iDataLink maestro Rr Install Manual

2012-2015 honda civic

Hide thumbs Also See for maestro Rr:

Install manual (1403 pages)

How to use manual (201 pages)

Manual (106 pages)

page of 26

/ 26
Bookmarks

Quick Links

Download this manual

SELECT VEHICLE

PRINT PAGES NEEDED

HOW TO USE THIS INSTALL GUIDE

Open the Bookmarks menu and find your vehicle OR scroll

down until you find the install guide for your vehicle.

Print only the pages for your vehicle using the advanced

options in the Print menu.

Install your Maestro RR according to the guide for your vehicle.

Pressing the printer icon or "quick printing" this document will print

NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certiﬁ ed technician. Logos and trademarks used here in

are the properties of their respective owners.

WARNING

all of the guides in this compilation.

Need help?

Do you have a question about the maestro Rr and is the answer not in the manual?

Questions and answers

Summary of Contents for iDataLink maestro Rr

Page 1 Print only the pages for your vehicle using the advanced options in the Print menu. Install your Maestro RR according to the guide for your vehicle. WARNING Pressing the printer icon or “quick printing” this document will print all of the guides in this compilation.
Page 2 Honda CiviC witH nav RETAINS STEERING WHEEL CONTROLS PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface PROGRAMMED FIRMWARE ADS-RR(SI)-HON01-AS ADDITIONAL RESOURCES Maestro RR2 Programmable Outputs Guide NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here...
Page 3 Honda CiviC witH nav 2012-2015 WELCOME TABLE OF CONTENTS Wiring Diagram Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Vehicle Wire Reference Chart now a few simple steps away from enjoying your new car radio with Troubleshooting Table enhanced features.
Page 4 STEP 3 AFTERMARKET RADIO GRAY/RED RADIO ACCESSORY WIRE YELLOW RADIO BATTERY (+) WIRE BLACK RADIO GROUND WIRE STEP 4 MAESTRO RR MODULE STEERING WHEEL CONTROL CABLE DO NOT CONNECT NOT REQUIRED DATA CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2019 ADS-RR(SI)-HON01-AS-IG-EN maestro.idatalink.com...
Page 5 Wire Color Polarity Description Name Color Type Location Can2H 20 pin Pink (DATA) Behind radio Can2L 20 pin Blue (DATA) Behind radio SWI 2 32 pin Blue (DATA) Bluetooth unit, above glove box Automotive Data Solutions Inc. © 2019 ADS-RR(SI)-HON01-AS-IG-EN maestro.idatalink.com...
Page 6 The light on the Maestro is ﬂ ashing RED once. There is no ﬁ rmware on the module; ﬂ ash the RR module. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module.
Page 7 Honda CiviC witHout nav RETAINS STEERING WHEEL CONTROLS PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface PROGRAMMED FIRMWARE ADS-RR(SI)-HON01-AS ADDITIONAL RESOURCES Maestro RR2 Programmable Outputs Guide NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here...
Page 8 Honda CiviC witHout nav 2012-2015 WELCOME TABLE OF CONTENTS Wiring Diagram Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Vehicle Wire Reference Chart now a few simple steps away from enjoying your new car radio with Troubleshooting Table enhanced features.
Page 9 STEP 3 AFTERMARKET RADIO GRAY/RED RADIO ACCESSORY WIRE YELLOW RADIO BATTERY (+) WIRE BLACK RADIO GROUND WIRE STEP 4 MAESTRO RR MODULE STEERING WHEEL CONTROL CABLE DO NOT CONNECT NOT REQUIRED DATA CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2019 ADS-RR(SI)-HON01-AS-IG-EN maestro.idatalink.com...
Page 10 Wire Color Polarity Description Name Color Type Location Can2H 20 pin Pink (DATA) Behind radio Can2L 20 pin Blue (DATA) Behind radio SWI 2 32 pin Blue (DATA) Bluetooth unit, above glove box Automotive Data Solutions Inc. © 2019 ADS-RR(SI)-HON01-AS-IG-EN maestro.idatalink.com...
Page 11 The light on the Maestro is ﬂ ashing RED once. There is no ﬁ rmware on the module; ﬂ ash the RR module. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module.
