Theben TIME GUARD Programstat TRT034 Operating & Installation Instructions Manual page 6

flash. Press the butons to get the required
day for programming, then press select and this
day can be programmed as Monday above.
Complete all 7 days in the same manner. If set is
then pressed twice the TRT034 will return to
operating mode.
This defaults to permanently off – refer to "Setting
the operating mode" to get into timed mode.
Weekday/weekend (5-2) programming
on/off times
For 5-2 day mode, time periods will need to be
programmed for M-F (Mon-Fri) and then for S-S
(sat-sun). Only 2 sets of times need to be
programmed, not 7.
Setting the operating mode
Once programmed, the default mode is
'continuously off'. To enter programmed mode,
press the advance/mode button. One press changes
the output to 'continuously on', two presses changes
to 'programmed', and three presses changes to
'advance to next programme'. In advance mode,
once the next time period has past, the programmer
returns to programmed mode.
Omitting days and programmes
Days can be omitted by entering the same time in
each of the 3 on/off programmes for that day.
In 5-2 day mode the weekend can be omitted by
using the same technique for the 2 day (Sat &
Sun) programmes.
A programme (usually P2) can also be omitted
for a given day by making the P2 on and off times
the same. This can also be applied to P1 and P3
if required.
Boost
In operating mode, there is a boost facility
for between 1 and 9 hours in one hour steps.
Press the boost button the required number of
times for the number of hours of boost required.
The programmer returns to operating mode
15 seconds after the last button push. To cancel
boost, press the boost button until 0 hours is shown.
Press and hold the light button and the
programmer will enter holiday mode. Use the
buttons to set the required number of days.
The programmer will return to operating mode
15 seconds after the last button push. To exit holiday
mode, press and hold the light button again.
Screen illumination
Press the light button briefly at anytime,
and the screen will illuminate for 15 seconds.
To clean use a clean dry cloth only. Do not use
any liquid cleaners.
5. Specifications
Current rating: 3 (1) A
Voltage: 230V, 50Hz
Switch type: Single pole, double throw
(SPDT)
Operating
temperature
range: 0ºC to 50ºC
Complies with: BS EN 60730
Conforms to
directives: Conforms to latest directives
Micro
disconnection: Type 1.B control action
