Open the Bookmarks menu and find your vehicle OR scroll
down until you find the install guide for your vehicle.
2
Print only the pages for your vehicle using the advanced
options in the Print menu.
3
Install your Maestro RR according to the guide for your vehicle.
Pressing the printer icon or "quick printing" this document will print
NOTICE: Automotive Data Solutions Inc. (ADS) recommends having this installation performed by a certifi ed technician. Logos and trademarks used here in
Do you have a question about the maestro Rr and is the answer not in the manual?
Questions and answers
kevin haslett
March 9, 2025
to program the maestro Rr do you use a USB ?
1 comments:
Mr. Anderson
May 14, 2025
To program the iDataLink Maestro RR using a USB:
1. Connect the Maestro RR to your PC using the included USB cable. 2. Use a PC with Windows XP or newer and Internet Explorer. 3. Go to the iDatalink website and create an account. 4. Click the "Flash Your Module" button on the website. 5. Install the required software when prompted. 6. Refresh or restart the browser after installation. 7. Ensure ActiveX is enabled in Internet Explorer for proper recognition.
Once recognized, you can proceed with programming.
Page 1
Print only the pages for your vehicle using the advanced options in the Print menu. Install your Maestro RR according to the guide for your vehicle. WARNING Pressing the printer icon or “quick printing” this document will print all of the guides in this compilation.
Page 2
INSTALL GUIDE 2014-2023 Harley-DaviDson electra GliDe RETAINS HANDLE BAR CONTROLS PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-RR-WPB iDatalink Maestro HD2 Installation Harness ACC-ABP-HD2 Non-iDatalink Compatible Radio ACC-USB-HD2 PROGRAMMED FIRMWARE ADS-RR(SR)-HD02-AS ADDITIONAL RESOURCES Maestro RR2 Programmable Outputs Guide NOTICE: Automotive Data Solutions Inc.
Page 3
Harley-DaviDson electra GliDe 2014-2023 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Module Diagnostics enhanced features.
Page 4
(blue/yellow wire Kenwood/JVC only) OR (3.5mm jack to the radio’s steering wheel input). STEP 4 • Connect all the harnesses to the Maestro RR module then test your installation. Note: Because the vehicle is not equipped with illumination or reverse gear signals, these outputs can be triggered manually by confi guring them as steering wheel control commands during the fl ashing process in Weblink.
Page 7
There is no fi rmware on the module; fl ash the RR module. RED ONCE MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 8
INSTALL GUIDE 2014-2023 Harley-DaviDson roaD GliDe RETAINS HANDLE BAR CONTROLS PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-RR-WPB iDatalink Maestro HD2 Installation Harness ACC-ABP-HD2 Non-iDatalink Compatible Radio ACC-USB-HD2 PROGRAMMED FIRMWARE ADS-RR(SR)-HD02-AS ADDITIONAL RESOURCES Maestro RR2 Programmable Outputs Guide NOTICE: Automotive Data Solutions Inc.
Page 9
Harley-DaviDson roaD GliDe 2014-2023 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Module Diagnostics enhanced features.
Page 10
(blue/yellow wire Kenwood/JVC only) OR (3.5mm jack to the radio’s steering wheel input). STEP 4 • Connect all the harnesses to the Maestro RR module then test your installation. Note: Because the vehicle is not equipped with illumination or reverse gear signals, these outputs can be triggered manually by confi guring them as steering wheel control commands during the fl ashing process in Weblink.
Page 13
There is no fi rmware on the module; fl ash the RR module. RED ONCE MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 14
INSTALL GUIDE 2014-2023 Harley-DaviDson street GliDe RETAINS HANDLE BAR CONTROLS PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-RR-WPB iDatalink Maestro HD2 Installation Harness ACC-ABP-HD2 Non-iDatalink Compatible Radio ACC-USB-HD2 PROGRAMMED FIRMWARE ADS-RR(SR)-HD02-AS ADDITIONAL RESOURCES Maestro RR2 Programmable Outputs Guide NOTICE: Automotive Data Solutions Inc.
