings SIP EXTENSION: Enable or disable sip extension function. The SIP extension is used as the extension of the Guard Unit. When the panel or monitor call the Guard Unit, the SIP extension will ring too. If the Guard Unit or SIP extension answer the call, the rest of terminals will stop ringing.
  • Page 17: Pincode Settings

    3.7 Pincode Settings This allows to change the pin code of the web server login. 3.8 Log Out Log out the web server. Page 17...
  • Page 18: Installation

    4 Installation 4.1 Schematic Diagram of Guard Unit Installation ○ ○ ,1 Fit support on the base ,2Support installation. Assembly direction. ○ ○ ,4Installation is complete. ,3Display screen is stuck from up and down. Page 18...
  • Page 19 The steps for removing guard unit Take down the direction. ○ ,1The display screen is removed from the bottom up from the bracket. Use a screwdriver to force the direction of the arrow angle can be separated from the bracket and a base. ○...
  • Page 20: Connectors

    4.2 Connectors  12Vdc Power Input.  10/100Mbps RJ45 Port.  NOTE: the wire with white line is the positive. 4.3 Technical Parameters Power supply: 12Vdc Standby current: 200mA Working current: 500mA Screen: 9" inches Resistive touch screen Resolution: 800*480 Maximum conversation time: 120s Maximum record time: 30s Guard unit number: 01-98...
