OPERATOR'S MANUAL
WARNING
Revision #00
>
3108 Serial #611001
>
3110 Serial #612001
>
3112 Serial #613001
H&S MANUFACTURING CO.,INC.
P.O. BOX 768 (715) 387-3414 FAX (715) 384-5463
ACTION RAKE
3108/3110/3112
Manufactured By
MARSHFIELD, WISCONSIN 54449
READ AND UNDERSTAND THIS MANUAL
BEFORE OPERATING THIS EQUIPMENT.
UNSAFE OPERATION OR MAINTENANCE OF
THIS EQUIPMENT CAN RESULT IN SERIOUS
INJURY OR DEATH.
HSMFG0316
Part #75891
Advertisement
Table of Contents
Related Manuals for H&S 3108
Summary of Contents for H&S 3108
- Page 1 READ AND UNDERSTAND THIS MANUAL BEFORE OPERATING THIS EQUIPMENT. UNSAFE OPERATION OR MAINTENANCE OF WARNING THIS EQUIPMENT CAN RESULT IN SERIOUS INJURY OR DEATH. Revision #00 > 3108 Serial #611001 > 3110 Serial #612001 > 3112 Serial #613001 HSMFG0316 Part #75891 Manufactured By H&S MANUFACTURING CO.,INC.
-
Page 2: Table Of Contents
CONTENTS Warranty & Warranty Registration Card ..........1-2 Manufacturers Statement . -
Page 5: Dealer Pre-Delivery Checklist
DEALER PRE-DELIVERY CHECK LIST AFTER COMPLETION, DEALER SHOULD REMOVE AND RETAIN FOR RECORDS After the Rake has been completely set-up, check to be certain it is in correct operating order before delivering to the customer. The following is a list of points to inspect. Check off each item as you have made the proper adjustments and found the item operating satisfactorily. - Page 6 Intentionally Left Blank...
-
Page 7: Delivery Checklist
DEALER DELIVERY CHECK LIST AFTER COMPLETION, DEALER SHOULD REMOVE AND RETAIN FOR RECORDS This check list that follows is an important reminder of valuable information that should be passed on to the customer at the time this Rake is delivered. Check off each item as you explain it to the customer. - Page 8 Intentionally Left Blank...
-
Page 9: Safety Information - Be Alert Symbol
SAFETY INFORMATION YOUR SAFETY ALERT! IS INVOLVED. THIS SYMBOL IS USED THROUGHOUT THIS BOOK WHENEVER YOUR PERSONAL SAFETY IS INVOLVED. TAKE TIME TO BE CAREFUL. REMEMBER: THE CAREFUL OPERATOR IS THE BEST OPERATOR. MOST ACCIDENTS ARE CAUSED BY HUMAN ERROR. CERTAIN PRECAUTIONS MUST BE OBSERVED TO PREVENT THE POSSIBILITY OF INJURY OR DAMAGE. -
Page 10: Safety Information - Explanation Of Safety Signs
SAFETY INFORMATION Keep signs in good condition. Immediately replace any missing or damaged signs. RECOGNIZE SAFETY INFORMATION This is the safety-alert symbol. When you see this symbol on your machine or in this manual, be alert to the potential for personal injury. Follow recommended precautions and safe operating practices. -
Page 11: Safety Decals
SAFETY INFORMATION... -
Page 12: Safety Information - Warning - Owner Must Read And Understand
TRACTOR: This operators manual uses the term “Tractor” when identifying the power source. W A R N I N G TO PREVENT SERIOUS INJURY OR DEATH BEFORE YOU ATTEMPT TO OPERATE THIS EQUIPMENT, READ AND STUDY THE FOLLOWING INFORMATION. IN ADDITION, MAKE SURE THAT EVERY INDIVIDUAL WHO OPERATES OR WORKS WITH THIS EQUIPMENT, WHETHER FAMILY MEMBER OR EMPLOYEE, IS FAMILIAR WITH THESE SAFETY PRECAUTIONS. -
Page 13: Cap Screw Torque Value
-11-... -
Page 14: Set-Up & Assembly
SET-UP & ASSEMBLY NOTE: Determine right or left side of the Rake by viewing it from the rear. If instructions or parts lists call for hardened bolts, refer to the Cap Screw Torque Value page to identify. Assemble the Rake or check the Rake for proper assembly and adjustment. Make sure that all bolts are tightened. -
Page 15: Transporting
TRANSPORTING TRANSPORT LOCKS There are two hydraulic transport lock valves on the rake that must be turned to the closed position during transport in case of tractor valve leakage, or hose breakage. TOWING ON HIGHWAY Follow state and local regulations when towing farm equipment on public highways. Never tow the rake on a public highway at a speed greater than 20 m.p.h. -
Page 16: Preparing For Operation
PREPARING FOR OPERATION ADJUSTMENTS There are 5 sets of holes on the adjustable hitch. In addition, the hitch can also be flipped upside down to obtain 5 more positions, for a total of 10 positions to adjust for levelness. The hitch should be adjusted so the main rake beams are level, or parallel to the ground when in the raking position. -
Page 17: Operation & Adjustments
OPERATION & ADJUSTMENTS EMERGENCY SHUTDOWN Stop the tractor engine, remove ignition key, and allow all mechanisms to stop before cleaning or working on the machine. IMPORTANT: Retighten all bolts on the rake after 100 acres as bolts can loosen up on new machinery. Re-torque rake tooth bolts after first 100 acres. - Page 18 OPERATION & ADJUSTMENTS HYDRAULIC SYSTEM The Rake utilizes a 2 hose hook-up with a Master/Slave cylinder system. When the rake arms are lowered, the axles rotate forward, raising the main frame for more clearance. When the rake arms are raised, the axles rotate rearward, lowering the main frame for transport.
