POSI-CHLOR
®
SALT WATER CHLORINATOR
OWNER'S MANUAL
Should the installer or owner be unfamiliar with the correct installation
and/or operation of this type of equipment, please contact the distributor
or manufacturer for the correct advice before proceeding with the
installation or operation of this product.
PENTAIRPOOL.COM.AU
Advertisement
Table of Contents
Related Manuals for Pentair Posi-Chlor-15
Summary of Contents for Pentair Posi-Chlor-15
- Page 1 POSI-CHLOR ® SALT WATER CHLORINATOR OWNER’S MANUAL Should the installer or owner be unfamiliar with the correct installation and/or operation of this type of equipment, please contact the distributor or manufacturer for the correct advice before proceeding with the installation or operation of this product. PENTAIRPOOL.COM.AU...
- Page 2 IMPORTANT Please attach your sales invoice/docket here as proof of purchase should warranty service be required. Please do not return warranty form to Pentair Australia - Retain for your records. PURCHASED FROM: PURCHASE DATE: SERIAL NO: MODEL NO:...
-
Page 3: Table Of Contents
TABLE OF CONTENTS GENERAL DESCRIPTION ....................2 1.1 Product range ......................3 1.2 Technical specifications..................3 1.3 Recommendations and Safety Precautions ............4 PREPARING THE SWIMMING POOL ...................5 2.1 Adding salt to the water ..................5 2.2 Chemical balance of the water ................6 INSTALLATION OF THE EQUIPMENT ................7 3.1 Contents of Package .................... -
Page 4: General Description
GENERAL DESCRIPTION ATTENTION Before installing the salt water chlorinator, please read this manual carefully. If you need to clarify any point or have any doubts, please contact your dealer. Posi-Chlor® Thank you for purchasing the salt water chlorinator, which will enable you to enjoy your swimming pool in perfect conditions, without the need to add any chemical disinfectants. -
Page 5: Product Range
1. GENERAL DESCRIPTION Product range You will find various models within our range, depending on its production and features. Posi-Chlor® BASIC 1.1.1 • Chlorine production from 15 to 35g/h. • Advanced features and data display through an LCD screen. • Adjustable output. -
Page 6: Recommendations And Safety Precautions
1. GENERAL DESCRIPTION Common features in all Posi-Chlor® equipment 1.2.1 • Adjustment of chlorine production by switched mode power supply • Power supply performance >90% • Automatic switch-off owing to lack of water flow. • Automatic switch-off owing to the accumulation of gas in the cell, with automatic restart once the water flow is restored. -
Page 7: Preparing The Swimming Pool
PREPARING THE SWIMMING POOL Adding salt to the water To ensure that the chlorinator works correctly, a small amount of salt should be added and the pH level should be suitable. The recommended salt and pH levels are the following: Salt Concentration Salt Concentration (Range) -
Page 8: Chemical Balance Of The Water
2. PREPARING THE SWIMMING POOL Chemical balance of the water The effectiveness of chlorination and the quality of water for healthy bathing, depends largely on the pH of the water. Therefore, it should be checked regularly and adjusted as necessary. There are other parameters which should be considered for the correct operation of the salt water chlorinator. -
Page 9: Installation Of The Equipment
INSTALLATION OF THE EQUIPMENT Contents of Package 3.1.1 Posi-Chlor Basic Kit The pH Kit or pH/ORP kit can be added to any Posi-Chlor® series basic unit. The following figures show the parts of the Basic kit. 3.1.2 Posi-Chlor pH Kit The Auto pH/ORP kit can be added to any Posi-Chlor®... - Page 10 3. INSTALLATION OF THE EQUIPMENT 3.1.3 Posi-Chlor Auto pH/ORP Kit 3.1.4 Parts 1. Posi-Chlor® Control Centre 2. Electrolysis Cell 3. Peristaltic Pump (For Acid Delivery) 4. Suction Tube (Flexible) 5. Injection Tube (Rigid). 6. Saddle Clamp (For Acid Delivery). 7. Suction filter (place vertically on the bottom of the acid container) 8.
