- Page 1 50L AIR COMPRESSOR MODEL NO: RANGER 8/50 PART NO: 2242025 OPERATION & MAINTENANCE INSTRUCTIONS GC0522 - ISS 4 ORIGINAL INSTRUCTIONS...
-
Page 2: Environmental Recycling Policy
INTRODUCTION Thank you for purchasing this CLARKE 50L Air Compressor. Read this manual fully before use and follow the instructions carefully. In doing so you will ensure the safety of yourself and those around you and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: Safety Precautions
2. DO NOT operate your compressor with the guard removed. 3. Repairs must only be carried out by a qualified engineer. If problems occur, contact your nearest Clarke dealer. 4. Before carrying out any maintenance, make sure that the pressure is released from the air tank and that the compressor is disconnected from the electrical supply. -
Page 4: Safety Symbols
17. Make sure that any equipment or tool used in conjunction with your compressor has a safe working pressure exceeding that of the compressor. 18. Be careful when transporting the compressor to prevent tipping over 19. Permanently installed systems must be installed by a competent engineer. 20. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch. If the plug has to be changed because it is not suitable for your socket, or because of damage, it must be removed and a replacement fitted, following the wiring instructions shown below. -
Page 6: Attach The Wheels
ASSEMBLY ATTACH THE WHEELS Use a spanner to attach the wheels to the compressor. Use the washers and spring washer in the positions shown. ATTACH THE FEET Insert the feet into the position shown. ATTACH THE AIR FILTER 1. Screw the air filter into position. •... -
Page 7: Install The Oil Filler Cap
INSTALL THE OIL FILLER CAP 1. Remove the travel plug. 2. Insert the oil breather cap. MOVING THE AIR COMPRESSOR CAUTION: THE COMPRESSOR IS HEAVY AND REQUIRES TWO PEOPLE TO LIFT SAFELY. • Stop the compressor and disconnect it from the power supply before you move it. -
Page 8: Before Use
2. If not, remove the oil cap and add oil to the tank. • Only use SAE30 compressor oil, available from your Clarke dealer. • Only fill to the half way point on the sight glass, Overfilling may result in damage. -
Page 9: Operation
OPERATION If the compressor has not been used for more than 24 hours, open the drain valve on the bottom of the tank and drain any condensate which has collected. See page 11. ATTACHING AIR TOOLS WARNING: BEFORE CONNECTING AIR TOOLS, MAKE SURE THAT YOU READ THE INSTRUCTIONS SUPPLIED WITH THE TOOL, ALSO ENSURE THAT THE TOOL IS SUITABLE FOR USE WITH THE COMPRESSOR AND HOSE SPECIFICATIONS. -
Page 10: Set The Output Pressure
SET THE OUTPUT PRESSURE 1. Use the pressure regulator to set the output pressure of the outlet valves. • Turn clockwise to increase the pressure. • Turn counterclockwise to decrease the pressure. GAUGES 1. The tank pressure gauge shows the current pressure in the tank. 2. -
Page 11: Turn The Compressor Off
2. Turn the outlet valve handle to the closed position. 3. Operate the tool to depressurise the air hose. 4. Disconnect the tool from the hose. TURN THE COMPRESSOR OFF 1. Follow steps 1-3 above. 2. Disconnect the compressor from the power supply. -
Page 12: Reset Button
If you start the compressor and the overload cutout operates again, stop the compressor and disconnect from the power supply and have your compressor examined by a Clarke service agent. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 13: Maintenance
2. If not, remove the oil breather cap and add oil to the reservoir. • Only use SAE30 compressor oil, available from your Clarke dealer. DRAIN THE TANK (DAILY) After use, always open the drain valve to make sure that any condensate is drained off. -
Page 14: Check The Non-Return Valve (Every 6 Months)
CHECK THE NON-RETURN VALVE (EVERY 6 MONTHS) If the tank pressure decreases for no apparent reason, it is possible that the non-return valve is leaking. To check, 1. Make sure that the tank is not under pressure and the compressor is switched OFF. 2. -
Page 15: Specifications
SPECIFICATIONS Max Pressure 8 Bar / 116PSI Voltage 230 VAC (50Hz) Output Power 1491W Air Displacement 7 CFM Receiver Capacity 50 L Fuse Rating 13 A Dimensions (L x W x H) 725 x 380 x 650 mm Guaranteed Sound Power Level 96 dB(A) Weight 30 kg... -
Page 16: Troubleshooting
1. Switch off and wait approx has tripped. 5 minutes. 2. Press the reset button and switch on again. Motor windings burnt out. 1. Contact your Clarke dealer for a replacement motor. Compressor Compressor head gasket 1. Return the compressor to does not reach blown or valve broken. -
Page 17: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 18: Parts List
PARTS LIST CRANKCASE BEARING SEAT CRANKSHAFT WAVE GASKET OILSEAL GASKET STATOR FRONT COVER BALL BEARING OIL DRAIN PLUG ROTOR OIL SIGHTGLASS SEAL BALL BEARING OIL SIGHTGLASS OIL SEAL BOLT OVERLOAD PROTECTOR BREATHER TANK SCREW HOLE PLUG CONNECTING ROD RETAINING RING SPRING WASHER PISTON PIN FLAT WASHER... -
Page 19: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
