Benchmark PulsaCoil A-Class 145 Design, Installation And Servicing Instructions

A mains pressure hot water supply system incorporating an off peak electric thermal store

Hide thumbs Also See for PulsaCoil A-Class 145:

Design, installation and servicing instructions (32 pages)

Table Of Contents

Table of Contents

Quick Links

A - C L A S S

PulsaCoil

DESIGN, INSTALLATION AND

SERVICING INSTRUCTIONS

PLEASE LEAVE THESE INSTRUCTIONS IN THE POCKET PROVIDED ON

THE BACK OF THE FRONT PANEL

Gas Council Approved Reference Numbers

PulsaCoil 145

PulsaCoil 185

PulsaCoil 215

PulsaCoil 235

benchmark

A MAINS PRESSURE HOT WATER SUPPLY

The code of practice for the installation,

SYSTEM INCORPORATING AN OFF PEAK

commissioning & servicing of central heating systems

ELECTRIC THERMAL STORE

ALL MODELS COMPLY WITH THE

WATER HEATER MANUFACTURERS

SPECIFICATION FOR THERMAL STORES

Table of Contents

Need help?

Do you have a question about the PulsaCoil A-Class 145 and is the answer not in the manual?

Questions and answers

Summary of Contents for Benchmark PulsaCoil A-Class 145

Page 1 Gas Council Approved Reference Numbers PulsaCoil 145 PulsaCoil 185 PulsaCoil 215 PulsaCoil 235 benchmark A MAINS PRESSURE HOT WATER SUPPLY The code of practice for the installation, SYSTEM INCORPORATING AN OFF PEAK commissioning & servicing of central heating systems ELECTRIC THERMAL STORE...
Page 2: Table Of Contents
BSI. The Gledhill Group’s ﬁrst priority is to give a As part of the industry wide“Benchmark”Initiative all Gledhill PulsaCoils now include high quality service to our customers. a Benchmark Installation, Commissioning and Service Record Log Book. Please read carefully and complete all sections relevant to the appliance installation.
Page 3: Introduction
1.0 DESIGN 1.1 INTRODUCTION Any water distribution system/installation must comply with the relevant recommendations of the current version of the Regulations and British Standards listed below:- Building Regulations Requirements for Electrical Installations Water Regulations Manual Handling Operations Regulations British Standards BS6700 and BS7671.
Page 4 1.0 DESIGN �� ...
Page 5: Technical Data
1.0 DESIGN 1.2 TECHNICAL DATA Technical Speciﬁcation PulsaCoil A-CLASS Model PCA145 PCA185 PCA215 PCA235 Height (mm) 1042 1142 1300 1440 Width (mm) Depth (mm) Min cupboard height (mm) 1800 1900 2050 2200 Min cupboard width (mm) Min cupboard depth (mm) Weight (empty) (kg) Weight (full) (kg) Volume of water heated by on-peak...
Page 6 1.0 DESIGN 1.2 TECHNICAL DATA Standard Equipment �� The standard conﬁguration of the PulsaCoil A-CLASS is shown opposite. The Printed Circuit Control Board (A.C.B.), mounted inside the appliance,controls the operation of the complete system. This is pre-wired to a terminal strip where all electrical connections terminate.
Page 7 1.0 DESIGN 1.2 TECHNICAL DATA �� Appliance Dimensions Height Width Depth Model PCA145 1042 PCA185 1142 PCA215 1300 PCA235 1440 Note: The Appliance dimensions above do not allow for the100mm high installation base The following table of minimum cupboard dimensions only allow the minimum space required for the appliance (including...
Page 8 1.0 DESIGN 1.2 TECHNICAL DATA �� PLAN OF APPLIANCE CONNECTIONS A-CLASS The PulsaCoil units are supplied on an installation base to allow the pipe runs to connect to the appliance from any direction.
Page 9: System Details
1.0 DESIGN 1.3 SYSTEM DETAILS Hot and Cold Water System General The hot water ﬂow rate from the PulsaCoil A schematic layout of the hot and cold water services in a typical small dwelling is A-CLASS A-CLASS is directly related to the adequacy of the shown below.
Page 10 1.0 DESIGN 1.3 SYSTEM DETAILS Hot and Cold Water System Pipe Sizing / Materials The hot water supply to a shower-mixing To achieve even distribution of the available supply of hot and cold water,it is important valve should be fed wherever practical in any mains pressure system,that the piping in a dwelling should be sized in accordance A-CLASS directly from the PulsaCoil...
Page 11 1.0 DESIGN 1.3 SYSTEM DETAILS �� ...
Page 12: Issue 1
1.0 DESIGN 1.3 SYSTEM DETAILS Electrical Installation A-CLASS The upper immersion heater is positioned at a level on the PulsaCoil to provide approximately 50 litres of hot water - seeTechnical DataTable on page 5. This is connected to the unrestricted on peak supply and is switched manually by the householder using the button provided on the front of the appliance.
Page 13: Installation
2.0 INSTALLATION 2.1 SITE REQUIREMENTS The appliance is designed to be installed in an airing/cylinder cupboard and the relevant minimum dimensions are provided in section 1.2 Technical Data. Because of the ease of installation we recommend that the cupboard construction is completed and painted before installation of the appliance.
Page 14: Installation
