- Page 1 Instruction manual for ceiling hoods Model code: CE1500 Model code: CE1100 Model code: CE1105 Model code: CE900 Contact Caple on 0844 800 3830 or for spare parts www.4caple.co.uk...
- Page 3 CONTENTS Warnings Uses Installation Working Maintenance...
- Page 4 The cooker hood, when evacuating the sucked air, could generate a negative pressure in the room- which can’t exceed the limit of 0.04 CE1500 - CE1100 - CE1105 - CE900 with mbar, in order to avoid the suck of exhausts external motors manufactured by the same deriving from the heat-source.
- Page 5 - Use piping approved by standards in force. CE900: 865x405 mm with a minimum di- stance of 270 mm between the ceiling and the false ceiling; It is possible to select the side of the hood where the air suctioned can be discharged.
- Page 6 Make the electrical connections and connect WORKING the air outlet pipe; place the ceiling-mounted hood into the niche, by inserting the threaded bars into the holes (Fig.6); the outer edge of the hood needs to be perfectly flush with the false ceiling.
- Page 7 Refit the panel and the screws previously re- moved. To replace led strip (CE900) Using an appropriate tool, remove the LED bar from its seat (refer to fig. 15), discon- nect it electronically using the appropriate connector then substitute it with a LED bar with same characteristics.