- Page 19 OPERATION & ADJUSTMENTS FLEXIBILITY Rake Wheels Each rake wheel oscillates independently through the wheel arm mount bolt with the slotted style hole. ONE SIDED RAKING Raking with one side can be accomplished by closing either of the transport lock valves when the rake is in the transport position.
-
Page 20: Optional Equipment
OPTIONAL EQUIPMENT CENTER KICKER WHEEL An optional center kicker wheel is available. If the hay is laying out flat, the extra wheel allows you to raise the hay laying in the center of the rake out of the stubble for easier pick-up. -
Page 21: Lubrication Guide
LUBRICATION Become familiar with all lubrication points and establish a routine to ensure complete lubrication of the rake. GENERAL INFORMATION IMPORTANT: Catch and dispose of fluid per local waste disposal regulations whenever service is performed on hydraulic components, valves, cylinders, hoses, etc. WHEEL BEARING LUBRICATION, CLEAN &... - Page 22 LUBRICATION NOTE: LUBRICATION POINTS (1) on each rake ARE THE SAME ON THE RIGHT arm pivot point SIDE AS THE LEFT SIDE (2) 1 on the bottom of each “ACTION” pivot point (2) on the top of each lift arm (1) on each rake wheel hub assembly...
-
Page 23: Decal Location
Stay Clear of Rake 11599 Do not go near leaks 54033 U.S.A. 71188B Jack Storage Position 71565 Hydraulic Position Valve 72326 3108 Decal 72327 3110 Decal 72328 3112 Decal 69083 Action Rake Decal/Right 69084 Action Rake Decal/Left 82602 Crushing Hazard... - Page 24 DECAL LOCATION 093020 11599 DC31811 71565 71565 093020 1906C 1906C DC31811 72203A 54033 82907L 71188B -22-...
- Page 25 DECAL LOCATION 2700A 82602 DCAMB 11599 DCAMB 69083 72326 - 3108 72327 - 3110 72328 - 3112 2700B 093020 on each 093020 on each rake arm pivot point rake arm pivot point NOTE: DECALS & LOCATION ARE THE SAME ON THE RIGHT SIDE AS THE LEFT SIDE...
-
Page 26: Troubleshooting Guide
DECAL LOCATION 11599 093020 DCAMB 69084 2700A 82602 72326 - 3108 DCAMB 72327 - 3110 72328 - 3112 093020 093020 2700A B6DC 2700A DCRED DCRED -24-... - Page 27 TROUBLESHOOTING NOTE:This Troubleshooting Chapter presents problems, causes and suggested remedies beyond the extent of loose, worn or missing parts and it was developed with the understanding that the machine is in otherwise good operating condition. WARNING: MAKE SURE THAT THE TRACTOR IS SHUT OFF AND THE RAKE CAN NOT MOVE BEFORE SERVICING THE RAKE.
- Page 28 -24-...
-
Page 29: Specifications
SPECIFICATIONS 3108 3110 3112 Number of Wheels....8 ....10....12 .. - Page 30 H&S MFG H&S MFG ..CO H&S MFG CO ..H&S MFG H&S MFG products approved for the FEMA FEMA FEMA FEMA FEMA SEAL OF Q SEAL OF Q U U U U U ALITY SEAL OF Q ALITY ALITY...
