This unit is double insulated, and hence does
not need connection to earth. If earth continuity
is required, please use earth terminal on wall plate.
To reinstall the unit on the wall plate hook the top
of the unit over the retaining tabs, and push firmly
back. There will be some resistance from the terminals.
Once in place, secure with the retaining screws.
Restore mains to the unit after checking all system
wiring is complete.
4. Operation
Decide whether weekday/weekend (5-2) or
individual (7) day programming is required, and move
the jumper on the rear of the product (see Fig. 2).
It is important to make this decision first, as after
any change of jumper position, reset needs to be
pressed, which will return the unit to default time
and programme.
Reset
When programming a new unit or one that has
been disconnected from the mains for more than
24 hours, open the program access flap and press
the reset button (see Fig. 1a) using a pen or
similar implement which will clear the memory.
All of the screen segments will show briefly, and
then the default programme will be displayed.
Setting time and date
To programme the current time and date,
simultaneously press and hold both the select
and set buttons for 3 seconds.
The option 12 hour or 24 hour is displayed and
needs to be set. Use the up and down
buttons to select the required mode.
Press select to move to setting the hours.
Use the up and down buttons
the hour, and press select to set the minutes.
Again use the up and down buttons
the minutes, and then select to set the year (y),
the month (m), the day (d), and automatic
summer/winter time change or daylight saving
(dls) on/off, in each case using the up and down
buttons . Once the time and date have been
set, press set to exit back to the operating mode.
If at any time a button is not pressed for
15 seconds, the unit will return to operating mode.
Individual (7 day) programming on/off times
The default on/off times are as follows:
6:00 AM on
8:00 AM off
10:00 PM on
12:00 PM off
6:00 PM on
10:00 PM off
These apply to every day independent of whether
weekday/weekend (5-2) or individual (7) day
option is chosen.
Note: to omit days and programmes please refer
to "Omitting days and programmes"
To change from default values, proceed as follows:
Press set and MON will flash (with programme (P)
1 on time displayed). Press select and P1 on hour
to set
digit(s) will flash, use
required hours.
to set
Press select and P1 on minute digits will flash,
use buttons to get the required minutes.
Press select and P1 off hour digits will flash,
use buttons to get the required hours.
Press select and P1 off minute digits will flash,
use buttons to get the required minutes.
Press select and programme (P) 2 on hour digit(s)
will flash, use
hours.
Press select and programme (P) 2 on minute digit(s)
will flash, use
minutes. This procedure of alternatively using
select and
programmes P2 and P3.
Once complete the second day can be started by
pressing the set button when MON will begin to
buttons to get the
buttons to get the required
buttons to get the required
can be continued to set