-
Page 11: Installation Of Electrolysis Cell
3. INSTALLATION OF THE EQUIPMENT Installation of Electrolysis Cell • Place the chlorine cell in a vertical position with electrical connections on the top. If this is not possible, it can be assembled in a horizontal position, with the addition of the optional flow switch. -
Page 12: Mounting Of The Control Centre
3. INSTALLATION OF THE EQUIPMENT Mounting of the Control Centre • It is highly recommended that the control centre unit be installed where it is protected from the elements. Although inherently protected from rain (IP rated), continued expo- sure to rain and sunlight will accelerate the aging of the unit. •... -
Page 13: Advanced Kit (Ph/Orp)
3. INSTALLATION OF THE EQUIPMENT 2. When the saddle clamp is in position, drill a hole in the PVC pipe. Using the threaded port as a guide. Use a 10mm drill bit, careful not to touch the threads. 3. Connect one end of the suction tube (4) to the peristaltic pump (3) inlet. 4. -
Page 14: Hydraulic Connection Diagram
3. INSTALLATION OF THE EQUIPMENT Hydraulic Connection Diagram 3.6.1 Basic Unit, No Heater Backwash to sewer To pool returns From pool skimmer / main drain 3.6.2 Basic Unit, With Heater Check-valve To pool returns From pool skimmer / main drain Backwash to sewer Posi-Chlor®... - Page 15 3. INSTALLATION OF THE EQUIPMENT 3.6.3 Advanced Unit, No Heater Dosing Pump Sensor Sensor Backwash Acid to sewer Injection To pool returns From pool Pool skimmer / Acid main drain 3.6.4 Advanced Unit, With Heater Dosing Pump Check-valve Sensor Sensor Acid Injection To pool...
-
Page 16: Electrical Wiring Diagram
3. INSTALLATION OF THE EQUIPMENT Electrical wiring diagram 1 3 5 7 9 11 13 2 4 6 8 10 12 14 CELL L SW1 SW2 pH1 pH2 RLY OUT FILTER Terminal Description Notes Earth Earth Connections Pre-wired in factory. N, L 230-240VAC Supply Pre-wired in factory. - Page 17 3. INSTALLATION OF THE EQUIPMENT Terminal Description Notes RELAY OUT Filter Pump Output (230VAC) Pre-wired in factory. FILTER Not Used in Australian Version Pre-wired in factory. 1 & 2 Acid level sensor Not Used. Connection from pool cover control 3 & 4 Pool cover input (optional).
-
Page 18: Start-Up And Adjustments
START-UP AND ADJUSTMENTS Display and Control Once the Posi-Chlor® salt water chlorinator has been installed, you can start up your salt water chlorination equipment. Follow the instructions carefully. The following sections detail the operation of different models. 4.1.1 Display and Main Screen The Posi-Chlor®... - Page 19 4. START-UP AND ADJUSTMENTS Description Notes Alarm Light Will flash when there is an alarm condition. It may also flashes briefly during menu selections. LCD Screen For setting and displaying parameters. Also see a-j. Up and Down Buttons Used for navigating the menu's and altering values. OK Button Entering Menu.
-
Page 20: Main Menu
4. START-UP AND ADJUSTMENTS Main Menu The following table shows how to organise the configuration menu of the equipment: Main Menu Sub Menu Default Notes Language English Use to change display language. Control Manual (Basic & pH). Auto (Adv. pH/ORP). Cleaning 6 Hours Use to select cleaning... -
Page 21: Configuration
4. START-UP AND ADJUSTMENTS Main Menu Sub Menu Default Notes On/Off pH On (pH/ORP units) Turns on/off pH control Filter Pump On/Off Turn filter pump on manually Program 1 0:00-0:00 Set single daily program Program 2 0:00-0:00 Set dual daily programs Program Off Deactivate programs Timer... - Page 22 4. START-UP AND ADJUSTMENTS �Outdoors Cover Flow Switch Acid � Alkali � Alarm: pH Y � Alarm: Chlorine N �Buzzer Exit ATTENTION: A password will be required when trying to change some options of this menu, to avoid an involuntary change of some parameter that could affect to the right behaviour of the unit.
- Page 23 4. START-UP AND ADJUSTMENTS Semi-automatic Select this mode only if you have a temperature probe kit (optional). If you do not have one, the equipment will not operate correctly in the semi-automatic mode. This work mode enables you to determine the daily hours of operation of the salt water chlorinator based on the volume in m3 of the pool and the water temperature.
- Page 24 4. START-UP AND ADJUSTMENTS 4.3.6 Cover The equipment may detect the presence of a cover on the swimming pool (only for auto- matic covers). In this case, it is only necessary to place the limit switch of the cover in the terminal block, as indicated in the section on electrical installation.
- Page 25 4. START-UP AND ADJUSTMENTS If the cell is installed horizontally instead of vertically, the flow switch must be used. In the horizontal installation, gas may escape preventing the gas sensor from functioning. In the vertical installation of the cell, the gas sensor will function to shut off chlorine production in the event of a pump malfunction and as such the flow switch is not necessary.
