iDataLink maestro Rr Install Manual
  1. Manuals
  2. Brands
  3. iDataLink Manuals
  4. Automobile Accessories
  5. maestro Rr
  6. Install manual

iDataLink maestro Rr Install Manual

Hide thumbs Also See for maestro Rr:

Advertisement

Quick Links

Download this manual
SELECT VEHICLE
PRINT PAGES NEEDED
HOW TO USE THIS INSTALL GUIDE
1
Open the Bookmarks menu and find your vehicle OR scroll
down until you find the install guide for your vehicle.
2
Print only the pages for your vehicle using the advanced
options in the Print menu.
3
Install your Maestro RR according to the guide for your vehicle.
Pressing the printer icon or "quick printing" this document will print
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certifi ed technician. Logos and trademarks used here in
are the properties of their respective owners.
WARNING
all of the guides in this compilation.

Advertisement

loading
Need help?

Need help?

Do you have a question about the maestro Rr and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for iDataLink maestro Rr

Summary of Contents for iDataLink maestro Rr

  • Page 1 Print only the pages for your vehicle using the advanced options in the Print menu. Install your Maestro RR according to the guide for your vehicle. WARNING Pressing the printer icon or “quick printing” this document will print all of the guides in this compilation.
  • Page 2 Mazda 2 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 3 Mazda 2 2011-2014 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 4 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 5 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 6 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 7 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 8 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 9 Mazda 3 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 10 Mazda 3 2004-2013 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 11 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 12 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 13 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 14 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 15 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 16 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 17 Mazda 3 without touchscreen 2014-2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 18 STEP 7 • Unlug the HRR-MA1 4-pin white and 4-pin black connectors. • Connect all the harnesses to the Maestro RR module then test your installation. • Connect the HRR-MA1 4-pin white to 4-pin white connector with RCAs. Connect the 4-pin black to 4-pin black connector with RCAs.
  • Page 19 WHITE BLUE FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / RIGHT OF GLOVE BOX MAESTRO RR MODULE N.C. AA Y W U S Q G E C A GREEN AB Z X V T R GRAY...
  • Page 20 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 21 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 22 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 23 Mazda 5 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 24 Mazda 5 2006-2011 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 25 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 26 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 27 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 28 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 29 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 30 Mazda 5 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 31 Mazda 5 2012-2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 32 STEP 7 • Unlug the HRR-MA1 4-pin white and 4-pin black connectors. • Connect all the harnesses to the Maestro RR module then test your installation. • Connect the HRR-MA1 4-pin white to 4-pin white connector with RCAs. Connect the 4-pin black to 4-pin black connector with RCAs.
  • Page 33 WHITE BLUE FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / ABOVE GLOVE BOX MAESTRO RR MODULE N.C. AA Y W U S Q G E C A GREEN AB Z X V T R GRAY STEP 5...
  • Page 34 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 35 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 36 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 37 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 38 Mazda 5 without touchscreen 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 39 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 40 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 41 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 42 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 43 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 44 Mazda 6 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 45 Mazda 6 2003-2013 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 46 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 47 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 48 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 49 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 50 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 51 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 52 Mazda 6 without touchscreen 2014-2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 53 (ex: BOSE). • Connect all the harnesses to the Maestro RR module then test your installation. If the vehicle DOES NOT have a factory amplifi er: •...
  • Page 54 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS BLUE N.C. STEP 6 WHITE GREEN FACTORY RADIO HARNESS MAESTRO RR MODULE STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc.
  • Page 55 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 56 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 57 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 58 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 59 Mazda 6 without touchscreen 2016-2017 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 60 STEP 7 • Unlug the HRR-MA1 4-pin white and 4-pin black connectors. • Connect all the harnesses to the Maestro RR module then test your installation. • Connect the HRR-MA1 4-pin white to 4-pin white connector with RCAs. Connect the 4-pin black to 4-pin black connector with RCAs.
  • Page 61 WHITE BLUE FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / RIGHT OF GLOVE BOX MAESTRO RR MODULE N.C. AA Y W U S Q G E C A GREEN AB Z X V T R GREEN/ORANGE...
  • Page 62 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 63 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 64 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 65 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 66 Mazda CX-3 without touChsCreen 2016-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 67 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 68 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 69 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 70 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 71 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 72 Mazda CX-5 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 73 Mazda CX-5 2012-2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 74 (ex: BOSE). • Connect all the harnesses to the Maestro RR module then test your installation. If the vehicle DOES NOT have a factory amplifi er: •...
  • Page 75 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS BLUE N.C. STEP 6 WHITE GREEN FACTORY RADIO HARNESS MAESTRO RR MODULE STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE STEERING WHEEL CONTROL CABLE Automotive Data Solutions Inc.
