Predator™ II Cellular Media Filter
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
Attention Installer.
This manual contains important information about the installation, operation and safe use of
this product. This information should be given to the owner/operator of this equipment.
Before installing this product, read and follow all warning notices and instructions accompanying this
filter. Failure to follow safety warnings and instructions can result in severe injury, death, or property
damage. Call (800) 831-7133 for additional free copies of this manual.
Pentair Pool Products
1620 Hawkins Ave., Sanford, NC 27330 • (919)
10951 West Los Angeles Ave., Moorpark, CA 93021 • (805) 5
REV.C 4-3-12
System Kit Owners Manual
SAVE THESE INSTRUCTIONS
Important Notice
WARNING
1
®
P/N 99226200
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pentair Predator II
Summary of Contents for Pentair Predator II
- Page 1 Before installing this product, read and follow all warning notices and instructions accompanying this filter. Failure to follow safety warnings and instructions can result in severe injury, death, or property damage. Call (800) 831-7133 for additional free copies of this manual. Pentair Pool Products 1620 Hawkins Ave., Sanford, NC 27330 • (919) ®...
-
Page 2: Table Of Contents
Table of Contents SECTION I. PUMP SAFETY INSTRUCTIONS ................2 SECTION II. HOW YOUR FILTER WORKS ..................3 SECTION III. INSTALLATION ......................4 SECTION IV. INITIAL START-UP AND RESTART INSTRUCTIONS ..........5 SECTION V. CLEANING FILTER....................6 SECTION VI. WINTERIZING THE FILTER ..................7 SECTION VII. TROUBLE SHOOTING ....................8 SECTION VIII. -
Page 3: How Your Filter Works
WARNING THIS FILTER OPERATES UNDER HIGH PRESSURE. WHEN ANY PART OF THE CIRCULATING SYSTEM (e.g., LOCK RING, PUMP, FILTER, VALVES, ETC.) IS SERVICED, AIR CAN ENTER THE SYSTEM AND BECOME PRESSURIZED. PRESSURIZED AIR CAN CAUSE THE LID TO BE BLOWN OFF WHICH CAN RESULT IN SEVERE INJURY, DEATH, OR PROPERTY DAMAGE. -
Page 4: Installation
The filter’s function is to remove suspended matter from the water, but it does not sanitize the water. For sparkling clear water, the water must be sanitized as well as balanced. Pool chemistry is a specialized area, and you should consult your local pool service specialist for specific details. In general, proper pool sanita- tion requires a free chlorine level of 1 to 2 PPM and a PH range of 7.2 to 7.6. -
Page 5: Initial Start-Up And Restart Instructions
WARNING This filter operates under high pressure. When any part of the circulating system (e.g., lock ring, pump, filter, valves, etc.) is serviced, air can enter the system and become pressur- ized. Pressurized air can cause the lid to be blown off which can result in severe injury, death, or property damage. -
Page 6: Cleaning Filter
Your filter has now started its filter cycle. You should check that the water is returning to the pool. Check the system for water leaks. If a leak is found, shut off pump before correcting the leak. As the filter removes the dirt and impurities from the pool water, the accumulation will cause the filter flow to diminish. -
Page 7: Winterizing The Filter
WARNING If the filter lock ring is damaged, replace it immediately. This filter operates under high pressure. Replace locking ring if damaged or worn. Failure to replace locking ring can result in the lid separating from the filter which can cause severe injury or death. -
Page 8: Trouble Shooting
SECTION VII. TROUBLE SHOOTING Problem Cause Remedy Pool water not 1. Pool chemistry not adequate to inhibit Maintain pool chemistry or consult pool serv- sufficiently clean algae growth. ice technician. 2. Inadequate turnover rate. Run system for longer time or consult dealer or pool service technician. - Page 9 CAUTION DO NOT RUN PUMP DRY. If the pump is run dry, the mechanical seal will be damaged and external leak- age will occur. When a seal is damaged, the seal must be replaced. CAUTION ALWAYS MAINTAIN PROPER WATER LEVEL IN THE POOL. Water level must be half way up the skimmer opening.
-
Page 10: Technical Data
SECTION IX. TECHNICAL DATA A. FILTER AND TANK Replacement Parts Find Part Description Qty. 56208500 Air relief valve 56208100 85004500 Hose adapter 59019800 Pump connector 39102800 O-ring 56208600 O-ring 56208300 Cartridge 56208700 Body 56208400 Drain Plug 155153 Flexible Hose 1.5” 711004 Hose Clamp 98105700... - Page 11 B. PUMP Part number 351233 - Dynamo Pump 3/4 HP, 1 speed with on/off switch. Electrical Specifications: Branch Circuit: 15 Amps. Volts: 115. HZ: 60. Phase: 1. Dynamo Pump Replacement Parts for Predator II System Item Part No. Description Qty.
- Page 12 SAVE THESE INSTRUCTIONS Pentair Pool Products 1620 Hawkins Ave., Sanford, NC 27330 • (919) ® 10951 West Los Angeles Ave., Moorpark, CA 93021 • (805) 5 3- 00 REV.C 4/3/12 P/N 99226200...