Page 12 Honda CRv witH nav RETAINS STEERING WHEEL CONTROLS PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface PROGRAMMED FIRMWARE ADS-RR(SI)-HON01-AS ADDITIONAL RESOURCES Maestro RR2 Programmable Outputs Guide NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here...
Page 13 Honda CRv witH nav 2012-2016 WELCOME TABLE OF CONTENTS Wiring Diagram Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Vehicle Wire Reference Chart now a few simple steps away from enjoying your new car radio with Troubleshooting Table enhanced features.
Page 14 STEP 3 AFTERMARKET RADIO GRAY/RED RADIO ACCESSORY WIRE YELLOW RADIO BATTERY (+) WIRE BLACK RADIO GROUND WIRE STEP 4 MAESTRO RR MODULE STEERING WHEEL CONTROL CABLE DO NOT CONNECT NOT REQUIRED DATA CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2019 ADS-RR(SI)-HON01-AS-IG-EN maestro.idatalink.com...
Page 15 Name Color Type Location Can2H 20 pin Pink (DATA) Behind radio Can2L 20 pin Blue (DATA) Behind radio SWI 2 32 pin Yellow (DATA) Bluetooth unit, center dash in front of shifter Automotive Data Solutions Inc. © 2019 ADS-RR(SI)-HON01-AS-IG-EN maestro.idatalink.com...
Page 16 The light on the Maestro is ﬂ ashing RED once. There is no ﬁ rmware on the module; ﬂ ash the RR module. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module.
Page 17 Honda CRv witH nav witH BluetootH RETAINS STEERING WHEEL CONTROLS PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface PROGRAMMED FIRMWARE ADS-RR(SI)-HON01-AS ADDITIONAL RESOURCES Maestro RR2 Programmable Outputs Guide NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here...
Page 18 Honda CRv witH nav witH BluetootH 2010-2011 WELCOME TABLE OF CONTENTS Wiring Diagram Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Vehicle Wire Reference Chart now a few simple steps away from enjoying your new car radio with Troubleshooting Table enhanced features.
Page 19 STEP 4 AFTERMARKET RADIO GRAY/RED RADIO ACCESSORY WIRE YELLOW RADIO BATTERY (+) WIRE BLACK RADIO GROUND WIRE STEP 5 MAESTRO RR MODULE STEERING WHEEL CONTROL CABLE DO NOT CONNECT NOT REQUIRED DATA CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2019 ADS-RR(SI)-HON01-AS-IG-EN maestro.idatalink.com...
Page 20 Pink (DATA) Behind radio SWI 2 28 pin Blue (DATA) Bluetooth unit, center dash SWI 3 12 pin Green (DATA) Navigation unit, center dash SWI Feed 24 pin Brown (DATA) Behind radio Automotive Data Solutions Inc. © 2019 ADS-RR(SI)-HON01-AS-IG-EN maestro.idatalink.com...
Page 21 The light on the Maestro is ﬂ ashing RED once. There is no ﬁ rmware on the module; ﬂ ash the RR module. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module.
Page 22 Honda CRv witHout nav RETAINS STEERING WHEEL CONTROLS PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface PROGRAMMED FIRMWARE ADS-RR(SI)-HON01-AS ADDITIONAL RESOURCES Maestro RR2 Programmable Outputs Guide NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certified technician. Logos and trademarks used here...
Page 23 Honda CRv witHout nav 2012-2016 WELCOME TABLE OF CONTENTS Wiring Diagram Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Vehicle Wire Reference Chart now a few simple steps away from enjoying your new car radio with Troubleshooting Table enhanced features.
Page 24 STEP 3 AFTERMARKET RADIO GRAY/RED RADIO ACCESSORY WIRE YELLOW RADIO BATTERY (+) WIRE BLACK RADIO GROUND WIRE STEP 4 MAESTRO RR MODULE STEERING WHEEL CONTROL CABLE DO NOT CONNECT NOT REQUIRED DATA CABLE AUDIO CABLE Automotive Data Solutions Inc. © 2019 ADS-RR(SI)-HON01-AS-IG-EN maestro.idatalink.com...
Page 25 Name Color Type Location Can2H 20 pin Pink (DATA) Behind radio Can2L 20 pin Blue (DATA) Behind radio SWI 2 32 pin Yellow (DATA) Bluetooth unit, center dash in front of shifter Automotive Data Solutions Inc. © 2019 ADS-RR(SI)-HON01-AS-IG-EN maestro.idatalink.com...
Page 26 The light on the Maestro is ﬂ ashing RED once. There is no ﬁ rmware on the module; ﬂ ash the RR module. MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module.