  • Page 76 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 77 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 78 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 79 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 80 Mazda CX-5 without touChsCreen 2016-2020 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 81 Note: only connect purple/white wire to radio reverse input or module damage will occur. STEP 6 • Connect the blue POWER ANT terminal to amplifi ed • Connect all the harnesses to the Maestro RR module then antenna adapter (if required). test your installation. STEP 2 •...
  • Page 82 VEHICLE STEP 3 FACTORY RADIO HARNESS WHITE N.C. BLUE N.C. STEP 6 STEP 4 MAESTRO RR MODULE BLUETOOTH MODULE BEHIND/RIGHT OF GLOVE BOX N.C. AA Y W U S Q G E C A GREEN AB Z X V T R...
  • Page 83 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 84 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 85 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 86 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 87 Mazda CX-7 without touChsCreen 2007-2008 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 88 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 89 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 90 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 91 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 92 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 93 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 94 Mazda CX-7 without touChsCreen 2009 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 95 STEP 7 • Unlug the HRR-MA1 4-pin white and 4-pin black connectors. • Connect all the harnesses to the Maestro RR module then test your installation. • Connect the HRR-MA1 4-pin white to 4-pin white connector with RCAs. Connect the 4-pin black to 4-pin black connector with RCAs.
  • Page 96 WHITE BLUE FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / RIGHT OF GLOVE BOX MAESTRO RR MODULE N.C. AA Y W U S Q G E C A GREEN AB Z X V T R GRAY/ORANGE...
  • Page 97 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 98 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 99 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 100 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 101 Mazda CX-7 without touChsCreen 2010-2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 102 STEP 7 • Unlug the HRR-MA1 4-pin white and 4-pin black connectors. • Connect all the harnesses to the Maestro RR module then test your installation. • Connect the HRR-MA1 4-pin white to 4-pin white connector with RCAs. Connect the 4-pin black to 4-pin black connector with RCAs.
  • Page 103 WHITE BLUE FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / RIGHT OF GLOVE BOX MAESTRO RR MODULE N.C. AA Y W U S Q G E C A GREEN AB Z X V T R BROWN...
  • Page 104 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 105 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 106 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 107 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 108 Mazda CX-9 without touChsCreen 2007-2008 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 109 STEP 7 • Unlug the HRR-MA1 4-pin white and 4-pin black connectors. • Connect all the harnesses to the Maestro RR module then test your installation. • Connect the HRR-MA1 4-pin white to 4-pin white connector with RCAs. Connect the 4-pin black to 4-pin black connector with RCAs.
  • Page 110 WHITE BLUE FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / ABOVE GLOVE BOX MAESTRO RR MODULE N.C. AA Y W U S Q G E C A GREEN AB Z X V T R LTGREEN/RED STEP 5...
  • Page 111 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 112 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 113 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 114 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 115 Mazda CX-9 without touChsCreen 2009-2012 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 116 STEP 7 • Unlug the HRR-MA1 4-pin white and 4-pin black connectors. • Connect all the harnesses to the Maestro RR module then test your installation. • Connect the HRR-MA1 4-pin white to 4-pin white connector with RCAs. Connect the 4-pin black to 4-pin black connector with RCAs.
  • Page 117 WHITE BLUE FACTORY RADIO N.C. HARNESS STEP 4 STEP 7 BLUETOOTH MODULE BEHIND / ABOVE GLOVE BOX MAESTRO RR MODULE N.C. AA Y W U S Q G E C A GREEN AB Z X V T R LTGREEN/RED STEP 5...
  • Page 118 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 119 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 120 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 121 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 122 Mazda CX-9 without touChsCreen 2013-2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 123 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 124 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 125 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 126 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 127 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 128 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 129 Mazda MX-5 without touchscreen 2006-2015 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 130 (ex: BOSE). • Connect all the harnesses to the Maestro RR module then test your installation. If the vehicle DOES NOT have a factory amplifi er: •...
  • Page 131 VEHICLE STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 132 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 133 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 134 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 135 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 136 Mazda MX-5 without touchscreen 2016-2018 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 137 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 138 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 139 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 140 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 141 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
  • Page 142 RETAINS STEERING WHEEL CONTROLS, VEHICLE SETTINGS, AND MORE! PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface Click here for: iDatalink Maestro HRR-MA1 Installation Harness Radar Installation Guides E L E C T R O N I C S...
  • Page 143 Mazda RX-8 without touchscReen 2009-2011 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Radio Wire Reference Chart enhanced features.
  • Page 144 STEP 2 STEP 6 • Determine if the vehicle has a factory amplifi er. Look for • Connect all the harnesses to the Maestro RR module then badges on the radio, door panels and dash that indicate the test your installation.
  • Page 145 STEP 3 BACKUP CAMERA CONNECT IF EQUIPPED * HARNESS STEP 6 WHITE BLUE GREEN FACTORY RADIO N.C. N.C. HARNESS MAESTRO RR MODULE N.C. STEP 4 OBDII CONNECTOR BLACK AMP TURN ON AMP TURN ON N.C. HRR-MA1 T-HARNESS NOT REQUIRED AUDIO CABLE...
  • Page 146 Wire Color on Adapter Kenwood Radio Wire Description E-Brake LtGreen LtGreen Reverse Light* Purple/White Purple/White Steering Wheel Controls (DATA) Blue/Yellow * Reverse light wire: Only connect to radio or module damage will occur. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 147 Turns off after one minute: Normal operation. • • Normal operation (inactive). VIDEO HELP Installation, product information, vehicle specific videos. VERIFY FLASH Last flash information, steering control configuration, vehicle information. WEBLINK Software to program module. Automotive Data Solutions Inc. © 2023 ADS-HRR(SR)-MA01-DS-IG-EN maestro.idatalink.com...
  • Page 148 The light on the Maestro is blinking RED TWICE and the radio IS turning on. Ensure the 4-pin data cable is connected between the radio and the RR, and that it is plugged into the black port on the Maestro RR. The red and blue ports on the RR should be empty.