Page 15
Harley-DaviDson street GliDe 2014-2023 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Module Diagnostics enhanced features.
Page 16
(blue/yellow wire Kenwood/JVC only) OR (3.5mm jack to the radio’s steering wheel input). STEP 4 • Connect all the harnesses to the Maestro RR module then test your installation. Note: Because the vehicle is not equipped with illumination or reverse gear signals, these outputs can be triggered manually by confi guring them as steering wheel control commands during the fl ashing process in Weblink.
Page 19
There is no fi rmware on the module; fl ash the RR module. RED ONCE MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 20
INSTALL GUIDE 2014-2023 Harley-DaviDson Tri GliDe RETAINS HANDLE BAR CONTROLS PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-RR-WPB iDatalink Maestro HD2 Installation Harness ACC-ABP-HD2 Non-iDatalink Compatible Radio ACC-USB-HD2 PROGRAMMED FIRMWARE ADS-RR(SR)-HD02-AS ADDITIONAL RESOURCES Maestro RR2 Programmable Outputs Guide NOTICE: Automotive Data Solutions Inc.
Page 21
Harley-DaviDson Tri GliDe 2014-2023 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Module Diagnostics enhanced features.
Page 22
(blue/yellow wire Kenwood/JVC only) OR (3.5mm jack to the radio’s steering wheel input). STEP 4 • Connect all the harnesses to the Maestro RR module then test your installation. Note: Because the vehicle is not equipped with illumination or reverse gear signals, these outputs can be triggered manually by confi guring them as steering wheel control commands during the fl ashing process in Weblink.
Page 25
There is no fi rmware on the module; fl ash the RR module. RED ONCE MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Page 26
INSTALL GUIDE 2014-2023 Harley-DaviDson Ultra GliDe RETAINS HANDLE BAR CONTROLS PRODUCTS REQUIRED OPTIONAL ACCESSORIES iDatalink Maestro RR or RR2 Radio Replacement Interface ACC-RR-WPB iDatalink Maestro HD2 Installation Harness ACC-ABP-HD2 Non-iDatalink Compatible Radio ACC-USB-HD2 PROGRAMMED FIRMWARE ADS-RR(SR)-HD02-AS ADDITIONAL RESOURCES Maestro RR2 Programmable Outputs Guide NOTICE: Automotive Data Solutions Inc.
Page 27
Harley-DaviDson Ultra GliDe 2014-2023 WELCOME TABLE OF CONTENTS Installation Instructions Congratulations on the purchase of your iDatalink Maestro RR Radio replacement solution. You are Wiring Diagram now a few simple steps away from enjoying your new car radio with Module Diagnostics enhanced features.
Page 28
(blue/yellow wire Kenwood/JVC only) OR (3.5mm jack to the radio’s steering wheel input). STEP 4 • Connect all the harnesses to the Maestro RR module then test your installation. Note: Because the vehicle is not equipped with illumination or reverse gear signals, these outputs can be triggered manually by confi guring them as steering wheel control commands during the fl ashing process in Weblink.
Page 31
There is no fi rmware on the module; fl ash the RR module. RED ONCE MAESTRO RR RESET PROCEDURE: Turn the key to the OFF position, then disconnect all connectors from the module. Press and hold the module’s programming button and connect all the connectors back to the module. Wait, the module’s LED will fl ash RED rapidly (this may take up to 10 seconds).
Need help?
Do you have a question about the maestro Rr and is the answer not in the manual?
Questions and answers
to program the maestro Rr do you use a USB ?
To program the iDataLink Maestro RR using a USB:
1. Connect the Maestro RR to your PC using the included USB cable.
2. Use a PC with Windows XP or newer and Internet Explorer.
3. Go to the iDatalink website and create an account.
4. Click the "Flash Your Module" button on the website.
5. Install the required software when prompted.
6. Refresh or restart the browser after installation.
7. Ensure ActiveX is enabled in Internet Explorer for proper recognition.
Once recognized, you can proceed with programming.
This answer is automatically generated
