- Page 1 MANUAL ENGLISH Edison Dot E1 Ordercode: 30747 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Edison Dot E1 Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Return Procedure ................................6 Claims ....................................6 Description of the device ..............................7 Front ....................................7 Back ....................................8 Installation ................................... 8 Setup and Operation ................................ -
Page 3: Warning
Edison Dot E1 Warning Unpacking Instructions Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure that all parts are present, and have been received in good condition. Notify the dealer immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling. - Page 4 Edison Dot E1 IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorized modification to the device. ● Never let the power cord come into contact with other cables! Handle the power cord and all connections with the mains with particular caution! ●...
-
Page 5: Operating Determinations
Edison Dot E1 Operating Determinations ● This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. ● The minimum distance between light output and the illuminated surface must be bigger than 1 meter. - Page 6 Edison Dot E1 The Edison can be mounted to any kind of truss with quick locks and a clamp. Improper installation can cause serious injuries and/or damage of property! Connection with the mains Connect the device to the mains with the power-plug. Always check if the right color cable is connected to the right place.
-
Page 7: Return Procedure
Edison Dot E1 Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.com and request an RMA prior to shipping the... -
Page 8: Description Of The Device
Edison Dot E1 Description of the device Features The Edison Dot E1 is a light effect with high output. ● Input voltage: 230 V AC, 50 Hz ● Power consumption: 30 W ● Light source: 1 x LED bulb (not included); Use only dimmable LED bulbs. ●... -
Page 9: Back
Edison Dot E1 Back Fig. 02 04) Built-in microphone 05) LCD display + control buttons 06) LED power indicator 07) LED DMX indicator 08) 3-pin DMX signal connector IN 09) Safety eye 10) 3-pin DMX signal connector OUT 11) Fuse T1AL/250V 12) Power switch ON/OFF 13) 230 V pro power connector IN (Blue) 14) 230 V pro power connector OUT (Gray) -
Page 10: Installing The Lamp
Edison Dot E1 Installing the Lamp The Showtec Edison Dot E1 uses the following LED bulbs: 83260 – LED Filament Bulb E27 (4 W) 83271 – LED Filament Bulb T9, Straight Filament (185 mm) 83261 – LED Filament Bulb E27 (5 W) 83275 –... -
Page 11: Control Modes
Edison Dot E1 Control Modes There are 5 modes: ● Auto ● Manual ● Sound-controlled ● Master/Slave ● DMX-512 (1CH) One Edison (Auto and Manual) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). -
Page 12: Multiple Edisons (Dmx Control)
Edison Dot E1 Multiple Edisons (DMX Control) 01) Fasten the effect light to a firm trussing or mount it on flat surface. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 3-pin DMX cable to connect the Edison and other devices. -
Page 13: Fixture Linking
Edison Dot E1 Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support. -
Page 14: Control Panel
Edison Dot E1 The Edison Dot E1 can be operated with a controller in control mode or without the controller in stand- alone mode. Control Panel A) LCD display MENU button C) UP button D) DOWN button ENTER button Fig. 06 Control Mode The fixtures are individually addressed on a data-link and connected to the controller. -
Page 15: Menu Overview
Edison Dot E1 Menu Overview Main Menu Options Upon start-up, the device will show the current software version After 10 seconds, the display will show the main menu. Run Mode DMX Fail Reset DMX Addressing 1. Run Mode In this menu you can set the desired operation mode. 01) In main menu, press the MENU button until the display shows 02) Press the ENTER button to open the menu. -
Page 16: Sound-Controlled Mode
Edison Dot E1 1.2. Sound-controlled Mode In this menu the device will react to the beat of the background music. 01) Press the UP/DOWN buttons to choose one of the 16 sound-controlled programs. 02) Press the ENTER button to confirm your choice. 03) The device will now react to the beat of the background music by means of the built-in microphone. -
Page 17: Dmx Addressing
Edison Dot E1 4. DMX Addressing In this menu you can set the DMX address. 01) In main menu, press the MENU button until the display shows 02) Press the ENTER button to open the menu. 03) Press the UP/DOWN buttons to select the required address. The adjustment range is 001–512. 04) Press the ENTER button to save changes. -
Page 18: Troubleshooting
Edison Dot E1 Troubleshooting This troubleshooting guide is meant to help solve simple problems. If a problem occurs, carry out the steps below in sequence until a solution is found. Once the unit operates properly, do not carry out following steps. No Light If the light effect does not operate properly, refer servicing to a technician. -
Page 19: Product Specifications
Edison Dot E1 Product Specifications Model: Showtec Edison Dot E1 Input voltage: 230 V AC, 50 Hz Power consumption: 30 W Fuse: T1AL/250V Dimensions: 185 x 160 x 168 mm (LxWxH) Weight: 1,4 kg Electro-mechanical effects: Light source: 1 x LED bulb (not included); Use only dimmable LED bulbs. -
Page 20: Dimensions
Edison Dot E1 Dimensions Ordercode: 30747... -
Page 21: Notes
Edison Dot E1 Notes Ordercode: 30747... - Page 22 Edison Dot E1 Ordercode: 30747...
- Page 23 Edison Dot E1 Ordercode: 30747...
- Page 24 ©2019 Showtec...
