Read the entire instruction manual before you start installation and
assembly. If you have any questions regarding any of the instructions or
warnings, please contact your local distributor for assistance.
CAUTION: Use with products heavier than the rated weights indicated
may result in instability causing possible injury.
1.Mounts must be attached as specified in assembly instructions.
Improper installation may result in damage or serious personal injury.
2.Safety gear and proper tools must be used. This product should only
be installed by professionals.
3.Make sutr that the supporting surface will safely support the combined
weight of the equipment and all attached hardware and components.
4.Use the mounting screws provided and DO NOT OVER TIGHTEN
mounting screws
5.This product contains small items that could be a choking hazard if
swallowed. Keep these items away from children.
6.This product is intended for indoor use only. Using this product
outdoors could lead to product failure and personal injury.
IMPORTANT: Ensure that you have received all parts according to the
component checklist prior to installation. If any parts are missing or faulty,
telephone your local distributor for a replacement.
MAINTENANCE:Check that the bracket is secure and safe to use at
regular intervals(at least every three months).
INSTALLATION MANUAL
SBR-201
SBR201
15kg
(33lbs)
RATED

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SBR201 and is the answer not in the manual?

Questions and answers

Summary of Contents for Suptek SBR201

  • Page 1 SBR201 INSTALLATION MANUAL Read the entire instruction manual before you start installation and assembly. If you have any questions regarding any of the instructions or warnings, please contact your local distributor for assistance. CAUTION: Use with products heavier than the rated weights indicated may result in instability causing possible injury.
  • Page 2 1b-1 A/B/C M4X16(X2) M5X16(X2) M6X16(X4) M8X20(X2) M6X30(X4) M8X30(X4) D5x12(X2) D8x16(X4) I(X4) J(X4) K(X2) M6X12(X2) M6(X2) 1b-2 1a-1 A/B/C G/H 1a-2...
