UTC Fire and Security Interlogix VT7420-2DRDT Installation & Operation Instructions page 4

A
B
C D
E
F
G
H
I
VT7430-2DRDT
1 2
CARRIER DETECT
CHAN 1
CAMERA ON
J
K
L
A
Carrier Detect
B
Channel A Data: Switch 1
C
Channel A Data: Switch 2
D
Electrical Data Transmitted Channel A
E
Optical Data Received Channel A
F
Video Input From Camera: Channel 1
G
Camera 1 "ON"
H
Video Input From Camera: Channel 2
I
Camera 2 "ON"
J
Video Input From Camera: Channel 3
K
Camera 3 "ON"
L
Video Input From Camera: Channel 4
M
Camera 4 "ON"
N
Power
O
Electrical Data Transmitted Channel B
P
Optical Data Received Channel B
Q
Channel B Data: Switch 1
R
Channel B Data: Switch 2
A
TX RX TX RX
CHAN 3
CHAN 2
M
B
1 2
CHAN 4
POWER
LED: RED to GREEN
LED: RED to GREEN
LED: RED to GREEN
LED: Illuminates
LED: Illuminates
LED: Illuminates
LED: Illuminates
LED: Illuminates
LED: RED to GREEN
LED: RED to GREEN
R
Q
P
O
N
