Suptek ML1700S Instruction Manual

Instruction Manual
Severe personal injury and property damage can result from improper
installation or assembly. Read the following warning carefully before
beginning.
● If you do not understand the instructions or have any concerns or
questions,please contact a qualified local installer.
● Do not install or assemble if the product or hardware is damaged or
missing,if you require replacement parts, please contact your local distributor
for assistance.
● This product fits most 32"- 70" LCD/ plasma screen; maximum weight of
LCD/ plasma screen:220lbs/100KG; Lower shelf max load: 22lbs/10kg.
● Do not use this product for anything other than the original design.
● This product contains moving parts, please use with caution.
32 "-70"
Step 1 The installation of the base and column
1.1
1.2
Column
ML1700S
max 600X400
220lbs
（ 100 kg）
VESA
Castor
Base
H
A
B
Parts
Base x1 Column x2
Left and right Upper shelf connecting
pole x1
hook x2
Screw package
A:M8x55 B:Wrench (x1)
(x4)
E:M5x50 E:M5x8
(x2) (x4)
G:Φ6xΦ18x0.6 washer H:M8 nut
(x4)
I:M8x25 I:M6x25
(x4) (x4)
J:S5/S6 (x1) J: low spacer (x4)
Step 2 The installation of the column and lower shelf
J
D
G
第
Column
Lower shelf
Lower shelf x1 Panel x1
Upper shelf x1 Castors x4
C:M8x55
D:M6x50
(x4)
(x4)
F:M6x14 G:M6 nut
(x4) (x4)
H:Φ8xΦ18x0.6 washer
(x4) (x12)
I:M5x25 I:M4x25
(x4) (x4)
J: high spacer (x4)
G
Column