-
Page 26: Chlorine Menu
4. START-UP AND ADJUSTMENTS 4.3.11 Buzzer When an alarm occurs, the unit stops its production and shows an acoustic and visual alarm to indicate that it’s necessary to correct the problem. However, it is possible to configure the acoustic signal with the following options: •... -
Page 27: Ph Menu (Advanced)
4. START-UP AND ADJUSTMENTS NOTE: if working in automatic, you can also adjust the production percentage from 0% to 100%, On connecting the equipment in automatic mode, the ORP value will flash for 5 min before the equipment starts to produce chlorine. 4.4.3 Super chlorination Select this option if you require super-chlorination of your swimming pool, bearing in mind... - Page 28 4. START-UP AND ADJUSTMENTS pH cal. = 7 pH = 7.05 -2 mV 32 s A 60 seconds countdown will start (remaining time is shown on the 3rd line). Keep the probe in the solution until it finishes. When the countdown is finished, you will be asked to use the pH4 solution.
-
Page 29: Ph Menu (Predictive Algorithm)
4. START-UP AND ADJUSTMENTS pH adjustment does not start up until 5 minutes after the equipment has been switched A proportional control automatically adjusts the pH without the need for controller adjustments. The pump will start up every minute and with a variable operation time of between 0 and 60 seconds. -
Page 30: Filter Pump
4. START-UP AND ADJUSTMENTS 4.6.3 Dose You can increase or decrease the acid amount you’re dosing. Default (100% is the result of the theoretical formula, but you can adjust from 50% to 150%) 4.6.4 pH On/OFF ON/OFF to enable/disable the pH control Filter Pump The Posi-Chlor series chlorinators have a programmable filter pump relay that can be used to control the filtering pump. -
Page 31: Time
4. START-UP AND ADJUSTMENTS 4.7.3 Program (2/24h) This allows two individual daily programs. Press the OK button to save the value and move to the next. After the last option is saved, it will automatically exit this menu and this option will be selected. -
Page 32: Troubleshooting
TROUBLESHOOTING Warning messages and alarms In the event of abnormal operation, the Posi-Chlor® will display an alarm message on the 4th line of the screen, together with an acoustic warning. The alarms shut-down the equipment until the problem is solved. Similarly, it will display a warning also in the 4th line, but without an acoustic signal or shut- ting down the equipment. - Page 33 5. TROUBLESHOOTING 5.1.2 Additional Warning Messages Message: Causes: Action required: The ORP or free chlorine probe are balanced in automatic ORP or PPM value is flashing None. mode. When the probe is balanced, the value remains set. The pH probe is balancing. pH value is flashing When the probe is balanced, the None.
- Page 34 5. TROUBLESHOOTING Message Causes Action Required Check the cell connection Cell is incorrectly and ensure that cables and connected. connection terminals are in good condition. Check the condition of the "OPEN CIRCUIT" Cell is damaged or cell electrodes, and replace completely worn down.
-
Page 35: Operation Time
5. TROUBLESHOOTING Operation time It may be useful to see the operation times for regular maintenance operations. From the main screen, press both buttons at the same time. Electrolysis cell life The electrolysis cells from our units are designed to reach a lifespan of 10.000 hours. However, this lifespan is directly related with the quality of the water and specially with the correct use of the equipment. -
Page 36: Maintenance
MAINTENANCE Carefully follow the recommendations and safety warnings detailed in section 1.4 of this manual. The chlorinator has a self-cleaning system of the chlorination cell, which reduces maintenance considerably. In any event, it is advisable to clean the cell and check the chlorine (ORP), free chlorine or pH probe if available. -
Page 37: Checking And Maintenance Of The Ph Probe
6. MAINTENANCE Recheck the value of the probe. A probe that gives an error lower than around 30 mV can continue to be used provisionally while it is replaced. Never leave the probe outside. If the probe has been dry for a time, it can be regenerated with the hydrochloric acid solution. -
Page 38: Spare Parts
SPARE PARTS Power Center Spares Ref: Part No.: Description: Ref: Part No.: Description: 811010 Keypad 811014 Gasket Screw - See cover 811015 Switch 811011 Cover Base cabinet Hinge - See cover 811012 PCB - Contol Heat sink 811013 PCB - Power 811016 Power center complete Cable entry gland... -
Page 39: Electrolysis Cell Spares
For full terms and conditions, please refer to the Pentair Warranty Schedule. It is important to bear in mind that all repairs are performed by Pentair or by an authorized Pentair Service Agent. - Page 40 1-21 Monash Drive | Dandenong South, VIC 3175 | Australia | 1300 137 344 | pentairpool.com.au Information contained here-in remains the property of Pentair under Australian copyright law. Content may not be reproduced or transmitted without our prior written permission.
