Specification:

Current load
Type
cont. / peak
iESC 65.8 65A/75A
iESC 125.8 125A/135A
1. CONNECTIONS
First connect the iESC to the motor. Later on you can reverse its direction
of rotation by swapping over any two of the wires - although this is also
easily achieved with a software setting.
Connect the brown / red / yellow lead to the throttle channel of your recei-
ver, and set the throttle channel at the transmitter to -100% to +100%.
Telemetry is available for the following three systems; the telemetry sys-
tem in use is automatically detected:
PowerBox P²-BUS
Connect the blue / red / white patch lead (supplied) to the P²-BUS input
at the receiver. You can adjust all the controller's parameters conveniently
using the Telemetry menu.
Jeti EX-BUS
Connect the blue / red / white patch lead (supplied) to one of the EX-BUS
inputs at the receiver. You can adjust all the controller's parameters conve-
niently using the JetiBox menu.
Futaba S.BUS2
Connect the blue / red / white patch lead (supplied) to the S.BUS2 input
at the receiver. You can adjust all the controller's parameters using the
separately available LCD programming box.
www.powerbox-systems.com
LiPo
BEC output 8A
cells
3S - 6S 6.0V/7.4V/8.4V
3S - 8S 6.0V/7.4V/8.4V
Dimensions Weight
(mm) (g)
60 x 36 x 20 65
88 x 38 x 24 112
Adjustable
parameters
yes
yes
