  • Page 1 CSQ-Visual Version with CSQVIO8 card Installation manual Nov. 20, 2013...
  • Page 2: Table Of Contents

    Installing CSQ-Visual ......................3 Important notes for installation ...................... 3 Operating of the instrument ......................3 Internal cards............................ 4 Electric wiring........................... 4 Special functions ........................12 Configure automatic work selection ..................... 12 Configuring the use of the phases....................13 Connection of an external reset ..................... 14 SETPOINT output..........................
  • Page 3: Installing Csq-Visual

    (where installed) and the warning lights. 1.1 Important notes for installation This manual refers only to the instrument with expansion card CSQVIO8. The CSQ-Visual has to be powered at 24VDC. An optional internal power feeder is available, enabling direct connection to the mains power.
  • Page 4: Internal Cards

    PLC. In this case the signal to be given to the instrument may be taken parallel to that delivered to the PLC. 1.4.2 CSQVIO8 card wiring Attention: this information refers only to the CSQVIO8 card. Check that the correct type of card is fitted.
  • Page 5 The wiring is supported by removable terminal blocks (X3, X4, X5...). Every terminal on every terminal block is numbered. For example, when terminal X5.7 is indicated, reference is made to the seventh terminal of terminal block X5. The numbers are also printed on the printed circuit of the card.
  • Page 6 Inputs terminal block (X3) The inputs are optoinsulated and compatible with clean contact signals or 24 VDC PNP transistor outputs. Name Terminal Default Input 0 X3.1 START Input 8 X3.2 Input 1 X3.3 T.D.C.(1) Input 9 X3.4 Input 2 X3.5 Input 3 X3.6 Input 4...
  • Page 7 Control for electric lock lever on mechanical presses OPEN GREEN BOX Command for opening basket of the good pieces CLOSE PK TANK Closing command of the tank on the Alfamatic PK cilinders BLOCK OF THE TABLE Block piece for work PULL LEVER...
  • Page 8 Position transducer input terminal block (X5) An incremental encoder and a 0-10V signal can be connected to the X5 terminal block. A 12VDC power supply is available for the encoder. A very high-precision 10VDC power supply is available for the potentiometer. Name Terminal Description...
  • Page 9 Terminal X6.2 e X6.3 circuit Load cell 2mV/V working in compressed only mode * Load cell 2mV/V working in compressed and traction 0-10V signal 0-5V signal * default...
  • Page 10 Tipical connection...
  • Page 11 Pin 5: GND 1.4.3 CSQVIO8 card options The CSQVIO8 card can be supplied with special optional features: Option for several load cells It is possible to connect up to six load cells to the instrument to simultaneously check six curves. In...
  • Page 12: Special Functions

    2 Special functions 2.1 Configure automatic work selection The CSQ-Visual supports the automatic selection of work using the combination of the inputs or a command sent to the serial port. This selection can be useful for automatically recognising the piece or the tool fitted. To enable the automatic selection of work it is necessary to give the instrument the maximum number of selectable works and the way in which they are selected.
  • Page 13: Configuring The Use Of The Phases

    Example of wiring of three sensors (selection of 5 to 8 works): 2.1.2 Selection through serial command The CSQ-Visual supports serial communication through which it is possible to select a work remotely. Using serial communication, it is possible to select up to 250 works. To be able to operate it is necessary to enable slow serial communication and set the Automatic selection code.
  • Page 14: Connection Of An External Reset

    If required, it is possible to save them first on the computer using the WinScope program. 2.3 Connection of an external reset When a reject is detected, the instrument blocks, preventing the machining of other pieces. The release the instrument it is necessary to reset the reject. It is possible to connect an external reset signal which can be a button, key or sensor.
  • Page 15: Instructions For Setting Up The Csq-Visual

    3 Instructions for setting up the CSQ-Visual Always disconnect the instrument from the electricity supply before opening it. Open the CSQ-Visual by loosening the four screws in the corners of the front panel. Figure 3 Pull out the internal cards by a few centimetres. Then release the cards from the front panel. Figure 4 Pull out all the cards from the container and remove the five terminal block units.
  • Page 16 Figure 5 Slot the wires through the wire passage and start wiring. It is extremely important for the end of the wire of the load cell which is not covered by a sheath to be as short as possible: Figure 6 After completing the wiring, insert the card: Lastly, insert the terminal block units, paying attention to the direction.

This manual is also suitable for:
