Sentinel
Kinetic MVHR with
Cooker Hood & SELV
Transformer
User, Installation, Commissioning &
Servicing Instructions
Read in conjunction with Sentinel Kinetic MVHR Installation &
Commissioning and Operation & Monitoring Documents
PLEASE RETAIN THESE INSTRUCTIONS WITH THE PRODUCT.
Stock Ref. N°
477003 Kinetic CWHL SELV
477004 Kinetic CSHL SELV
477005 Kinetic CWHR SELV
477006 Kinetic CSHR SELV
Copyright © 2009 Vent-Axia Limited. All rights reserved.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vent-Axia Sentinel Kinetic CWHL SELV
Summary of Contents for Vent-Axia Sentinel Kinetic CWHL SELV
- Page 1 477004 Kinetic CSHL SELV 477005 Kinetic CWHR SELV 477006 Kinetic CSHR SELV Read in conjunction with Sentinel Kinetic MVHR Installation & Commissioning and Operation & Monitoring Documents PLEASE RETAIN THESE INSTRUCTIONS WITH THE PRODUCT. Copyright © 2009 Vent-Axia Limited. All rights reserved.
- Page 2 Safety Information IMPORTANT PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE COMMENCING INSTALLATION. READ THE SAFETY INSTRUCTIONS ON PAGE 2 OF THE SENTINEL KINETIC MVHR INSTALLATION & COMMISSIONING AND OPERATION & MONITORING DOCUMENTS IF THE EXTRACTOR HOOD IS INSTALLED IN A ROOM CONTAINING A FUEL-BURNING APPLIANCE, THE INSTALLER MUST ENSURE THAT AIR REPLACEMENT IS ADEQUATE FOR BOTH THE EXTRACTOR HOOD FAN...
-
Page 3: Table Of Contents
About this Document Contents UK Building Regulations (Part F) Product Description Declaration of Conformance Sentinel Kinetic MVHR with Cooker Hood ........4 User Information................5 The Sentinel Kinetic conforms to the 2010 Building Regulations (Part F - Means of Ventilation requirements) Technical Specification for installed performance of a ducted mechanical extract Sentinel Kinetic with Cooker Hood Technical Specification ... -
Page 4: Product Description
Product Description Sentinel Kinetic MVHR with Cooker Hood The Vent-Axia Sentinel Kinetic Mechanical Ventilation Heat Recovery (MVHR) unit is a heat recovery unit with a Cooker Hood designed for the energy efficient ventilation of houses and similar dwellings, conforming to the latest requirements of the Building Regulations document F 2010. -
Page 5: User Information
CO sensor, manual switches and pull cords. For these alternative control options, see www.vent-axia.com User Information Operation of Cooker Hood The unit is operated in boost mode when the telescopic hood is pulled out. Close it to return the unit to its Normal Flow Rate. -
Page 6: Technical Specification
Refer to Sentinel Kinetic Installation & Commissioning Document page 5 Flow for cooker hood adjustable using the integral damper. Sound levels (@ 3 m) 20 dB(A) (normal), 36 dB(A) (boost). Detailed sound spectra available from Vent-Axia. Power AC Voltage Input 220-240 V AC (single phase) - Page 7 Technical Specification Figure 2: Sentinel Kinetic with Cooker Hood Dimensions Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning...
- Page 8 Figure 3: Sentinel Kinetic with RIGHT HAND Cooker Hood Dimensions Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning...
- Page 9 Figure 4: Sentinel Kinetic with LEFT HAND Cooker Hood Dimensions Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning...
- Page 10 Wiring Connections Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning...
-
Page 11: Installation
Installation Installation Overview The following instructions are intended to help prevent potential hazards and should be carried out only by a qualified electrician and installer. Before Installing the Unit Inspect the Unit When taking delivery of the unit, check the items delivered against the delivery note. Inspect the unit for damage in transit. -
Page 12: Fitting The Cooker Hood To The Metal Duct Unit
Installation Condensate Horizontal Discharge Installation To install the condensate horizontal outlet refer to Sentinel Kinetic Installation & Commissioning document page 15. Spigot Installation See Sentinel Kinetic Installation & Commissioning document page 17. Note, only vertical spigots can be used on this product. - Page 13 Installation Wall Mounting A wall mounting template can be obtained from Vent Axia technical support or refer to pages 8 & 9 for dimensions. If you are in receipt of wall mounting template, fix the template to the wall and ensure that it is level.
- Page 14 Installation Figure 8: Door Panel Hanging Bracket Positions Sentinel Kinetic MVHR with Cooker Hood Installation & Commissioning...
- Page 15 Installation Fitting Cooker Hood to Left Hand Unit Remove the cooker hood light cover using cross type screwdriver. After removing the light cover, turn the cooker hood to its opposite face. Unscrew the cable clip from inside, then insert the cable with its Figure 9: Passing cable through connector (fig.
-
Page 16: Attach Ducting
Installation Attach Ducting See the Sentinel Kinetic Installation & Commissioning document. Electrical Installation See the Sentinel Kinetic Installation & Commissioning document. Commissioning See the Sentinel Kinetic Installation & Commissioning document. Setting the Cooker Hood Flow Adjust the damper to give the correct flow as determined by the system designer. Airflow damper Front Panel Adjustment... -
Page 17: Maintenance
Installation Maintenance Caring for the Unit Heat recovery units, by their very nature, require regular maintenance. The Sentinel Kinetic has been designed to facilitate access to enable maintenance to be carried out easily. WARNING THE FAN AND ANCILLARY CONTROL EQUIPMENT MUST BE ISOLATED FROM THE POWER SUPPLY DURING MAINTENANCE. -
Page 18: Spares
Installation Spares The following spares may be ordered from Vent-Axia: Table 1: Spares Part No Description 497808 Control PCBA & Patch Cable Kit 441774 Filters, 2-pack (bypass version 438222) 441764 Heat Recovery Cell (bypass version 438222) 497812 Supply Motor & Cable Kit 497810 Exhaust Motor &... -
Page 19: Appendix A: Options And Accessories
For further details on options and accessories, refer to Sentinel Kinetic installation & commissioning documentation. PRODUCT FICHE For Residential Ventilation Units (Complying Commission Delegated Regulation (EU) No 1254/2014) Name: Vent-Axia Vent-Axia Kinetic CSH / L - 446759 Kinetic CWH / L- 446758 Model ID (Stock Ref.) :... - Page 20 TECHNICAL SUPPORT Tel: 0844 8560594 Fax: 01293 532814 For details of the warranty and returns procedure please refer to www.vent-axia or write to Vent-Axia Ltd, Fleming Way, Crawley, RH10 9YX 477254 G © 2016 Vent-Axia Limited. All rights reserved. 0921...
