Mechanical Dimensions

Figure 15

Overall dimensions – Charger tray

68 mm

144 mm

BPC65 / BDIST / MDIST – Product Manual

CHARGER TRAY (TOP VIEW)

BDIST

CHARGER

A = 32 mm

450 mm

BDIST

CHARGER

CHARGER TRAY (FRONT VIEW)

U-0456-0143.doc – Issue: 03 complete, approved

Page 25 of 32

56 mm

80 mm
