Summary of Contents for SIMPLIHOME WyndenHall brooklyn+max AXCLEV06-SMB
- Page 1 Lev / Rowan / Cadwyn Console Table Model # AXCLEV06-SMB...
- Page 2 Great quality is a right. Thank you for shopping with Simpli Home, America's top brand for high-value furniture. It's time to register your product warranty. It's quick and easy. And you'll be happy you did. ü Activate your 1-year warranty ü...
- Page 3 Review your product and collect rewards! Thank you for your purchase! We hope you enjoy it. We’d love your feedback. Please share a review and get instant rewards! simpli-home.com/product-review Share photos and get your cash back! Send us images or share them on social and qualify for instant rewards.
- Page 4 For Fastest Customer Service: Open your phone’s camera. Point your phone’s camera at the QR code to scan. Click on the pop up. You’ll be taken to our customer service page. Fill the form with your order information and issue. Submit form.
-
Page 5: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. Safety Information CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product. -
Page 6: Care And Maintenance
Care & Maintenance This furniture is designed for indoor use. Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally along different grain directions. -
Page 7: Pre-Assembly Information
Pre-Assembly Information Model # AXCLEV06-SMB Part Description MIDDLE SHELF BOTTOM FRAME QTY 1 QTY 1 QTY 1 LEFT SIDE RIGHT SIDE LEFT DIVIDER QTY 1 QTY 1 QTY 1 RIGHT DIVIDER BACK DOOR QTY 1 QTY 1 QTY 3... - Page 8 Pre-Assembly Information Model # AXCLEV06-SMB Hardware Description CAM LOCK PIN HANDLE ALLEN KEY SCREW M4 X 15mm CAM LOCK M6 X 30mm QTY 6 SETS QTY 3 SETS QTY 24 WOOD DOWEL ALLEN KEY Ø8 X 30mm ADJUSTABLE HINGE QTY 8 QTY 6 QTY 1 PHILLIPS SCREW...
- Page 9 Components - Key Diagram Model # AXCLEV06-SMB...
- Page 10 Assembly Model # AXCLEV06-SMB Step 1 1. Attach two Cam Lock Pins 2 into pre-drilled holes on Top A . 2. Use Phillips screwdriver to secure Cam Lock Pins. Do not over-tighten. 1. Insert four Wood Dowels 5 into guide holes on Back F . 2.
- Page 11 Assembly Model # AXCLEV06-SMB Step 1 1. Insert two Wood Dowels 5 into guide holes on each Side DL , DR . 2. Use rubber mallet to tap Dowels 5 into bottom of holes securely. 1/2 length of Dowels should be exposed.
- Page 12 Assembly Model # AXCLEV06-SMB Step 3 1. Align Wood Dowels with guide holes and attach Back F to Sides DL , DR . 2. Use three Allen Key Screws 1 to attach Middle Shelf B through guide holes from Middle Shelf B to pre-drilled holes of Sides DL , DR . 3.
- Page 13 Assembly Model # AXCLEV06-SMB Step 4 1. Attach Dividers EL , ER to part B using six Allen Key Screws 1 . 2. Use Allen Key 4 to tighten screws. Do not over-tighten.
- Page 14 Assembly Model # AXCLEV06-SMB Step 5 1. Use Allen Key Screws 1 to attach Bottom Frame C through guide holes from Bottom Frame C to pre-drilled holes of Sides DL , DR and Dividers EL , ER. 2. Use Allen Key 4 to tighten Screws. Do not over-tighten.
- Page 15 Assembly Model # AXCLEV06-SMB Step 6 1. Align Cam Lock Pins and Wood Dowels with guide holes and attach Top A to Sides DL , DR . 2. Insert three Cam Locks 2 into guided holes on each Side DL , DR. 3.
- Page 16 Assembly Model # AXCLEV06-SMB Step 7 1. Attach Adjustable Hinges 6 to Doors G using Phillips Screws 7 into pre-drilled holes on Doors G . 1. Attach Adjustable Hinges 6 on Doors G to Sides DL , DR and Divider ER using Phillips Screws 7 into guide holes on Sides DL , DR and Divider ER .
-
Page 17: Important Note
Assembly Model # AXCLEV06-SMB Step 8 IMPORTANT NOTE: Tighten the Screw marked II to fasten hinge. The door may need to be adjusted so that all the spaces between the door and the unit sides are equal. To adjust, follow instructions: 1. - Page 18 Assembly Model # AXCLEV06-SMB Step 9 1. Attach Magnets 8 to Middle Shelf B using Phillips Screws 9 into pre-drilled holes on Middle Shelf C . 2. Attach Magnet Plates 8 using Phillips Screws 9 into pre-drilled holes on Doors G . 3.
- Page 19 Furniture Tip Over Restraint Assembly WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. Step 10 NOTE: The screwdriver is not included in the hardware pack.
- Page 20 Furniture Anti-Tipping Restraint Instructions Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