2.0INSTALLATION 2.2 INSTALLATION The plastic cover and protective wrapping should be removed from the appliance and the installation base (provided) placed in position. The appliance can then be lifted into position in the cupboard on top of the base and the front panel removed by unscrewing the 2 screws and lifting the door up and out, ready for connection of the pipework and...
Page 15 2.0INSTALLATION 2.2 INSTALLATION Pipework connections The position of the pipework connections is shown opposite.The exact location dimensions are listed in Section 1.2 Technical Data. All the connections are also labelled on the appliance. It is essential that the pipework is connected to the correct connection.
Page 16 2.0INSTALLATION SCALE INHIBITOR WIRE COLOUR LEGEND SENSOR LEGEND S1 & S2 Store overheat sensors BLUE Cold Water IN S1 & S2 Domestic Hot Water OUT BROWN Bottom Immersion Heater BLACK ORANGE Top Immersion Heater YELLOW 3K3 Resistor ID_RESISTOR WHITE VIOLET GREEN / YELLOW 1.5mm²...
Page 17 2.0 INSTALLATION FRONT PANEL Red LED Push Button Neon Illuminated ON / OFF Switch (ON PEAK IMMERSION HEATER) (OFF PEAK SIGNAL) (OFF PEAK IMMERSIONHEATER) (ON PEAK SIGNAL) Pump TITLE JOB NAME GLEDHILL WATER STORAGE LTD. 'A' CLASS PULSACOIL APPLIANCE 'A' CLASS PULSACOIL APPLIANCE SYCAMORE TRADING ESTATE SQUIRES GATE LANE ELECTRICAL SCHEMATIC DRAWING...
Page 18 2.0 INSTALLATION 2.2 INSTALLATION Combined feed and open vent pipe Electrical Connection - Standard Appliance A-CLASS It is normally envisaged that the top up cistern will be located in the same cupboard The PulsaCoil is pre-wired internally, A-CLASS as the PulsaCoil appliance itself to maintain a dry roof space.
Page 19: Commissioning
ﬂow rates of 6-25l/min are being drawn. Commissioning the PulsaCoil Control System This product is covered by the‘Benchmark’ A-CLASS Once the PulsaCoil is ﬁlled with water, check the on/off switch on the front is scheme and a separate commissioning/ in the off position.
Page 20: Servicing
3.0 SERVICING 3.1 ANNUAL SERVICING Important Do’s and Don’ts A-CLASS 1. DO check the incoming mains water pressure. The preferred range of mains No annual servicing of the PulsaCoil pressure is 2 -3 bar. is necessary. 2. DO check the ﬂow rate of the incoming cold water main is adequate to meet the maximum hot and cold water simultaneous demands.
Page 21: Short Parts List
3.0 SERVICING 3.3 SHORT PARTS LIST Description Supplier & Model Part Number Stock Code PHE pump Grundfos, UPR 15-50 5950543 GT089 Plate heat exchanger (PHE) SWEP, 24 Plate heat exchanger E8T/24 GT017 Pump isolating valve - inlet & outlet Martin Orgee, 90° valve 7308123 GT135 Top immersion heater...
Page 22: Fault Finding
3.0 SERVICING 3.4 FAULT FINDING appliance control panel and printed circuit control board/display A-CLASS The PulsaCoil have been designed to be fully automatic whilst able to provide functional and diagnostic information to the householder/installer. The panel/board work in conjunction with a number of sensors (thermistors) located as shown in the diagram below.
Page 23 3.0 SERVICING 3.4 FAULT FINDING The following checks should be carried out by the installer before calling the CONTROL PANEL (on the front of the manufacturer. appliance) 1. Noise when hot water tap is opened/closed This is designed for operation by the householder and is self explanatory.
Page 24 3.0 SERVICING By pressing B1 and B2 as shown opposite the display can be moved to show the condition/ temperature the sensors are experiencing. �� The display normally flashes alternately between the sensor reference (e.g.
Page 25: Appendix A
APPENDIX A WATER SAVINGS WATER RELATED COSTS CAN BE REDUCED BY GOOD PLUMBING PRACTICE. TAPS & MIXERS 2 TAP 5, 6 OR HALF OPEN OVER 8 L/M 20 L/M Fitted with regulator Unregulated SHOWERS 4 FIXING OPTIONS FOR TAPS & MIXERS 1.
Page 26: Appendix B
APPENDIX B MANIFOLDS Two sets of manifolds are available as an optional extra. Each set comprises a separate hot and cold water manifold. Both are provided with a 22mm inlet connection t t i t i l located centrally. All outlet connections are 15mm compression.
Page 27 APPENDIX B The pressure loss through a ﬂow regulator at the designated ﬂow rate is about 1.8 bar. Therefore for the ﬂow regulator to control the ﬂow rate at pre-set level,the inlet pressure must be greater than 1.8 bar. If the inlet pressure is lower,the ﬂow rate will be correspondingly less than the pre-set values.
Page 28 APPENDIX B The size of the distribution pipes supplying the manifold should be calculated using the method set out in BS 6700. A typical diagrammatic arrangement of a system using Manifold Type 1 is shown below. This is only meant to show the principles involved and the actual connection of ﬁttings to the manifold will need to suit the arrangements shown on page 35.
Page 29: Appendix C
APPENDIX C �� ...
Page 30: Terms & Conditions
�� ...
Page 31 �� ...
