Controls

2 Controls
136 365
364
135
295
8.1 System Pressure gauge
Reset button
61
135 Master switch
136 Central heating temperature control
170 Service valves in CH flow and return
171 Hot water
172 Gas isolation valve (open)
173 Cold water inlet
295 Identification sticker
310 Hot water temperature control (RD 532)
317 Display
363 Indicator lamp for "burner on"
364 Indicator lamp for "off/on"
365 "Chimney sweep" button
366 Service button
367 "ECO" button
422 Optional timer
10
61
317 366 367
E
170
171
363 310 422
ECO
CH
C
172 173 170
6 720 610 600-01.1O
6 720 610 600 GB (03.06)
8.1
