Operating instructions
TYPE
Voltage
Manuf. no.
Your service centre ...............................................
KF 903
KF 1203
KF 1403
...............................................
...............................................
...............................................
...............................................
64401 A 99/03
page 1 - 15
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DITTING KF 903
Summary of Contents for DITTING KF 903
- Page 1 Operating instructions KF 903 KF 1203 KF 1403 TYPE Voltage Manuf. no. Your service centre ................................................64401 A 99/03 page 1 - 15...
-
Page 2: Table Of Contents
Operating instructions Contents page General Warranty information Transfer declaration General safety instructions 1.3.1 Information and safety symbols Installation of coffee grinder Description and installation of unit How to use the coffee grinder Care / Maintenance / Adjustment Care and cleaning of the coffee grinder Maintenance Setting the scale (adjustment) 3.3.1... -
Page 3: General
General Dear Customer, We congratulate and thank you for purchasing a DITTING quality product. These operating instructions have been prepared to simplify your use of the coffee grinder. They contain information, advice and instructions for the best use of your unit. -
Page 4: Transfer Declaration
Operating instructions Transfer declaration To ensure transfer of the operating instructions to final consumers Note: The following declaration should be completed by the dealer and the purchaser. The purchaser undertakes to return this declaration to the dealer. The purchaser thereby certifies that the dealer has drawn his attention to the contents of operating instructions no. -
Page 5: General Safety Instructions
Only original grinding discs sharpened by DITTING must be used. Never reach into the hopper opening while the machine is running. Never touch electrical components with conducting objects, such as needles, pins, cutlery, etc. -
Page 6: Information And Safety Symbols
The grinding fineness can be set from "Turkish fine" to "coarse" with an adjusting knob provided with a scale. The KF 903/1003/1203/1403 coffee grinders are suitable for use in medium-sized to large food stores, coffee companies and roasting plants. The simple method of operation enables customers to use the grinder themselves in self-service stores. -
Page 7: How To Use The Coffee Grinder
Operating instructions 2.1.1 Switch on overload protector, if necessary (option). How to use the coffee grinder Set the required grinding fineness on the scale with adjusting knob (1). Open the filling cover (2) and place coffee beans in hopper (3). Attach empty paper bag with bag holding lever (4) onto discharge tube (5) . -
Page 8: Care / Maintenance / Adjustment
Operating instructions Care / maintenance / adjustment Care and cleaning of coffee grinder The coffee grinder must only be cleaned with a dry cloth. Do not use an alkaline cleaning agent. Do not spray coffee grinder with water and/or steam. Reason: It can result in a short-circuit and therefore damage to the unit. -
Page 9: Basic Setting (Calibration)
Operating instructions 3.3.1 Basic setting (calibration) If the basic setting is incorrect, friction can occur between the grinding discs, resulting in excessive wear. Switch on motor. Unscrew screw (1) at centre of adjusting knob (2) approx. 3 - 5 mm, do not remove. Pull out (3) adjusting knob (2) and turn 1/4 of a revolution anti-clockwise (4). -
Page 10: Changing The Scale Setting (Customer Setting)
Operating instructions 3.3.2 Changing the scale setting (adjustment for customer settings) Switch off motor. Unscrew screw (1) at centre of adjusting knob (2) approx. 3 - 5 mm, do not remove. Set required number of divisions by pulling out adjusting knob (2), turning in the corresponding direction and re-engaging. -
Page 11: Replacing The Grinding Discs
Operating instructions Replacing grinding discs Before changing grinding discs switch off motor without fail and disconnect power cable ! The grinding discs must only be replaced by persons familiar with operation of the machine according to the following instructions. Switch off motor and pull out power cable. -
Page 12: Faults / Action
Operating instructions Plug in power cable, switch on coffee grinder briefly. If it blocks or there is a sound of metal parts rubbing together, the scale setting must be adjusted according to 3.3.2. Retighten screws (6) of the stationary disc flange. -
Page 13: Repairs
Operating instructions Repairs Switch off motor and pull out power cable before all major repairs requiring work inside the machine, in order to avoid danger of injury while working on motor while running and electric shock ! The electrical wiring diagram for this grinder is placed either: - inside the bottom section of the housing panel or - on the inside of the bottom plate 4.2.1... -
Page 14: Replacing The Rubber Bolt Of Discharge Tube
Operating instructions Remove foreign bodies. Check grinding discs, rotating and stationary disc flange, etc. for damage. All supporting surfaces of stationary disc flange, rotating disc flange, grinding discs and grinding case must be absolutely clean before assembly. Only in this way can perfect grinding be guaranteed. Then re-assemble parts... -
Page 15: Overload Protector (Optional For 1203/1403 Models)
Data such as manufacturing number and type of power supply as specified on the nameplate of the coffee grinder should be stated on orders for grinding discs, spare-parts and accessories to ensure rapid and efficient advice and delivery. Ditting Maschinen AG CH-8184 Bachenbülach Switzerland...
